SDO HMI 2014-07-06 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 110.21 | 655.86 | 59.59 | 354.36 | -19.20 | 255.74 | 6.13 | 194.56 | 0.4003 | 736.1 | 348.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.00 | 0.00 | 0.58 | -22.75 | 267.46 | 17.85 | 212.79 | 0.5239 | 669.0 | 572.4 | |
| 0.00 | 0.82 | 0.00 | 0.46 | -20.17 | 266.08 | 16.47 | 213.76 | 0.4809 | 902.0 | 748.2 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -20.89 | 265.34 | 15.74 | 211.72 | 0.4838 | 846.0 | 742.4 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -21.76 | 265.20 | 15.59 | 210.50 | 0.4938 | 652.0 | 507.4 | |
| 0.00 | 1.91 | 0.00 | 1.10 | -23.96 | 264.35 | 14.74 | 206.90 | 0.5160 | 667.0 | 587.7 | |
| 0.00 | 1.91 | 0.00 | 1.06 | -20.15 | 263.15 | 13.54 | 208.88 | 0.4571 | 867.0 | 656.4 | |
| 0.00 | 2.09 | 0.00 | 1.17 | -20.52 | 262.95 | 13.34 | 208.11 | 0.4605 | 948.0 | 777.2 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -22.06 | 262.89 | 13.28 | 206.39 | 0.4808 | 463.0 | 475.8 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -17.31 | 262.27 | 12.66 | 210.67 | 0.4119 | 770.0 | 586.7 | |
| 10.09 | 15.54 | 5.64 | 8.68 | -21.08 | 262.46 | 12.85 | 206.66 | 0.4646 | 946.8 | 681.6 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -22.73 | 262.55 | 12.94 | 205.16 | 0.4877 | 687.0 | 581.9 | |
| 0.00 | 1.36 | 0.00 | 0.76 | -21.07 | 262.03 | 12.42 | 205.89 | 0.4615 | 844.0 | 683.4 | |
| 0.00 | 0.91 | 0.00 | 0.50 | -20.47 | 259.42 | 9.81 | 201.55 | 0.4366 | -825.0 | -600.2 | |
| 0.00 | 1.73 | 0.00 | 0.98 | -24.66 | 258.20 | 8.59 | 196.09 | 0.4915 | -637.0 | -559.2 | |
| 2.27 | 11.18 | 1.26 | 6.19 | -22.09 | 256.87 | 7.26 | 195.22 | 0.4479 | -1058.7 | -693.3 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -22.56 | 256.59 | 6.98 | 194.38 | 0.4539 | -846.0 | -733.1 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -21.51 | 256.31 | 6.70 | 194.45 | 0.4369 | -871.0 | -721.6 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -21.27 | 256.10 | 6.49 | 194.17 | 0.4325 | -735.0 | -598.9 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -23.54 | 255.91 | 6.30 | 192.51 | 0.4662 | -864.0 | -685.2 | |
| 92.13 | 564.15 | 49.62 | 303.83 | -18.90 | 255.62 | 6.01 | 194.62 | 0.3942 | 1511.6 | 436.2 | |
| 0.00 | 1.64 | 0.00 | 0.91 | -23.16 | 255.72 | 6.11 | 192.34 | 0.4599 | -924.0 | -826.4 | |
| 1.00 | -20.00 | 0.54 | -20.00 | -19.53 | 255.38 | 5.77 | 193.66 | 0.4030 | 855.5 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.46 | -23.78 | 255.35 | 5.74 | 191.33 | 0.4680 | -723.0 | -610.3 | |
| 1.27 | -20.00 | 0.68 | -20.00 | -18.54 | 254.83 | 5.22 | 192.99 | 0.3854 | 1122.2 | 999999 | |
| 0.00 | 0.55 | 0.00 | 0.29 | -17.48 | 254.16 | 4.55 | 191.97 | 0.3664 | -661.0 | -475.7 | |
| 0.00 | 1.64 | 0.00 | 0.90 | -21.42 | 253.94 | 4.33 | 189.49 | 0.4279 | 834.0 | 611.9 | |
| 0.00 | 1.36 | 0.00 | 0.75 | -21.22 | 253.84 | 4.23 | 189.35 | 0.4244 | 533.0 | 501.8 | |
| 0.00 | 0.82 | 0.00 | 0.44 | -18.76 | 253.77 | 4.16 | 190.32 | 0.3855 | 644.0 | 507.7 | |
| 0.00 | 1.82 | 0.00 | 1.01 | -23.73 | 253.34 | 3.73 | 187.44 | 0.4622 | -631.0 | -339.5 | |
| 0.00 | 2.00 | 0.00 | 1.07 | -18.30 | 253.15 | 3.54 | 189.00 | 0.3764 | -646.0 | -570.8 | |
| 0.00 | 1.45 | 0.00 | 0.78 | -18.56 | 252.93 | 3.32 | 188.34 | 0.3800 | -877.0 | -706.4 | |
| 0.00 | 0.64 | 0.00 | 0.34 | -19.48 | 252.07 | 2.46 | 185.94 | 0.3931 | 586.0 | 533.0 | |
| 1.36 | 4.00 | 0.73 | 2.14 | -18.95 | 251.94 | 2.33 | 185.76 | 0.3844 | -995.5 | -787.1 | |
| 0.00 | 2.09 | 0.00 | 1.12 | -19.31 | 251.68 | 2.07 | 185.05 | 0.3898 | 824.0 | 667.0 | |
| 0.00 | 0.82 | 0.00 | 0.44 | -20.31 | 251.37 | 1.76 | 184.09 | 0.4053 | -731.0 | -525.9 | |
| 2.09 | 6.36 | 1.12 | 3.41 | -19.14 | 251.07 | 1.46 | 183.58 | 0.3864 | -1061.6 | -746.9 | |
| 0.00 | 1.00 | 0.00 | 0.54 | -19.74 | 250.88 | 1.27 | 183.03 | 0.3958 | -608.0 | -589.4 | |
| 0.00 | 2.00 | 0.00 | 1.08 | -19.64 | 250.16 | 0.56 | 181.33 | 0.3937 | -878.0 | -612.5 | |
| 0.00 | 0.82 | 0.00 | 0.47 | -26.60 | 250.19 | 0.58 | 181.03 | 0.5027 | -686.0 | -512.9 | |
| 0.00 | 2.00 | 0.00 | 1.08 | -19.87 | 250.04 | 0.43 | 181.01 | 0.3974 | -786.0 | -643.1 | |
| 0.00 | 4.91 | 0.00 | 2.65 | -19.77 | 249.71 | 0.10 | 180.24 | 0.3957 | -903.0 | -674.3 | |
| 0.00 | 1.00 | 0.00 | 0.54 | -19.84 | 249.32 | -0.29 | 179.32 | 0.3968 | -732.0 | -623.9 | |
| 0.00 | 1.27 | 0.00 | 0.68 | -19.11 | 248.97 | -0.64 | 178.42 | 0.3852 | -685.0 | -640.2 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -19.01 | 248.23 | -1.38 | 176.59 | 0.3841 | -731.0 | -512.1 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -24.58 | 246.02 | -3.59 | 173.09 | 0.4750 | -709.0 | -511.0 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -24.37 | 246.03 | -3.58 | 173.04 | 0.4718 | -801.0 | -697.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
