SDO HMI 2014-07-06 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.98 | 140.46 | 21.30 | 100.88 | 6.53 | 203.23 | -46.38 | 84.25 | 0.7248 | -476.1 | -252.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.94 | 9.58 | 205.89 | -43.72 | 79.73 | 0.6948 | -618.0 | -501.7 | |
| 2.91 | 14.08 | 2.03 | 9.85 | 6.74 | 204.65 | -44.96 | 83.90 | 0.7081 | -997.4 | -620.6 | |
| 2.63 | -2.00 | 1.85 | -2.00 | 6.95 | 204.53 | -45.08 | 83.60 | 0.7095 | -833.9 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.58 | 9.02 | 204.11 | -45.50 | 80.73 | 0.7160 | -588.0 | -519.6 | |
| 0.00 | 0.73 | 0.00 | 0.51 | 6.99 | 203.92 | -45.69 | 83.58 | 0.7171 | -315.0 | -350.0 | |
| 19.99 | 101.04 | 14.21 | 71.88 | 6.31 | 203.73 | -45.88 | 84.54 | 0.7191 | -1044.9 | -301.0 | |
| 0.45 | 1.45 | 0.33 | 1.05 | 8.39 | 203.01 | -46.60 | 81.70 | 0.7287 | -550.8 | -469.7 | |
| 4.00 | 9.63 | 2.88 | 6.94 | 7.23 | 203.04 | -46.57 | 83.30 | 0.7277 | -695.1 | -402.7 | |
| 0.00 | 1.00 | 0.00 | 0.77 | 6.10 | 199.62 | -49.99 | 84.92 | 0.7669 | 627.0 | 510.3 | |
| 0.00 | 1.45 | 0.00 | 1.12 | 5.94 | 199.49 | -50.12 | 85.13 | 0.7683 | 662.0 | 540.6 | |
| 0.00 | 1.54 | 0.00 | 1.20 | 6.08 | 199.28 | -50.33 | 84.95 | 0.7706 | 607.0 | 523.9 | |
| 0.00 | 1.45 | 0.00 | 1.14 | 6.64 | 198.82 | -50.79 | 84.23 | 0.7758 | 559.0 | 433.4 | |
| 0.00 | 1.00 | 0.00 | 0.81 | 6.73 | 197.42 | -52.19 | 84.14 | 0.7910 | 460.0 | 407.5 | |
| 0.00 | 0.27 | 0.00 | 0.22 | 8.14 | 196.77 | -52.84 | 82.38 | 0.7981 | 505.0 | 496.3 | |
| 0.00 | 0.82 | 0.00 | 0.67 | 7.02 | 196.97 | -52.64 | 83.79 | 0.7958 | 497.0 | 416.7 | |
| 0.00 | 0.27 | 0.00 | 0.22 | 8.07 | 196.58 | -53.03 | 82.47 | 0.8001 | 387.0 | 360.0 | |
| 0.00 | 2.09 | 0.00 | 1.71 | 6.88 | 196.73 | -52.88 | 83.96 | 0.7982 | 374.0 | 332.5 | |
| 0.00 | 0.91 | 0.00 | 0.75 | 7.03 | 196.61 | -53.00 | 83.78 | 0.7996 | 247.0 | 287.7 | |
| 0.00 | 0.55 | 0.00 | 0.52 | 8.10 | 190.82 | -58.79 | 82.60 | 0.8559 | 462.0 | 402.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
