SDO HMI 2014-07-06 12:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 356.75 | 1763.06 | 182.35 | 901.00 | -7.33 | 239.16 | -8.80 | 141.94 | 0.2451 | 29.1 | 57.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 12:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.65 | -9.49 | 243.09 | -4.87 | 159.47 | 0.2398 | -507.0 | -251.7 | |
| 35.79 | 882.08 | 18.15 | 447.87 | -7.72 | 242.87 | -5.09 | 155.53 | 0.2133 | 1395.3 | 465.0 | |
| 0.64 | -2.00 | 0.32 | -2.00 | -9.43 | 242.78 | -5.18 | 158.19 | 0.2408 | -862.0 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -5.00 | 242.78 | -5.18 | 148.43 | 0.1727 | -887.0 | -644.8 | |
| 2.27 | -2.00 | 1.16 | -2.00 | -9.12 | 242.51 | -5.45 | 156.64 | 0.2377 | 562.2 | 999999 | |
| 0.00 | 1.73 | 0.00 | 0.87 | -5.40 | 242.53 | -5.43 | 148.42 | 0.1809 | -703.0 | -468.9 | |
| 5.72 | -2.00 | 2.90 | -2.00 | -7.53 | 242.47 | -5.49 | 153.48 | 0.2134 | 1272.0 | 999999 | |
| 0.91 | -2.00 | 0.46 | -2.00 | -8.31 | 242.46 | -5.50 | 154.99 | 0.2254 | 720.0 | 999999 | |
| 0.00 | 2.54 | 0.00 | 1.28 | -5.80 | 242.40 | -5.56 | 148.97 | 0.1879 | 842.0 | 526.5 | |
| 7.27 | 11.81 | 3.72 | 6.04 | -9.62 | 242.10 | -5.87 | 155.95 | 0.2483 | 999.4 | 601.6 | |
| 1.91 | -2.00 | 0.97 | -2.00 | -8.75 | 242.05 | -5.91 | 154.23 | 0.2352 | 932.8 | 999999 | |
| 64.41 | -2.00 | 32.68 | -2.00 | -7.57 | 242.04 | -5.92 | 151.78 | 0.2173 | 1470.2 | 999999 | |
| 2.45 | -2.00 | 1.24 | -2.00 | -6.91 | 242.02 | -5.95 | 150.19 | 0.2077 | 1384.4 | 999999 | |
| 2.73 | -2.00 | 1.39 | -2.00 | -8.97 | 241.83 | -6.13 | 153.81 | 0.2402 | 792.3 | 999999 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -9.53 | 241.79 | -6.17 | 154.67 | 0.2491 | 631.0 | 509.0 | |
| 2.18 | -2.00 | 1.11 | -2.00 | -7.29 | 241.67 | -6.29 | 149.68 | 0.2162 | 1436.2 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -9.41 | 241.57 | -6.39 | 153.68 | 0.2488 | 786.0 | 683.4 | |
| 36.06 | -2.00 | 18.32 | -2.00 | -7.57 | 241.48 | -6.48 | 149.59 | 0.2220 | 1348.8 | 999999 | |
| 1.82 | -2.00 | 0.93 | -2.00 | -8.10 | 241.29 | -6.68 | 150.04 | 0.2315 | 1011.0 | 999999 | |
| 3.09 | -2.00 | 1.57 | -2.00 | -7.20 | 241.12 | -6.85 | 147.30 | 0.2199 | 1092.4 | 999999 | |
| 1.00 | -2.00 | 0.51 | -2.00 | -8.19 | 241.10 | -6.86 | 149.55 | 0.2345 | 878.9 | 999999 | |
| 3.54 | -2.00 | 1.80 | -2.00 | -6.98 | 240.93 | -7.03 | 146.07 | 0.2185 | 905.2 | 999999 | |
| 6.27 | -2.00 | 3.19 | -2.00 | -7.60 | 240.89 | -7.07 | 147.45 | 0.2278 | 980.4 | 999999 | |
| 1.27 | -2.00 | 0.65 | -2.00 | -7.67 | 240.83 | -7.13 | 147.37 | 0.2292 | 814.2 | 999999 | |
| 0.00 | 7.99 | 0.00 | 4.10 | -9.88 | 240.66 | -7.30 | 151.43 | 0.2630 | 844.0 | 649.1 | |
| 0.00 | 2.18 | 0.00 | 1.10 | -4.55 | 240.69 | -7.27 | 137.66 | 0.1882 | 1052.0 | 823.8 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -6.09 | 240.64 | -7.32 | 142.48 | 0.2090 | 126.0 | 56.5 | |
| 0.91 | -2.00 | 0.46 | -2.00 | -6.55 | 240.51 | -7.45 | 143.32 | 0.2167 | 1109.4 | 999999 | |
| 2.63 | -2.00 | 1.34 | -2.00 | -6.40 | 240.48 | -7.48 | 142.78 | 0.2149 | 1020.0 | 999999 | |
| 0.73 | -2.00 | 0.37 | -2.00 | -6.27 | 240.30 | -7.67 | 141.76 | 0.2152 | 826.4 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -4.49 | 240.32 | -7.64 | 136.03 | 0.1918 | 823.0 | 634.1 | |
| 2.36 | -2.00 | 1.20 | -2.00 | -6.00 | 240.21 | -7.75 | 140.62 | 0.2124 | -731.6 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -9.17 | 240.02 | -7.94 | 147.93 | 0.2580 | -571.0 | -509.9 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -4.55 | 240.07 | -7.89 | 135.34 | 0.1955 | 1017.0 | 839.2 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -7.05 | 240.03 | -7.93 | 142.99 | 0.2284 | 658.0 | 571.5 | |
| 0.00 | 2.18 | 0.00 | 1.11 | -7.52 | 240.03 | -7.94 | 144.16 | 0.2348 | -99.0 | -169.9 | |
| 0.00 | 1.27 | 0.00 | 0.64 | -3.97 | 240.08 | -7.88 | 133.17 | 0.1884 | 770.0 | 670.8 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -8.33 | 239.85 | -8.11 | 145.54 | 0.2477 | 569.0 | 552.8 | |
| 1.36 | 8.54 | 0.69 | 4.34 | -6.87 | 239.85 | -8.11 | 141.86 | 0.2278 | 894.4 | 549.7 | |
| 0.00 | 1.64 | 0.00 | 0.83 | -7.46 | 239.84 | -8.12 | 143.38 | 0.2358 | 750.0 | 434.1 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -7.08 | 239.79 | -8.18 | 142.22 | 0.2314 | 478.0 | 392.3 | |
| 1.36 | 8.99 | 0.69 | 4.57 | -6.28 | 239.68 | -8.28 | 139.59 | 0.2219 | 945.4 | 718.8 | |
| 0.00 | 2.27 | 0.00 | 1.16 | -8.48 | 239.60 | -8.36 | 145.08 | 0.2523 | 789.0 | 716.8 | |
| 0.00 | 2.18 | 0.00 | 1.11 | -7.61 | 239.59 | -8.37 | 142.94 | 0.2405 | -399.0 | -247.2 | |
| 0.00 | 4.27 | 0.00 | 2.17 | -6.47 | 239.58 | -8.38 | 139.81 | 0.2254 | 36.0 | 21.2 | |
| 1.27 | 5.00 | 0.65 | 2.56 | -8.42 | 239.32 | -8.64 | 144.05 | 0.2543 | 730.4 | 415.7 | |
| 1.18 | 6.81 | 0.61 | 3.50 | -8.77 | 239.16 | -8.80 | 144.33 | 0.2606 | 1003.2 | 804.5 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -6.62 | 239.08 | -8.88 | 138.62 | 0.2330 | 770.0 | 567.6 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -5.23 | 239.11 | -8.86 | 134.40 | 0.2155 | 855.0 | 639.6 | |
| 1.36 | 13.63 | 0.70 | 6.96 | -7.59 | 239.03 | -8.93 | 141.07 | 0.2460 | -866.7 | -256.2 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -5.67 | 239.04 | -8.93 | 135.59 | 0.2216 | 748.0 | 523.2 | |
| 0.00 | 3.45 | 0.00 | 1.75 | -5.79 | 238.97 | -8.99 | 135.77 | 0.2239 | 468.0 | 237.6 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -9.27 | 238.80 | -9.16 | 144.38 | 0.2710 | 646.0 | 542.2 | |
| 1.18 | -50.00 | 0.60 | -50.00 | -7.59 | 238.81 | -9.15 | 140.40 | 0.2484 | -912.7 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -8.74 | 238.53 | -9.43 | 142.40 | 0.2665 | -689.0 | -461.7 | |
| 0.00 | 2.09 | 0.00 | 1.07 | -7.53 | 238.44 | -9.52 | 139.12 | 0.2517 | -673.0 | -556.5 | |
| 1.82 | 3.91 | 0.93 | 2.00 | -7.41 | 238.13 | -9.83 | 137.89 | 0.2536 | -787.2 | -550.4 | |
| 5.09 | 697.76 | 2.59 | 359.08 | -5.92 | 238.10 | -9.86 | 133.53 | 0.2360 | -1223.6 | -421.4 | |
| 0.00 | 0.73 | 0.00 | 0.37 | -9.25 | 237.89 | -10.07 | 141.73 | 0.2798 | 637.0 | 539.5 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -7.16 | 237.89 | -10.07 | 136.53 | 0.2534 | -728.0 | -505.3 | |
| 5.45 | -58.00 | 2.78 | -58.00 | -5.68 | 237.86 | -10.11 | 132.06 | 0.2362 | -1143.4 | 999999 | |
| 0.00 | 2.63 | 0.00 | 1.35 | -7.48 | 237.47 | -10.49 | 136.23 | 0.2621 | -800.0 | -606.6 | |
| 5.45 | -58.00 | 2.78 | -58.00 | -5.53 | 237.39 | -10.57 | 130.31 | 0.2405 | 891.4 | 999999 | |
| 0.00 | 2.27 | 0.00 | 1.17 | -8.01 | 237.33 | -10.63 | 137.23 | 0.2701 | -757.0 | -584.1 | |
| 1.00 | -58.00 | 0.51 | -58.00 | -6.52 | 237.28 | -10.68 | 133.02 | 0.2531 | -1021.5 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -9.82 | 237.18 | -10.78 | 141.09 | 0.2947 | -819.0 | -519.8 | |
| 0.64 | -58.00 | 0.33 | -58.00 | -6.64 | 237.18 | -10.78 | 133.13 | 0.2557 | -984.4 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -5.22 | 237.18 | -10.78 | 128.76 | 0.2400 | 666.0 | 470.4 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -5.25 | 237.02 | -10.94 | 128.46 | 0.2424 | -373.0 | -254.9 | |
| 7.36 | -58.00 | 3.77 | -58.00 | -6.15 | 236.60 | -11.36 | 130.20 | 0.2576 | -1144.9 | 999999 | |
| 1.09 | -58.00 | 0.56 | -58.00 | -6.87 | 236.49 | -11.47 | 131.99 | 0.2669 | -903.2 | 999999 | |
| 14.72 | -58.00 | 7.56 | -58.00 | -6.59 | 236.31 | -11.66 | 130.76 | 0.2661 | -1403.2 | 999999 | |
| 3.91 | -58.00 | 2.01 | -58.00 | -6.28 | 236.13 | -11.84 | 129.43 | 0.2651 | -1096.8 | 999999 | |
| 0.91 | -58.00 | 0.47 | -58.00 | -5.45 | 235.86 | -12.10 | 126.30 | 0.2600 | -1083.2 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -5.11 | 235.84 | -12.12 | 125.18 | 0.2570 | -795.0 | -691.9 | |
| 105.01 | -58.00 | 54.21 | -58.00 | -7.34 | 235.69 | -12.27 | 131.38 | 0.2822 | -1353.4 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -4.84 | 235.56 | -12.40 | 123.69 | 0.2583 | -797.0 | -561.4 | |
| 1.54 | 6.36 | 0.79 | 3.27 | -5.61 | 235.11 | -12.85 | 125.15 | 0.2720 | -1037.8 | -870.9 | |
| 6.09 | -58.00 | 3.14 | -58.00 | -6.57 | 235.05 | -12.91 | 127.84 | 0.2823 | -1045.8 | 999999 | |
| 0.00 | 5.09 | 0.00 | 2.62 | -5.83 | 235.04 | -12.92 | 125.66 | 0.2750 | -1201.0 | -886.8 | |
| 2.18 | 13.54 | 1.12 | 6.99 | -6.11 | 234.94 | -13.02 | 126.27 | 0.2792 | -1067.9 | -730.9 | |
| 0.82 | -81.00 | 0.42 | -81.00 | -6.39 | 234.58 | -13.38 | 126.35 | 0.2867 | -812.3 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -6.70 | 234.48 | -13.48 | 127.01 | 0.2912 | -921.0 | -801.1 | |
| 0.00 | 2.27 | 0.00 | 1.18 | -7.20 | 234.34 | -13.62 | 128.07 | 0.2981 | -926.0 | -773.0 | |
| 0.00 | 2.91 | 0.00 | 1.52 | -9.48 | 234.22 | -13.74 | 133.44 | 0.3241 | -854.0 | -801.8 | |
| 0.00 | 1.27 | 0.00 | 0.66 | -6.68 | 234.29 | -13.67 | 126.55 | 0.2935 | -911.0 | -725.8 | |
| 0.00 | 1.00 | 0.00 | 0.52 | -8.60 | 234.07 | -13.90 | 131.08 | 0.3164 | -801.0 | -720.1 | |
| 0.00 | 2.27 | 0.00 | 1.18 | -6.86 | 234.10 | -13.87 | 126.67 | 0.2979 | -591.0 | -589.5 | |
| 0.00 | 2.18 | 0.00 | 1.14 | -9.67 | 233.96 | -14.00 | 133.33 | 0.3294 | -601.0 | -517.3 | |
| 0.00 | 1.91 | 0.00 | 1.01 | -10.70 | 233.88 | -14.08 | 135.42 | 0.3421 | -948.0 | -728.3 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -7.80 | 233.75 | -14.21 | 128.44 | 0.3120 | -881.0 | -796.8 | |
| 0.00 | 2.18 | 0.00 | 1.14 | -8.64 | 233.52 | -14.44 | 130.09 | 0.3236 | -734.0 | -630.5 | |
| 0.00 | 2.09 | 0.00 | 1.09 | -7.84 | 233.46 | -14.50 | 127.98 | 0.3161 | -933.0 | -797.5 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -7.03 | 233.14 | -14.82 | 125.31 | 0.3125 | -707.0 | -591.8 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -7.25 | 233.07 | -14.89 | 125.75 | 0.3155 | -861.0 | -746.6 | |
| 0.00 | 0.91 | 0.00 | 0.48 | -8.12 | 233.04 | -14.93 | 127.89 | 0.3245 | -622.0 | -511.1 | |
| 0.00 | 0.82 | 0.00 | 0.43 | -7.47 | 232.90 | -15.06 | 126.01 | 0.3199 | -657.0 | -598.1 | |
| 0.00 | 3.27 | 0.00 | 1.72 | -9.44 | 232.59 | -15.37 | 130.18 | 0.3436 | -752.0 | -657.2 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -7.16 | 232.59 | -15.37 | 124.68 | 0.3211 | -797.0 | -702.1 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -6.17 | 232.56 | -15.40 | 121.99 | 0.3126 | -830.0 | -596.3 | |
| 0.00 | 1.00 | 0.00 | 0.52 | -6.77 | 231.94 | -16.02 | 122.56 | 0.3266 | -602.0 | -453.3 | |
| 0.00 | 1.27 | 0.00 | 0.67 | -8.61 | 231.45 | -16.52 | 126.29 | 0.3502 | -766.0 | -579.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
