SDO HMI 2014-07-06 15:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.17 | 0.00 | 11.10 | 11.13 | 306.39 | 60.09 | 280.94 | 0.8680 | 245.3 | 200.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 15:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.09 | 0.00 | 1.21 | 7.82 | 309.95 | 63.65 | 277.03 | 0.8963 | -360.0 | -389.2 | |
| 0.00 | 0.27 | 0.00 | 0.28 | 9.73 | 307.82 | 61.51 | 279.20 | 0.8795 | 235.0 | 222.7 | |
| 0.00 | 1.27 | 0.00 | 1.30 | 10.68 | 307.36 | 61.05 | 280.31 | 0.8759 | 163.0 | 142.4 | |
| 0.00 | 1.27 | 0.00 | 1.28 | 9.74 | 306.92 | 60.62 | 279.25 | 0.8721 | 400.0 | 333.1 | |
| 0.00 | 2.00 | 0.00 | 2.01 | 10.17 | 306.93 | 60.63 | 279.74 | 0.8723 | 318.0 | 245.0 | |
| 0.00 | 0.82 | 0.00 | 0.82 | 9.96 | 306.80 | 60.50 | 279.51 | 0.8711 | 413.0 | 383.1 | |
| 0.00 | 1.18 | 0.00 | 1.17 | 9.83 | 306.50 | 60.20 | 279.36 | 0.8685 | 579.0 | 543.2 | |
| 0.00 | 0.27 | 0.00 | 0.27 | 10.50 | 306.66 | 60.35 | 280.13 | 0.8700 | 543.0 | 536.3 | |
| 0.00 | 1.00 | 0.00 | 0.97 | 12.42 | 305.47 | 59.16 | 282.42 | 0.8606 | 561.0 | 467.8 | |
| 0.00 | 0.91 | 0.00 | 0.87 | 18.07 | 304.59 | 58.29 | 289.06 | 0.8577 | 330.0 | 320.4 | |
| 0.00 | 1.09 | 0.00 | 0.92 | 15.56 | 300.12 | 53.82 | 286.72 | 0.8141 | -484.0 | -323.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
