SDO HMI 2014-07-06 16:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 353.77 | 1883.01 | 198.53 | 1060.12 | -7.81 | 220.37 | -25.38 | 114.25 | 0.4670 | 385.9 | 83.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 16:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.63 | 0.00 | 0.87 | -6.02 | 226.22 | -19.53 | 115.85 | 0.3711 | 970.0 | 746.1 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -7.80 | 225.65 | -20.10 | 119.34 | 0.3923 | 675.0 | 584.6 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -5.12 | 225.17 | -20.58 | 112.52 | 0.3806 | 640.0 | 550.4 | |
| 0.00 | 1.73 | 0.00 | 0.92 | -4.90 | 225.12 | -20.63 | 111.93 | 0.3801 | 646.0 | 547.8 | |
| 1.09 | 13.80 | 0.59 | 7.46 | -5.24 | 223.76 | -21.99 | 111.47 | 0.4024 | 642.3 | -208.6 | |
| 0.00 | 1.00 | 0.00 | 0.54 | -5.07 | 223.03 | -22.72 | 110.46 | 0.4123 | -714.0 | -516.5 | |
| 10.53 | 1505.74 | 5.83 | 840.43 | -8.78 | 222.13 | -23.62 | 117.58 | 0.4485 | 919.1 | 218.2 | |
| 174.07 | -7.00 | 96.07 | -7.00 | -7.84 | 222.13 | -23.62 | 115.67 | 0.4423 | 1476.0 | 999999 | |
| 35.78 | -7.00 | 19.85 | -7.00 | -8.51 | 221.75 | -24.00 | 116.66 | 0.4520 | 1127.9 | 999999 | |
| 7.08 | -7.00 | 3.93 | -7.00 | -7.52 | 221.41 | -24.34 | 114.35 | 0.4504 | 988.1 | 999999 | |
| 4.63 | -7.00 | 2.58 | -7.00 | -7.91 | 220.77 | -24.98 | 114.58 | 0.4618 | 883.3 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -9.28 | 220.54 | -25.21 | 117.06 | 0.4740 | -117.0 | -107.6 | |
| 1.45 | -7.00 | 0.81 | -7.00 | -7.57 | 220.59 | -25.16 | 113.75 | 0.4623 | 770.7 | 999999 | |
| 11.53 | -7.00 | 6.45 | -7.00 | -8.07 | 220.49 | -25.26 | 114.66 | 0.4668 | 927.3 | 999999 | |
| 1.91 | -7.00 | 1.07 | -7.00 | -7.79 | 220.41 | -25.34 | 114.04 | 0.4663 | 705.1 | 999999 | |
| 2.09 | -7.00 | 1.17 | -7.00 | -7.73 | 220.24 | -25.51 | 113.79 | 0.4683 | 702.2 | 999999 | |
| 0.00 | 1.63 | 0.00 | 0.93 | -9.86 | 219.94 | -25.81 | 117.61 | 0.4860 | 568.0 | 468.2 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -9.71 | 219.92 | -25.83 | 117.30 | 0.4853 | 350.0 | 257.1 | |
| 0.00 | 9.53 | 0.00 | 5.31 | -5.82 | 220.08 | -25.67 | 109.80 | 0.4599 | 33.0 | 78.3 | |
| 7.72 | -7.00 | 4.34 | -7.00 | -8.08 | 219.91 | -25.84 | 114.20 | 0.4751 | 755.4 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -9.30 | 219.81 | -25.94 | 116.45 | 0.4840 | 404.0 | 308.2 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -5.49 | 219.75 | -26.00 | 108.89 | 0.4630 | -684.0 | -476.9 | |
| 0.00 | 1.63 | 0.00 | 0.93 | -10.69 | 219.24 | -26.51 | 118.50 | 0.5010 | -898.0 | -794.4 | |
| 1.09 | -7.00 | 0.62 | -7.00 | -8.10 | 219.43 | -26.32 | 113.84 | 0.4819 | 707.8 | 999999 | |
| 2.09 | -7.00 | 1.18 | -7.00 | -7.26 | 219.48 | -26.27 | 112.25 | 0.4762 | 844.2 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -10.64 | 219.00 | -26.75 | 118.19 | 0.5038 | -784.0 | -599.0 | |
| 0.00 | 0.82 | 0.00 | 0.46 | -5.59 | 219.37 | -26.38 | 108.84 | 0.4691 | 670.0 | 555.4 | |
| 2.91 | -7.00 | 1.64 | -7.00 | -7.79 | 219.17 | -26.58 | 113.05 | 0.4837 | 830.0 | 999999 | |
| 0.64 | 1.54 | 0.36 | 0.86 | -5.16 | 219.29 | -26.46 | 107.91 | 0.4682 | -678.3 | -466.4 | |
| 0.00 | 2.63 | 0.00 | 1.48 | -5.44 | 219.24 | -26.51 | 108.45 | 0.4703 | 399.0 | 330.7 | |
| 0.00 | 1.54 | 0.00 | 0.87 | -5.66 | 219.16 | -26.59 | 108.84 | 0.4725 | 727.0 | 619.8 | |
| 3.36 | -7.00 | 1.90 | -7.00 | -7.61 | 218.98 | -26.77 | 112.56 | 0.4854 | 813.5 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -6.03 | 218.90 | -26.85 | 109.42 | 0.4781 | -521.0 | -385.1 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -7.24 | 218.80 | -26.95 | 111.72 | 0.4859 | 491.0 | 431.8 | |
| 1.73 | -7.00 | 0.98 | -7.00 | -6.78 | 218.79 | -26.96 | 110.81 | 0.4835 | 909.1 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.82 | -6.35 | 218.65 | -27.10 | 109.87 | 0.4834 | 525.0 | 508.3 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -10.19 | 218.35 | -27.40 | 116.83 | 0.5096 | 689.0 | 524.5 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -5.98 | 218.67 | -27.08 | 109.15 | 0.4813 | 629.0 | 449.9 | |
| 0.00 | 1.45 | 0.00 | 0.84 | -11.01 | 218.16 | -27.59 | 118.12 | 0.5174 | -656.0 | -486.6 | |
| 3.00 | -7.00 | 1.70 | -7.00 | -7.47 | 218.37 | -27.38 | 111.84 | 0.4933 | 798.8 | 999999 | |
| 0.00 | 4.27 | 0.00 | 2.47 | -10.73 | 217.98 | -27.77 | 117.49 | 0.5180 | -826.0 | -649.3 | |
| 0.00 | 2.36 | 0.00 | 1.34 | -6.08 | 218.32 | -27.43 | 109.12 | 0.4868 | 225.0 | 142.8 | |
| 2.54 | -7.00 | 1.45 | -7.00 | -8.01 | 217.94 | -27.81 | 112.55 | 0.5022 | -1011.6 | 999999 | |
| 0.00 | 5.63 | 0.00 | 3.27 | -10.93 | 217.54 | -28.21 | 117.47 | 0.5252 | -425.0 | -648.0 | |
| 2.81 | -7.00 | 1.62 | -7.00 | -8.14 | 217.69 | -28.06 | 112.61 | 0.5064 | -1008.1 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.84 | -9.83 | 217.54 | -28.21 | 115.56 | 0.5182 | -617.0 | -487.1 | |
| 0.00 | 2.00 | 0.00 | 1.15 | -9.52 | 217.50 | -28.25 | 114.97 | 0.5169 | -220.0 | -217.0 | |
| 2.45 | -7.00 | 1.41 | -7.00 | -8.09 | 217.48 | -28.27 | 112.36 | 0.5090 | -951.4 | 999999 | |
| 0.00 | 1.82 | 0.00 | 1.05 | -9.40 | 217.34 | -28.41 | 114.63 | 0.5184 | -928.0 | -742.2 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -8.68 | 217.40 | -28.35 | 113.39 | 0.5134 | -567.0 | -432.6 | |
| 0.00 | 3.72 | 0.00 | 2.16 | -9.50 | 217.08 | -28.67 | 114.62 | 0.5225 | -820.0 | -709.9 | |
| 0.00 | 3.36 | 0.00 | 1.92 | -6.05 | 217.35 | -28.40 | 108.44 | 0.5007 | -779.0 | -675.2 | |
| 0.00 | 2.00 | 0.00 | 1.14 | -5.90 | 217.11 | -28.64 | 108.02 | 0.5034 | -1002.0 | -750.6 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -8.63 | 216.84 | -28.91 | 112.91 | 0.5209 | -792.0 | -703.3 | |
| 0.00 | 1.36 | 0.00 | 0.78 | -6.52 | 216.97 | -28.78 | 109.11 | 0.5083 | -900.0 | -690.7 | |
| 2.27 | 4.81 | 1.30 | 2.76 | -5.66 | 216.98 | -28.77 | 107.48 | 0.5041 | -1044.3 | -810.5 | |
| 0.00 | 1.91 | 0.00 | 1.10 | -6.34 | 216.91 | -28.84 | 108.73 | 0.5083 | -953.0 | -836.7 | |
| 0.00 | 1.09 | 0.00 | 0.64 | -11.15 | 216.49 | -29.26 | 117.01 | 0.5404 | -645.0 | -543.0 | |
| 0.00 | 4.72 | 0.00 | 2.74 | -8.55 | 216.64 | -29.11 | 112.61 | 0.5232 | -768.0 | -627.5 | |
| 3.36 | -7.00 | 1.95 | -7.00 | -8.24 | 216.63 | -29.12 | 112.04 | 0.5217 | -990.5 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.10 | -6.74 | 216.71 | -29.04 | 109.37 | 0.5131 | -834.0 | -613.3 | |
| 0.00 | 1.54 | 0.00 | 0.89 | -5.20 | 216.73 | -29.02 | 106.47 | 0.5058 | -820.0 | -597.8 | |
| 1.45 | 5.36 | 0.85 | 3.13 | -9.59 | 216.26 | -29.49 | 114.17 | 0.5341 | -879.9 | -719.7 | |
| 0.00 | 1.18 | 0.00 | 0.70 | -11.29 | 216.01 | -29.74 | 116.88 | 0.5476 | -494.0 | -442.1 | |
| 2.00 | 30.33 | 1.16 | 17.72 | -8.53 | 216.25 | -29.50 | 112.31 | 0.5284 | -931.1 | -658.9 | |
| 0.00 | 2.00 | 0.00 | 1.17 | -9.25 | 216.15 | -29.60 | 113.51 | 0.5337 | -719.0 | -688.7 | |
| 2.91 | 4.54 | 1.71 | 2.67 | -9.63 | 215.93 | -29.82 | 114.02 | 0.5387 | -850.9 | -673.3 | |
| 0.00 | 1.27 | 0.00 | 0.75 | -10.35 | 215.86 | -29.89 | 115.20 | 0.5439 | -773.0 | -585.6 | |
| 16.34 | -65.00 | 9.55 | -65.00 | -8.54 | 215.97 | -29.78 | 112.13 | 0.5324 | -893.7 | 999999 | |
| 5.54 | 32.42 | 3.23 | 18.86 | -7.94 | 215.98 | -29.77 | 111.09 | 0.5291 | -1078.6 | -575.9 | |
| 0.00 | 1.00 | 0.00 | 0.58 | -5.87 | 216.02 | -29.73 | 107.34 | 0.5188 | -863.0 | -753.0 | |
| 0.00 | 1.54 | 0.00 | 0.91 | -9.29 | 215.75 | -30.00 | 113.31 | 0.5393 | -641.0 | -522.3 | |
| 0.00 | 1.63 | 0.00 | 0.94 | -4.85 | 216.04 | -29.71 | 105.45 | 0.5143 | -585.0 | -609.9 | |
| 0.00 | 3.09 | 0.00 | 1.82 | -9.83 | 215.52 | -30.23 | 114.07 | 0.5454 | -705.0 | -562.6 | |
| 0.00 | 2.36 | 0.00 | 1.37 | -5.29 | 215.84 | -29.91 | 106.17 | 0.5189 | -647.0 | -496.8 | |
| 0.00 | 2.36 | 0.00 | 1.38 | -7.80 | 215.64 | -30.11 | 110.62 | 0.5332 | -920.0 | -719.0 | |
| 0.00 | 1.63 | 0.00 | 0.95 | -5.75 | 215.71 | -30.04 | 106.96 | 0.5228 | -830.0 | -626.4 | |
| 0.00 | 1.00 | 0.00 | 0.58 | -5.60 | 215.61 | -30.14 | 106.63 | 0.5235 | -903.0 | -676.8 | |
| 0.00 | 0.73 | 0.00 | 0.43 | -8.21 | 215.39 | -30.36 | 111.19 | 0.5386 | -572.0 | -504.5 | |
| 0.00 | 2.36 | 0.00 | 1.38 | -7.72 | 215.32 | -30.43 | 110.28 | 0.5371 | -1004.0 | -763.5 | |
| 0.00 | 2.81 | 0.00 | 1.63 | -5.05 | 215.50 | -30.25 | 105.55 | 0.5229 | -539.0 | -684.9 | |
| 0.00 | 0.73 | 0.00 | 0.43 | -9.56 | 215.08 | -30.67 | 113.32 | 0.5498 | -638.0 | -548.6 | |
| 0.00 | 2.09 | 0.00 | 1.22 | -5.86 | 215.38 | -30.37 | 106.97 | 0.5278 | -936.0 | -752.7 | |
| 0.00 | 2.00 | 0.00 | 1.16 | -5.36 | 215.38 | -30.37 | 106.07 | 0.5259 | -852.0 | -773.8 | |
| 0.00 | 1.09 | 0.00 | 0.64 | -5.71 | 215.25 | -30.50 | 106.63 | 0.5291 | -639.0 | -578.2 | |
| 0.00 | 1.63 | 0.00 | 0.95 | -5.52 | 215.23 | -30.52 | 106.28 | 0.5287 | -708.0 | -611.5 | |
| 0.00 | 1.00 | 0.00 | 0.58 | -5.77 | 215.10 | -30.65 | 106.67 | 0.5315 | -600.0 | -399.3 | |
| 0.00 | 1.63 | 0.00 | 0.96 | -6.83 | 214.96 | -30.79 | 108.49 | 0.5380 | -570.0 | -519.3 | |
| 0.00 | 1.45 | 0.00 | 0.86 | -8.70 | 214.70 | -31.05 | 111.60 | 0.5505 | -807.0 | -627.1 | |
| 8.26 | 127.94 | 4.85 | 75.41 | -6.25 | 214.79 | -30.96 | 107.36 | 0.5379 | -1187.1 | -391.6 | |
| 2.45 | -90.00 | 1.44 | -90.00 | -6.65 | 214.69 | -31.06 | 108.03 | 0.5410 | -907.3 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.13 | -7.49 | 214.59 | -31.16 | 109.45 | 0.5462 | -859.0 | -677.2 | |
| 0.00 | 0.91 | 0.00 | 0.54 | -6.93 | 214.52 | -31.23 | 108.44 | 0.5446 | -666.0 | -506.2 | |
| 0.00 | 1.82 | 0.00 | 1.08 | -8.71 | 214.34 | -31.41 | 111.40 | 0.5555 | -584.0 | -385.2 | |
| 0.00 | 1.91 | 0.00 | 1.13 | -8.15 | 214.28 | -31.47 | 110.41 | 0.5535 | -762.0 | -620.5 | |
| 0.00 | 1.45 | 0.00 | 0.85 | -4.31 | 214.51 | -31.24 | 103.73 | 0.5345 | -796.0 | -559.2 | |
| 25.79 | -90.00 | 15.21 | -90.00 | -6.38 | 214.35 | -31.40 | 107.37 | 0.5446 | -1043.9 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.69 | -4.10 | 214.48 | -31.27 | 103.32 | 0.5341 | -769.0 | -704.2 | |
| 0.00 | 0.82 | 0.00 | 0.49 | -7.91 | 214.08 | -31.67 | 109.88 | 0.5551 | -809.0 | -725.9 | |
| 1.36 | -90.00 | 0.81 | -90.00 | -6.24 | 214.03 | -31.72 | 106.96 | 0.5484 | -723.0 | 999999 | |
| 0.00 | 2.36 | 0.00 | 1.40 | -7.51 | 213.94 | -31.81 | 109.12 | 0.5553 | -689.0 | -558.6 | |
| 0.00 | 3.00 | 0.00 | 1.78 | -7.29 | 213.88 | -31.87 | 108.72 | 0.5550 | -859.0 | -748.0 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -8.48 | 213.78 | -31.97 | 110.68 | 0.5619 | -637.0 | -547.8 | |
| 0.00 | 3.72 | 0.00 | 2.19 | -4.08 | 214.01 | -31.74 | 103.10 | 0.5408 | -784.0 | -659.9 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -7.73 | 213.77 | -31.98 | 109.41 | 0.5585 | -647.0 | -564.4 | |
| 0.00 | 1.18 | 0.00 | 0.72 | -10.90 | 213.37 | -32.38 | 114.40 | 0.5797 | -574.0 | -523.1 | |
| 0.00 | 2.72 | 0.00 | 1.63 | -7.68 | 213.38 | -32.37 | 109.11 | 0.5637 | -616.0 | -498.2 | |
| 0.00 | 1.36 | 0.00 | 0.82 | -7.87 | 213.32 | -32.43 | 109.39 | 0.5653 | -603.0 | -452.1 | |
| 0.00 | 3.72 | 0.00 | 2.26 | -10.03 | 213.03 | -32.72 | 112.80 | 0.5796 | -674.0 | -626.9 | |
| 0.00 | 0.82 | 0.00 | 0.49 | -8.81 | 213.12 | -32.63 | 110.85 | 0.5723 | -552.0 | -453.0 | |
| 0.00 | 1.82 | 0.00 | 1.08 | -6.17 | 213.31 | -32.44 | 106.48 | 0.5582 | -703.0 | -582.0 | |
| 1.54 | 3.18 | 0.92 | 1.90 | -6.60 | 213.25 | -32.50 | 107.19 | 0.5609 | -739.2 | -537.1 | |
| 0.00 | 1.54 | 0.00 | 0.95 | -10.79 | 211.93 | -33.82 | 113.34 | 0.5977 | -32.0 | -98.6 | |
| 0.00 | 0.91 | 0.00 | 0.55 | -4.94 | 212.11 | -33.64 | 103.83 | 0.5705 | -730.0 | -549.1 | |
| 0.00 | 3.09 | 0.00 | 1.91 | -10.43 | 211.53 | -34.22 | 112.54 | 0.6011 | -413.0 | -452.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
