SDO HMI 2014-07-07 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.09 | 22.43 | 1.58 | 11.50 | 7.53 | 251.97 | 13.96 | 286.61 | 0.2508 | 714.3 | 603.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-07 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.75 | 7.24 | 253.80 | 15.78 | 283.92 | 0.2792 | -951.0 | -770.9 | |
| 0.00 | 2.27 | 0.00 | 1.17 | 7.74 | 252.80 | 14.78 | 286.61 | 0.2650 | 703.0 | 521.9 | |
| 0.00 | 4.09 | 0.00 | 2.10 | 8.45 | 252.32 | 14.30 | 289.74 | 0.2607 | 802.0 | 752.8 | |
| 0.91 | 2.18 | 0.47 | 1.12 | 8.00 | 252.04 | 14.03 | 288.37 | 0.2540 | 1092.4 | 904.8 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 8.43 | 252.06 | 14.04 | 289.95 | 0.2565 | 845.0 | 652.6 | |
| 2.18 | 6.81 | 1.11 | 3.48 | 7.33 | 251.67 | 13.66 | 286.19 | 0.2449 | 1071.3 | 765.0 | |
| 0.00 | 1.82 | 0.00 | 0.93 | 7.03 | 251.32 | 13.30 | 285.35 | 0.2378 | 816.0 | 652.8 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 6.12 | 251.07 | 13.05 | 281.75 | 0.2304 | 880.0 | 679.4 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 6.37 | 250.64 | 12.62 | 283.22 | 0.2240 | 953.0 | 765.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
