SDO HMI 2014-07-07 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 453.85 | 2224.06 | 229.31 | 1124.50 | -7.17 | 239.86 | 2.39 | 191.41 | 0.1981 | 35.1 | 95.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-07 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.18 | 5.45 | 1.10 | 2.75 | -5.57 | 244.00 | 6.53 | 215.62 | 0.1951 | 1127.8 | 838.9 | |
| 0.00 | 2.36 | 0.00 | 1.21 | -9.58 | 243.99 | 6.52 | 206.31 | 0.2538 | -623.0 | -389.4 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -6.16 | 243.91 | 6.44 | 213.58 | 0.2026 | 744.0 | 550.9 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -9.92 | 243.90 | 6.43 | 205.41 | 0.2584 | -770.0 | -545.0 | |
| 0.55 | 7.90 | 0.27 | 3.98 | -4.86 | 243.71 | 6.24 | 216.65 | 0.1824 | -860.2 | -540.6 | |
| 0.00 | 4.18 | 0.00 | 2.14 | -9.33 | 243.77 | 6.30 | 205.97 | 0.2483 | -20.0 | 11.5 | |
| 12.81 | 1217.17 | 6.51 | 616.82 | -7.58 | 243.56 | 6.09 | 208.64 | 0.2203 | 1202.6 | 464.4 | |
| 1.45 | -5.00 | 0.73 | -5.00 | -4.98 | 243.47 | 6.00 | 215.16 | 0.1816 | -845.8 | 999999 | |
| 7.45 | -7.00 | 3.79 | -7.00 | -8.01 | 243.44 | 5.97 | 207.25 | 0.2259 | 916.1 | 999999 | |
| 1.82 | -7.00 | 0.93 | -7.00 | -8.45 | 243.35 | 5.88 | 206.05 | 0.2319 | 899.9 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.50 | -3.41 | 243.24 | 5.77 | 219.77 | 0.1577 | 718.0 | 522.7 | |
| 7.27 | -7.00 | 3.69 | -7.00 | -7.73 | 243.19 | 5.72 | 206.84 | 0.2197 | 1002.5 | 999999 | |
| 8.00 | -7.00 | 4.05 | -7.00 | -6.96 | 242.99 | 5.52 | 207.72 | 0.2063 | 1448.2 | 999999 | |
| 3.09 | -7.00 | 1.57 | -7.00 | -8.23 | 242.98 | 5.51 | 205.01 | 0.2257 | 836.6 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -5.29 | 242.92 | 5.45 | 211.69 | 0.1807 | 823.0 | 613.1 | |
| 7.81 | -7.00 | 3.98 | -7.00 | -8.60 | 242.92 | 5.45 | 204.10 | 0.2311 | 805.4 | 999999 | |
| 0.00 | 5.82 | 0.00 | 2.92 | -4.70 | 242.85 | 5.38 | 213.17 | 0.1716 | -241.0 | -318.7 | |
| 4.45 | -7.00 | 2.25 | -7.00 | -6.61 | 242.84 | 5.37 | 207.83 | 0.1999 | 1271.2 | 999999 | |
| 4.45 | -7.00 | 2.25 | -7.00 | -6.74 | 242.78 | 5.31 | 207.28 | 0.2013 | 1347.4 | 999999 | |
| 0.00 | 1.64 | 0.00 | 0.82 | -4.39 | 242.76 | 5.29 | 213.72 | 0.1663 | -759.0 | -555.6 | |
| 55.15 | -7.00 | 27.99 | -7.00 | -7.79 | 242.76 | 5.29 | 204.95 | 0.2173 | 1361.0 | 999999 | |
| 0.27 | -7.00 | 0.14 | -7.00 | -8.48 | 242.64 | 5.17 | 203.21 | 0.2272 | 749.3 | 999999 | |
| 5.00 | -7.00 | 2.52 | -7.00 | -6.46 | 242.59 | 5.12 | 207.09 | 0.1955 | 1294.2 | 999999 | |
| 5.63 | -7.00 | 2.85 | -7.00 | -6.67 | 242.56 | 5.09 | 206.46 | 0.1986 | 1430.5 | 999999 | |
| 0.27 | -7.00 | 0.14 | -7.00 | -8.38 | 242.52 | 5.05 | 202.87 | 0.2249 | 988.3 | 999999 | |
| 71.05 | -7.00 | 35.96 | -7.00 | -7.23 | 242.35 | 4.88 | 204.33 | 0.2057 | 1639.6 | 999999 | |
| 2.18 | -7.00 | 1.11 | -7.00 | -9.66 | 242.28 | 4.81 | 199.94 | 0.2437 | 998.3 | 999999 | |
| 0.27 | -7.00 | 0.14 | -7.00 | -8.29 | 242.17 | 4.71 | 201.63 | 0.2212 | 1015.0 | 999999 | |
| 2.36 | -7.00 | 1.20 | -7.00 | -9.09 | 241.69 | 4.22 | 198.39 | 0.2313 | 815.9 | 999999 | |
| 3.73 | -7.00 | 1.88 | -7.00 | -7.22 | 241.55 | 4.08 | 200.71 | 0.2004 | 1143.0 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -9.78 | 241.45 | 3.98 | 196.54 | 0.2412 | 642.0 | 526.8 | |
| 1.09 | -7.00 | 0.55 | -7.00 | -7.04 | 241.30 | 3.83 | 199.88 | 0.1959 | 1062.5 | 999999 | |
| 1.54 | -7.00 | 0.78 | -7.00 | -7.41 | 241.24 | 3.77 | 198.97 | 0.2016 | 1225.2 | 999999 | |
| 0.00 | 2.18 | 0.00 | 1.09 | -4.29 | 241.19 | 3.72 | 205.46 | 0.1513 | 973.0 | 737.2 | |
| 1.82 | -7.00 | 0.92 | -7.00 | -7.01 | 241.15 | 3.68 | 199.19 | 0.1945 | 969.8 | 999999 | |
| 0.91 | 5.18 | 0.46 | 2.65 | -10.00 | 241.17 | 3.70 | 195.21 | 0.2435 | 981.4 | 714.1 | |
| 5.09 | -7.00 | 2.57 | -7.00 | -7.22 | 241.12 | 3.65 | 198.69 | 0.1978 | 1322.3 | 999999 | |
| 1.36 | -7.00 | 0.69 | -7.00 | -6.85 | 241.05 | 3.58 | 199.00 | 0.1914 | 1204.2 | 999999 | |
| 0.00 | 2.45 | 0.00 | 1.25 | -9.53 | 241.07 | 3.60 | 195.34 | 0.2353 | 829.0 | 633.0 | |
| 0.00 | 2.00 | 0.00 | 1.00 | -4.13 | 241.04 | 3.57 | 204.97 | 0.1478 | 984.0 | 775.5 | |
| 0.00 | 2.18 | 0.00 | 1.11 | -9.12 | 241.01 | 3.54 | 195.55 | 0.2284 | 939.0 | 710.1 | |
| 0.00 | 0.36 | 0.00 | 0.19 | -10.59 | 240.96 | 3.49 | 193.78 | 0.2524 | 638.0 | 640.5 | |
| 0.00 | 2.91 | 0.00 | 1.49 | -10.40 | 240.90 | 3.43 | 193.72 | 0.2490 | 728.0 | 690.8 | |
| 0.00 | 2.18 | 0.00 | 1.11 | -10.00 | 240.89 | 3.42 | 194.11 | 0.2423 | 753.0 | 564.2 | |
| 2.36 | -7.00 | 1.20 | -7.00 | -8.43 | 240.85 | 3.38 | 195.71 | 0.2163 | 1178.1 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.68 | -4.53 | 240.80 | 3.33 | 202.41 | 0.1524 | 1009.0 | 827.8 | |
| 1.54 | -7.00 | 0.78 | -7.00 | -7.16 | 240.78 | 3.31 | 197.15 | 0.1950 | 995.1 | 999999 | |
| 5.54 | -7.00 | 2.79 | -7.00 | -6.63 | 240.74 | 3.27 | 197.82 | 0.1862 | 1158.6 | 999999 | |
| 2.82 | -7.00 | 1.43 | -7.00 | -8.62 | 240.76 | 3.29 | 195.07 | 0.2190 | 1160.9 | 999999 | |
| 0.36 | 4.18 | 0.19 | 2.13 | -9.49 | 240.76 | 3.29 | 194.12 | 0.2334 | 833.2 | 414.0 | |
| 1.36 | -7.00 | 0.69 | -7.00 | -8.84 | 240.60 | 3.13 | 194.16 | 0.2219 | 978.8 | 999999 | |
| 0.82 | 4.54 | 0.42 | 2.32 | -10.12 | 240.49 | 3.02 | 192.40 | 0.2427 | -315.7 | -38.6 | |
| 0.45 | -7.00 | 0.23 | -7.00 | -8.00 | 240.41 | 2.94 | 194.28 | 0.2071 | -538.2 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.59 | -4.22 | 240.37 | 2.90 | 200.48 | 0.1447 | 816.0 | 653.4 | |
| 0.27 | -7.00 | 0.14 | -7.00 | -6.94 | 240.28 | 2.82 | 195.01 | 0.1890 | 1039.7 | 999999 | |
| 0.91 | -7.00 | 0.46 | -7.00 | -7.03 | 240.19 | 2.72 | 194.42 | 0.1902 | 1081.3 | 999999 | |
| 0.00 | 5.18 | 0.00 | 2.63 | -9.18 | 240.14 | 2.67 | 191.82 | 0.2258 | 742.0 | 643.1 | |
| 0.55 | -7.00 | 0.28 | -7.00 | -7.65 | 240.07 | 2.60 | 193.06 | 0.2000 | -743.3 | 999999 | |
| 0.00 | 1.82 | 0.00 | 0.92 | -6.60 | 239.98 | 2.51 | 193.87 | 0.1820 | 124.0 | 188.9 | |
| 0.55 | -7.00 | 0.28 | -7.00 | -7.06 | 239.95 | 2.48 | 193.13 | 0.1897 | 932.8 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -7.56 | 239.83 | 2.36 | 191.96 | 0.1975 | 908.0 | 572.5 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -6.69 | 239.55 | 2.08 | 191.46 | 0.1819 | 112.0 | 79.3 | |
| 0.00 | 1.54 | 0.00 | 0.77 | -4.59 | 239.51 | 2.04 | 194.10 | 0.1464 | 881.0 | 699.8 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -5.64 | 239.45 | 1.98 | 192.18 | 0.1638 | 510.0 | 321.1 | |
| 0.00 | 0.73 | 0.00 | 0.36 | -4.80 | 239.42 | 1.95 | 193.16 | 0.1496 | 970.0 | 801.9 | |
| 0.00 | 1.82 | 0.00 | 0.92 | -7.12 | 239.30 | 1.83 | 189.74 | 0.1885 | -340.0 | -188.6 | |
| 0.00 | 1.36 | 0.00 | 0.68 | -4.83 | 239.21 | 1.74 | 191.71 | 0.1493 | 799.0 | 658.0 | |
| 0.00 | 0.82 | 0.00 | 0.41 | -7.59 | 239.21 | 1.74 | 188.88 | 0.1961 | 65.0 | -18.0 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -8.99 | 239.18 | 1.72 | 187.76 | 0.2198 | -797.0 | -647.8 | |
| 0.00 | 1.00 | 0.00 | 0.50 | -5.64 | 239.11 | 1.64 | 190.16 | 0.1627 | 213.0 | 243.1 | |
| 0.00 | 2.00 | 0.00 | 1.01 | -6.28 | 239.05 | 1.58 | 189.16 | 0.1735 | 35.0 | -49.1 | |
| 0.00 | 1.27 | 0.00 | 0.64 | -7.68 | 239.03 | 1.56 | 187.88 | 0.1972 | -558.0 | -508.8 | |
| 0.73 | 810.02 | 0.37 | 408.11 | -5.79 | 238.99 | 1.52 | 189.27 | 0.1649 | -757.9 | -446.2 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -7.21 | 238.87 | 1.40 | 187.42 | 0.1889 | 615.0 | 457.5 | |
| 0.00 | 1.00 | 0.00 | 0.50 | -7.09 | 238.81 | 1.34 | 187.18 | 0.1867 | 858.0 | 699.0 | |
| 1.27 | 12.81 | 0.64 | 6.46 | -6.90 | 238.66 | 1.19 | 186.47 | 0.1832 | 982.3 | 287.1 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -8.80 | 238.60 | 1.13 | 185.20 | 0.2155 | 799.0 | 563.7 | |
| 4.91 | -73.00 | 2.46 | -73.00 | -5.73 | 238.50 | 1.03 | 186.36 | 0.1627 | -1130.9 | 999999 | |
| 0.00 | 4.54 | 0.00 | 2.29 | -6.59 | 238.41 | 0.94 | 185.30 | 0.1774 | 204.0 | 293.2 | |
| 1.54 | -73.00 | 0.78 | -73.00 | -6.07 | 238.17 | 0.70 | 184.14 | 0.1680 | -788.8 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.41 | -7.18 | 238.17 | 0.70 | 183.71 | 0.1872 | -437.0 | -237.2 | |
| 0.00 | 0.45 | 0.00 | 0.23 | -7.43 | 238.13 | 0.67 | 183.46 | 0.1914 | -346.0 | -403.0 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -6.56 | 238.10 | 0.63 | 183.59 | 0.1765 | -119.0 | -60.8 | |
| 2.91 | -73.00 | 1.46 | -73.00 | -5.69 | 237.95 | 0.48 | 182.98 | 0.1614 | -1106.9 | 999999 | |
| 0.00 | 1.73 | 0.00 | 0.87 | -7.06 | 237.92 | 0.45 | 182.43 | 0.1848 | -537.0 | -465.7 | |
| 1.54 | -73.00 | 0.78 | -73.00 | -5.69 | 237.77 | 0.30 | 181.84 | 0.1612 | -1164.1 | 999999 | |
| 2.73 | -73.00 | 1.37 | -73.00 | -5.39 | 237.68 | 0.21 | 181.32 | 0.1559 | 451.4 | 999999 | |
| 0.00 | 9.09 | 0.00 | 4.59 | -7.96 | 237.64 | 0.17 | 180.86 | 0.2002 | -576.0 | -467.0 | |
| 0.00 | 1.73 | 0.00 | 0.87 | -5.11 | 237.61 | 0.14 | 180.96 | 0.1510 | 853.0 | 694.2 | |
| 0.00 | 5.91 | 0.00 | 2.99 | -8.36 | 237.43 | -0.04 | 179.79 | 0.2071 | -114.0 | -112.1 | |
| 13.63 | -73.00 | 6.85 | -73.00 | -5.94 | 237.34 | -0.13 | 179.20 | 0.1654 | -1193.2 | 999999 | |
| 1.18 | -73.00 | 0.59 | -73.00 | -5.48 | 237.34 | -0.13 | 179.17 | 0.1574 | 462.2 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -7.58 | 237.30 | -0.16 | 179.15 | 0.1938 | -805.0 | -645.9 | |
| 20.99 | -73.00 | 10.57 | -73.00 | -6.84 | 237.21 | -0.26 | 178.59 | 0.1810 | -1112.4 | 999999 | |
| 1.82 | -73.00 | 0.91 | -73.00 | -5.76 | 237.15 | -0.32 | 178.06 | 0.1623 | -1239.3 | 999999 | |
| 0.00 | 8.09 | 0.00 | 4.09 | -7.89 | 237.15 | -0.32 | 178.40 | 0.1992 | -543.0 | -698.6 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -7.64 | 237.06 | -0.41 | 177.90 | 0.1949 | -684.0 | -573.8 | |
| 13.63 | -73.00 | 6.85 | -73.00 | -6.28 | 236.88 | -0.59 | 176.55 | 0.1716 | -1204.3 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -9.92 | 236.81 | -0.66 | 177.19 | 0.2341 | -873.0 | -696.2 | |
| 11.81 | -73.00 | 5.94 | -73.00 | -6.22 | 236.63 | -0.84 | 175.10 | 0.1708 | -1372.8 | 999999 | |
| 6.91 | -73.00 | 3.47 | -73.00 | -5.91 | 236.63 | -0.84 | 174.94 | 0.1655 | -1313.5 | 999999 | |
| 5.18 | -73.00 | 2.60 | -73.00 | -5.69 | 236.63 | -0.84 | 174.83 | 0.1618 | -618.5 | 999999 | |
| 1.18 | -73.00 | 0.59 | -73.00 | -5.20 | 236.45 | -1.02 | 173.36 | 0.1536 | -950.3 | 999999 | |
| 6.36 | -73.00 | 3.20 | -73.00 | -6.37 | 236.42 | -1.05 | 173.95 | 0.1738 | -1266.1 | 999999 | |
| 4.00 | -73.00 | 2.01 | -73.00 | -6.10 | 236.39 | -1.08 | 173.60 | 0.1691 | -1407.9 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.77 | -5.17 | 236.15 | -1.32 | 171.35 | 0.1538 | -965.0 | -804.1 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -9.20 | 236.10 | -1.37 | 173.88 | 0.2228 | 619.0 | 407.2 | |
| 31.80 | -73.00 | 16.00 | -73.00 | -6.28 | 235.99 | -1.48 | 171.43 | 0.1732 | -1305.7 | 999999 | |
| 0.91 | -73.00 | 0.46 | -73.00 | -6.62 | 235.80 | -1.67 | 170.69 | 0.1795 | -1205.2 | 999999 | |
| 0.00 | 2.36 | 0.00 | 1.18 | -4.71 | 235.78 | -1.69 | 168.42 | 0.1470 | -1051.0 | -793.6 | |
| 0.00 | 0.73 | 0.00 | 0.36 | -5.32 | 235.78 | -1.69 | 169.19 | 0.1575 | -798.0 | -561.9 | |
| 71.87 | -73.00 | 36.29 | -73.00 | -7.43 | 235.65 | -1.82 | 170.57 | 0.1936 | -1456.2 | 999999 | |
| 2.73 | -73.00 | 1.37 | -73.00 | -6.84 | 235.65 | -1.82 | 170.06 | 0.1836 | -1335.0 | 999999 | |
| 1.73 | -73.00 | 0.87 | -73.00 | -6.65 | 235.62 | -1.85 | 169.72 | 0.1806 | -1285.7 | 999999 | |
| 0.00 | 1.64 | 0.00 | 0.83 | -9.45 | 235.51 | -1.96 | 171.46 | 0.2283 | -856.0 | -614.2 | |
| 0.82 | 7.18 | 0.41 | 3.60 | -5.39 | 235.47 | -2.00 | 167.38 | 0.1596 | -1037.2 | -673.3 | |
| 3.18 | -73.00 | 1.60 | -73.00 | -6.19 | 235.34 | -2.12 | 167.69 | 0.1736 | -1127.6 | 999999 | |
| 1.91 | -73.00 | 0.96 | -73.00 | -6.10 | 235.10 | -2.37 | 166.19 | 0.1730 | -994.6 | 999999 | |
| 0.00 | 0.64 | 0.00 | 0.33 | -11.24 | 234.94 | -2.53 | 170.35 | 0.2599 | -725.0 | -589.0 | |
| 0.00 | 1.64 | 0.00 | 0.82 | -6.28 | 234.82 | -2.65 | 164.93 | 0.1773 | -819.0 | -674.4 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -11.09 | 234.75 | -2.72 | 169.55 | 0.2578 | -859.0 | -761.9 | |
| 0.00 | 1.82 | 0.00 | 0.92 | -6.47 | 234.70 | -2.77 | 164.54 | 0.1810 | -1008.0 | -818.0 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -10.93 | 234.47 | -3.00 | 168.39 | 0.2561 | -931.0 | -751.1 | |
| 0.00 | 1.27 | 0.00 | 0.64 | -6.50 | 234.45 | -3.02 | 163.29 | 0.1827 | -881.0 | -767.0 | |
| 0.00 | 2.54 | 0.00 | 1.28 | -6.75 | 234.42 | -3.05 | 163.51 | 0.1869 | -1188.0 | -940.9 | |
| 0.00 | 1.27 | 0.00 | 0.64 | -6.62 | 233.96 | -3.51 | 160.97 | 0.1873 | -737.0 | -496.3 | |
| 0.00 | 12.90 | 0.00 | 6.52 | -7.15 | 233.86 | -3.61 | 161.39 | 0.1965 | -849.0 | -826.9 | |
| 0.00 | 0.73 | 0.00 | 0.37 | -6.25 | 233.81 | -3.66 | 159.52 | 0.1822 | -773.0 | -560.0 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -10.49 | 233.70 | -3.77 | 165.07 | 0.2519 | -703.0 | -440.2 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -8.30 | 233.57 | -3.90 | 161.85 | 0.2167 | -926.0 | -743.6 | |
| 0.00 | 2.45 | 0.00 | 1.24 | -7.46 | 233.52 | -3.95 | 160.30 | 0.2034 | -806.0 | -686.3 | |
| 0.00 | 1.82 | 0.00 | 0.92 | -7.03 | 233.50 | -3.97 | 159.42 | 0.1966 | -821.0 | -705.6 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -8.43 | 233.29 | -4.17 | 160.83 | 0.2203 | -884.0 | -720.4 | |
| 0.00 | 2.18 | 0.00 | 1.11 | -8.49 | 233.02 | -4.45 | 159.75 | 0.2229 | -845.0 | -668.9 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -5.30 | 232.87 | -4.60 | 152.48 | 0.1738 | -785.0 | -558.6 | |
| 0.00 | 1.45 | 0.00 | 0.73 | -5.98 | 232.74 | -4.73 | 153.57 | 0.1852 | -960.0 | -741.2 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -7.78 | 232.50 | -4.97 | 156.35 | 0.2149 | -771.0 | -518.5 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -7.93 | 232.31 | -5.16 | 155.86 | 0.2186 | -859.0 | -657.6 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -7.97 | 231.82 | -5.65 | 153.90 | 0.2227 | -811.0 | -648.5 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -9.03 | 231.74 | -5.73 | 155.58 | 0.2396 | -940.0 | -740.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
