SDO HMI 2014-07-07 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 429.69 | 2203.87 | 217.22 | 1115.25 | -7.17 | 239.73 | 3.35 | 195.98 | 0.2019 | 3.6 | 88.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-07 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.65 | -6.13 | 244.08 | 7.71 | 218.52 | 0.2151 | 756.0 | 542.9 | |
| 0.00 | 2.09 | 0.00 | 1.06 | -5.45 | 244.04 | 7.67 | 220.45 | 0.2057 | 1158.0 | 934.8 | |
| 0.00 | 4.36 | 0.00 | 2.24 | -9.30 | 243.92 | 7.54 | 210.29 | 0.2580 | 311.0 | 321.2 | |
| 0.00 | 2.73 | 0.00 | 1.38 | -4.86 | 243.70 | 7.32 | 221.07 | 0.1941 | -677.0 | -669.1 | |
| 0.00 | 1.73 | 0.00 | 0.89 | -10.30 | 243.69 | 7.32 | 207.68 | 0.2709 | -642.0 | -580.2 | |
| 12.27 | 1155.92 | 6.24 | 586.86 | -7.55 | 243.61 | 7.23 | 213.03 | 0.2300 | 1202.0 | 498.7 | |
| 1.91 | 4.27 | 0.96 | 2.16 | -4.92 | 243.48 | 7.11 | 220.03 | 0.1925 | -959.6 | -673.7 | |
| 3.09 | -6.00 | 1.57 | -6.00 | -8.02 | 243.49 | 7.12 | 211.53 | 0.2356 | 974.1 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.59 | -3.69 | 243.41 | 7.04 | 224.25 | 0.1760 | 940.0 | 659.1 | |
| 1.82 | -6.00 | 0.92 | -6.00 | -7.55 | 243.33 | 6.95 | 212.01 | 0.2274 | 1007.6 | 999999 | |
| 1.36 | -6.00 | 0.69 | -6.00 | -6.68 | 243.07 | 6.69 | 213.18 | 0.2125 | 1230.5 | 999999 | |
| 8.00 | -6.00 | 4.08 | -6.00 | -8.67 | 242.85 | 6.48 | 207.84 | 0.2398 | 748.9 | 999999 | |
| 0.00 | 6.09 | 0.00 | 3.07 | -4.64 | 242.80 | 6.43 | 218.16 | 0.1814 | -446.0 | -364.9 | |
| 133.65 | -6.00 | 67.85 | -6.00 | -7.33 | 242.68 | 6.30 | 210.04 | 0.2184 | 1571.1 | 999999 | |
| 3.09 | -6.00 | 1.56 | -6.00 | -6.40 | 242.66 | 6.29 | 212.29 | 0.2047 | 1276.4 | 999999 | |
| 3.73 | -6.00 | 1.90 | -6.00 | -8.17 | 242.44 | 6.06 | 207.30 | 0.2290 | 1208.8 | 999999 | |
| 1.00 | -6.00 | 0.51 | -6.00 | -9.66 | 242.31 | 5.93 | 204.07 | 0.2510 | 1021.1 | 999999 | |
| 3.27 | -6.00 | 1.67 | -6.00 | -9.04 | 242.23 | 5.86 | 204.88 | 0.2408 | 925.9 | 999999 | |
| 0.27 | -6.00 | 0.14 | -6.00 | -9.16 | 242.11 | 5.74 | 204.20 | 0.2418 | 899.3 | 999999 | |
| 1.00 | -6.00 | 0.51 | -6.00 | -7.48 | 241.75 | 5.38 | 205.95 | 0.2132 | 1011.9 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -5.65 | 241.70 | 5.33 | 210.09 | 0.1851 | 195.0 | 211.8 | |
| 4.72 | -6.00 | 2.39 | -6.00 | -7.26 | 241.69 | 5.31 | 206.14 | 0.2094 | 1168.9 | 999999 | |
| 2.91 | -6.00 | 1.48 | -6.00 | -9.10 | 241.65 | 5.27 | 202.55 | 0.2377 | 813.7 | 999999 | |
| 0.00 | 2.09 | 0.00 | 1.07 | -9.81 | 241.50 | 5.13 | 200.89 | 0.2481 | 636.0 | 496.6 | |
| 1.45 | -6.00 | 0.74 | -6.00 | -7.47 | 241.44 | 5.07 | 204.65 | 0.2109 | 1080.8 | 999999 | |
| 4.09 | -6.00 | 2.07 | -6.00 | -7.07 | 241.31 | 4.94 | 204.92 | 0.2037 | 1172.4 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -9.62 | 241.34 | 4.97 | 200.57 | 0.2441 | 791.0 | 585.7 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -9.19 | 241.31 | 4.93 | 201.09 | 0.2370 | 275.0 | 318.3 | |
| 5.82 | -6.00 | 2.94 | -6.00 | -7.29 | 241.19 | 4.82 | 203.94 | 0.2063 | 1357.4 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -4.26 | 241.17 | 4.80 | 211.60 | 0.1599 | 964.0 | 814.0 | |
| 0.00 | 1.82 | 0.00 | 0.91 | -5.43 | 241.18 | 4.80 | 208.16 | 0.1775 | -788.0 | -502.6 | |
| 1.82 | 4.18 | 0.93 | 2.14 | -10.06 | 241.13 | 4.76 | 199.16 | 0.2499 | 898.3 | 636.4 | |
| 0.00 | 2.00 | 0.00 | 1.02 | -9.56 | 241.03 | 4.66 | 199.47 | 0.2413 | 755.0 | 609.9 | |
| 1.73 | -6.00 | 0.87 | -6.00 | -6.85 | 240.97 | 4.60 | 203.83 | 0.1979 | 1206.9 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -9.09 | 241.00 | 4.62 | 200.01 | 0.2336 | 969.0 | 824.3 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -10.28 | 240.95 | 4.57 | 198.20 | 0.2524 | 669.0 | 519.8 | |
| 2.82 | -6.00 | 1.43 | -6.00 | -8.44 | 240.90 | 4.52 | 200.61 | 0.2225 | 1152.6 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.59 | -4.50 | 240.83 | 4.46 | 209.01 | 0.1606 | 1002.0 | 836.9 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -10.09 | 240.85 | 4.48 | 198.08 | 0.2489 | 839.0 | 675.4 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -10.47 | 240.83 | 4.45 | 197.51 | 0.2548 | 717.0 | 537.5 | |
| 2.00 | -6.00 | 1.01 | -6.00 | -6.63 | 240.76 | 4.38 | 203.27 | 0.1930 | 1098.2 | 999999 | |
| 5.45 | -6.00 | 2.77 | -6.00 | -8.62 | 240.74 | 4.37 | 199.68 | 0.2246 | 1056.3 | 999999 | |
| 0.64 | 2.73 | 0.32 | 1.39 | -9.53 | 240.72 | 4.35 | 198.31 | 0.2391 | 715.6 | 487.0 | |
| 0.73 | -6.00 | 0.37 | -6.00 | -7.97 | 240.58 | 4.21 | 200.03 | 0.2131 | -537.0 | 999999 | |
| 0.00 | 3.73 | 0.00 | 1.90 | -10.12 | 240.48 | 4.11 | 196.63 | 0.2475 | -112.0 | -146.5 | |
| 3.00 | -6.00 | 1.52 | -6.00 | -7.13 | 240.42 | 4.05 | 200.73 | 0.1987 | 1151.1 | 999999 | |
| 0.55 | -6.00 | 0.28 | -6.00 | -8.06 | 240.43 | 4.05 | 199.21 | 0.2137 | -677.7 | 999999 | |
| 0.55 | 4.63 | 0.28 | 2.36 | -9.18 | 240.19 | 3.82 | 196.63 | 0.2307 | 847.7 | 676.7 | |
| 0.00 | 5.18 | 0.00 | 2.61 | -6.75 | 240.11 | 3.74 | 199.92 | 0.1908 | 864.0 | 452.5 | |
| 0.00 | 3.91 | 0.00 | 1.98 | -7.81 | 240.09 | 3.71 | 198.07 | 0.2078 | -105.0 | -314.5 | |
| 2.00 | -6.00 | 1.01 | -6.00 | -7.09 | 239.96 | 3.58 | 198.59 | 0.1955 | 1006.6 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -7.65 | 239.72 | 3.34 | 196.59 | 0.2033 | 764.0 | 551.6 | |
| 0.00 | 1.00 | 0.00 | 0.50 | -5.55 | 239.64 | 3.27 | 199.78 | 0.1685 | 537.0 | 391.6 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -4.56 | 239.55 | 3.17 | 201.40 | 0.1519 | 889.0 | 617.7 | |
| 0.00 | 2.54 | 0.00 | 1.28 | -4.74 | 239.40 | 3.02 | 200.04 | 0.1540 | 938.0 | 702.6 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -7.77 | 239.07 | 2.70 | 193.37 | 0.2025 | -865.0 | -604.8 | |
| 0.00 | 1.73 | 0.00 | 0.87 | -7.55 | 239.04 | 2.66 | 193.47 | 0.1987 | 796.0 | 456.7 | |
| 0.36 | 18.81 | 0.18 | 9.46 | -5.88 | 238.94 | 2.57 | 195.22 | 0.1704 | -711.0 | -203.1 | |
| 0.00 | 20.26 | 0.00 | 10.21 | -6.84 | 238.51 | 2.14 | 191.62 | 0.1848 | 470.0 | 332.6 | |
| 6.54 | 839.00 | 3.29 | 422.64 | -5.63 | 238.39 | 2.01 | 192.37 | 0.1639 | -1169.1 | -450.9 | |
| 0.00 | 6.00 | 0.00 | 3.03 | -7.43 | 238.18 | 1.80 | 189.31 | 0.1937 | -98.0 | -94.0 | |
| 1.00 | -60.00 | 0.50 | -60.00 | -5.72 | 238.08 | 1.71 | 190.43 | 0.1644 | -1110.1 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -8.39 | 238.09 | 1.71 | 188.14 | 0.2098 | -626.0 | -412.9 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -7.24 | 238.02 | 1.65 | 188.67 | 0.1901 | -748.0 | -598.6 | |
| 1.54 | -60.00 | 0.78 | -60.00 | -5.91 | 237.96 | 1.58 | 189.51 | 0.1672 | -955.2 | 999999 | |
| 6.54 | -60.00 | 3.28 | -60.00 | -5.63 | 237.90 | 1.52 | 189.42 | 0.1623 | -1209.9 | 999999 | |
| 3.27 | -60.00 | 1.64 | -60.00 | -5.38 | 237.68 | 1.31 | 188.33 | 0.1575 | 473.6 | 999999 | |
| 0.00 | 11.54 | 0.00 | 5.84 | -8.08 | 237.69 | 1.31 | 186.42 | 0.2036 | -110.0 | -300.4 | |
| 0.00 | 1.00 | 0.00 | 0.50 | -7.55 | 237.65 | 1.28 | 186.57 | 0.1945 | -383.0 | -295.4 | |
| 1.27 | -60.00 | 0.64 | -60.00 | -7.15 | 237.53 | 1.16 | 186.16 | 0.1874 | -929.9 | 999999 | |
| 0.36 | -60.00 | 0.18 | -60.00 | -5.41 | 237.38 | 1.00 | 186.38 | 0.1573 | 851.5 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -8.02 | 237.38 | 1.00 | 184.95 | 0.2020 | -627.0 | -507.8 | |
| 11.45 | -60.00 | 5.75 | -60.00 | -5.97 | 237.28 | 0.91 | 185.46 | 0.1667 | -1211.3 | 999999 | |
| 1.54 | -60.00 | 0.78 | -60.00 | -5.75 | 237.16 | 0.79 | 184.84 | 0.1628 | -1130.7 | 999999 | |
| 1.09 | 6.72 | 0.55 | 3.40 | -7.95 | 237.10 | 0.73 | 183.61 | 0.2006 | -840.9 | -723.7 | |
| 22.44 | -60.00 | 11.30 | -60.00 | -6.74 | 237.04 | 0.67 | 183.69 | 0.1797 | -1135.7 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -9.95 | 236.92 | 0.54 | 182.29 | 0.2346 | -823.0 | -601.9 | |
| 10.45 | -60.00 | 5.25 | -60.00 | -6.18 | 236.89 | 0.51 | 183.01 | 0.1700 | -1224.7 | 999999 | |
| 1.73 | -60.00 | 0.87 | -60.00 | -7.27 | 236.82 | 0.45 | 182.38 | 0.1886 | -835.9 | 999999 | |
| 29.53 | -60.00 | 14.84 | -60.00 | -6.18 | 236.55 | 0.17 | 181.03 | 0.1697 | -1357.0 | 999999 | |
| 2.00 | 9.27 | 1.00 | 4.65 | -5.20 | 236.52 | 0.14 | 180.95 | 0.1526 | -942.6 | -607.8 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -10.73 | 236.30 | -0.08 | 179.69 | 0.2477 | -737.0 | -596.5 | |
| 0.00 | 2.91 | 0.00 | 1.49 | -10.83 | 235.99 | -0.39 | 178.47 | 0.2494 | -895.0 | -682.1 | |
| 32.53 | -60.00 | 16.36 | -60.00 | -6.31 | 235.97 | -0.41 | 177.63 | 0.1720 | -1334.2 | 999999 | |
| 2.45 | -60.00 | 1.23 | -60.00 | -5.81 | 235.88 | -0.50 | 176.95 | 0.1635 | -1040.4 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.68 | -4.67 | 235.88 | -0.50 | 176.54 | 0.1438 | -936.0 | -728.7 | |
| 1.82 | -60.00 | 0.91 | -60.00 | -6.65 | 235.84 | -0.53 | 177.02 | 0.1779 | -1125.0 | 999999 | |
| 0.00 | 2.18 | 0.00 | 1.09 | -5.44 | 235.85 | -0.53 | 176.63 | 0.1571 | -733.0 | -626.8 | |
| 4.45 | -60.00 | 2.25 | -60.00 | -7.21 | 235.75 | -0.62 | 176.68 | 0.1876 | -1451.0 | 999999 | |
| 52.06 | -60.00 | 26.29 | -60.00 | -7.52 | 235.69 | -0.69 | 176.45 | 0.1930 | -1458.6 | 999999 | |
| 1.54 | -60.00 | 0.78 | -60.00 | -6.86 | 235.66 | -0.72 | 176.07 | 0.1819 | -1451.2 | 999999 | |
| 6.00 | -60.00 | 3.02 | -60.00 | -7.08 | 235.60 | -0.78 | 175.82 | 0.1857 | -1574.8 | 999999 | |
| 1.91 | -60.00 | 0.96 | -60.00 | -6.68 | 235.60 | -0.78 | 175.66 | 0.1787 | -1220.0 | 999999 | |
| 1.00 | -60.00 | 0.50 | -60.00 | -5.44 | 235.45 | -0.93 | 174.11 | 0.1577 | -972.4 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -9.60 | 235.43 | -0.94 | 175.93 | 0.2290 | -733.0 | -507.7 | |
| 7.81 | -60.00 | 3.94 | -60.00 | -7.11 | 235.35 | -1.02 | 174.52 | 0.1866 | -1377.9 | 999999 | |
| 2.27 | -60.00 | 1.14 | -60.00 | -6.21 | 235.35 | -1.02 | 174.03 | 0.1711 | -1110.0 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -11.24 | 234.99 | -1.38 | 174.70 | 0.2573 | -658.0 | -610.3 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -11.05 | 234.84 | -1.54 | 174.03 | 0.2544 | -859.0 | -695.4 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -10.86 | 234.81 | -1.57 | 173.84 | 0.2513 | -965.0 | -768.3 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -6.25 | 234.77 | -1.60 | 170.71 | 0.1730 | -889.0 | -725.2 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -6.43 | 234.74 | -1.64 | 170.70 | 0.1763 | -1060.0 | -919.9 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -10.95 | 234.56 | -1.82 | 172.91 | 0.2533 | -810.0 | -667.2 | |
| 0.00 | 2.27 | 0.00 | 1.14 | -6.74 | 234.43 | -1.94 | 169.31 | 0.1824 | -1120.0 | -950.7 | |
| 0.00 | 12.99 | 0.00 | 6.56 | -7.11 | 233.88 | -2.50 | 166.83 | 0.1907 | -894.0 | -806.9 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -8.92 | 233.65 | -2.73 | 167.70 | 0.2218 | -829.0 | -572.6 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -8.42 | 233.37 | -3.00 | 165.96 | 0.2145 | -866.0 | -726.1 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -9.32 | 233.36 | -3.01 | 166.90 | 0.2296 | -900.0 | -679.8 | |
| 0.00 | 1.45 | 0.00 | 0.73 | -6.87 | 233.26 | -3.11 | 163.38 | 0.1893 | -910.0 | -718.1 | |
| 0.00 | 3.73 | 0.00 | 1.89 | -8.51 | 233.12 | -3.25 | 164.97 | 0.2171 | -817.0 | -619.0 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -9.39 | 233.05 | -3.32 | 165.67 | 0.2319 | -575.0 | -525.1 | |
| 0.00 | 2.27 | 0.00 | 1.15 | -6.87 | 232.92 | -3.45 | 161.69 | 0.1911 | -838.0 | -756.5 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -7.68 | 232.12 | -4.26 | 159.26 | 0.2088 | -974.0 | -784.5 | |
| 0.00 | 7.72 | 0.00 | 3.92 | -8.05 | 232.05 | -4.32 | 159.60 | 0.2152 | -499.0 | -533.0 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -8.92 | 231.76 | -4.61 | 159.77 | 0.2309 | -936.0 | -761.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
