SDO HMI 2014-07-07 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.61 | 153.21 | 18.08 | 88.01 | 6.60 | 203.82 | -30.36 | 82.98 | 0.5078 | -755.1 | -387.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-07 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.18 | 0.00 | 0.65 | 6.20 | 207.47 | -26.71 | 83.25 | 0.4518 | -797.0 | -643.9 | |
| 7.45 | 10.08 | 4.23 | 5.73 | 7.17 | 204.97 | -29.20 | 81.65 | 0.4912 | -967.4 | -660.6 | |
| 24.16 | 131.52 | 13.85 | 75.35 | 6.50 | 204.03 | -30.15 | 83.16 | 0.5046 | -1203.2 | -425.0 | |
| 0.00 | 2.63 | 0.00 | 1.52 | 8.57 | 203.48 | -30.70 | 79.22 | 0.5159 | -701.0 | -642.9 | |
| 0.00 | 1.09 | 0.00 | 0.63 | 7.67 | 202.98 | -31.20 | 81.07 | 0.5217 | -703.0 | -486.6 | |
| 0.00 | 0.73 | 0.00 | 0.42 | 8.27 | 202.86 | -31.32 | 79.93 | 0.5245 | -597.0 | -510.5 | |
| 0.00 | 0.54 | 0.00 | 0.33 | 6.11 | 200.18 | -34.00 | 84.33 | 0.5609 | 619.0 | 564.5 | |
| 0.00 | 1.27 | 0.00 | 0.78 | 6.16 | 198.15 | -36.03 | 84.40 | 0.5898 | 717.0 | 589.4 | |
| 0.00 | 1.27 | 0.00 | 0.79 | 7.79 | 197.50 | -36.67 | 81.72 | 0.6001 | 787.0 | 668.5 | |
| 0.00 | 1.54 | 0.00 | 0.96 | 5.90 | 196.71 | -37.47 | 84.93 | 0.6097 | 505.0 | 499.4 | |
| 0.00 | 1.36 | 0.00 | 0.85 | 7.14 | 196.56 | -37.61 | 82.90 | 0.6125 | 480.0 | 339.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
