SDO HMI 2014-07-07 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 312.05 | 1852.74 | 160.76 | 956.05 | -7.88 | 220.56 | -10.84 | 137.26 | 0.2745 | 489.6 | 199.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-07 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 5.72 | 0.00 | 2.88 | -4.91 | 225.85 | -5.55 | 146.75 | 0.1766 | 886.0 | 766.1 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -10.84 | 222.86 | -8.55 | 149.52 | 0.2890 | -958.0 | -772.4 | |
| 200.37 | 1554.50 | 102.69 | 799.48 | -8.00 | 222.12 | -9.28 | 141.33 | 0.2568 | 1712.8 | 363.8 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -3.06 | 222.21 | -9.20 | 125.65 | 0.1973 | -825.0 | -579.2 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -10.60 | 220.95 | -10.46 | 143.79 | 0.3034 | 824.0 | 587.1 | |
| 13.44 | -3.00 | 6.91 | -3.00 | -8.01 | 220.93 | -10.47 | 137.96 | 0.2699 | 1114.9 | 999999 | |
| 4.90 | -3.00 | 2.52 | -3.00 | -7.54 | 220.85 | -10.55 | 136.54 | 0.2651 | 939.7 | 999999 | |
| 1.45 | -3.00 | 0.75 | -3.00 | -8.32 | 220.80 | -10.60 | 138.37 | 0.2753 | 715.2 | 999999 | |
| 1.91 | -3.00 | 0.98 | -3.00 | -8.07 | 220.71 | -10.69 | 137.53 | 0.2732 | 1048.5 | 999999 | |
| 2.18 | -3.00 | 1.12 | -3.00 | -8.45 | 220.64 | -10.76 | 138.25 | 0.2787 | 550.0 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -5.90 | 220.67 | -10.73 | 131.42 | 0.2481 | -626.0 | -416.5 | |
| 2.36 | -3.00 | 1.21 | -3.00 | -7.70 | 220.60 | -10.81 | 136.27 | 0.2700 | 1011.0 | 999999 | |
| 1.09 | -3.00 | 0.56 | -3.00 | -8.82 | 220.50 | -10.90 | 138.79 | 0.2849 | 542.9 | 999999 | |
| 0.00 | 2.09 | 0.00 | 1.07 | -6.46 | 220.44 | -10.96 | 132.47 | 0.2573 | -46.0 | 119.1 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -6.40 | 220.19 | -11.21 | 131.66 | 0.2597 | 882.0 | 644.3 | |
| 0.00 | 2.00 | 0.00 | 1.04 | -10.33 | 219.92 | -11.49 | 140.64 | 0.3103 | -1005.0 | -789.0 | |
| 3.00 | -3.00 | 1.56 | -3.00 | -9.52 | 219.91 | -11.49 | 138.88 | 0.3001 | 810.7 | 999999 | |
| 0.73 | 3.45 | 0.38 | 1.80 | -10.93 | 219.80 | -11.61 | 141.57 | 0.3192 | -990.0 | -776.9 | |
| 0.00 | 3.90 | 0.00 | 2.04 | -10.55 | 219.59 | -11.81 | 140.32 | 0.3166 | -1139.0 | -809.7 | |
| 8.35 | -3.00 | 4.31 | -3.00 | -7.65 | 219.63 | -11.78 | 133.68 | 0.2809 | 1106.9 | 999999 | |
| 1.72 | -3.00 | 0.89 | -3.00 | -8.09 | 219.62 | -11.79 | 134.76 | 0.2861 | 1079.5 | 999999 | |
| 3.00 | -3.00 | 1.55 | -3.00 | -7.90 | 219.21 | -12.19 | 133.34 | 0.2889 | 953.8 | 999999 | |
| 0.00 | 0.73 | 0.00 | 0.38 | -11.00 | 218.84 | -12.56 | 139.51 | 0.3302 | -773.0 | -624.5 | |
| 0.64 | -3.00 | 0.33 | -3.00 | -7.44 | 218.79 | -12.62 | 131.17 | 0.2890 | 1109.3 | 999999 | |
| 1.72 | -3.00 | 0.89 | -3.00 | -7.01 | 218.70 | -12.70 | 129.83 | 0.2854 | 1192.0 | 999999 | |
| 2.09 | -3.00 | 1.08 | -3.00 | -6.95 | 218.52 | -12.89 | 129.25 | 0.2872 | 1009.8 | 999999 | |
| 4.90 | -3.00 | 2.54 | -3.00 | -7.20 | 218.48 | -12.93 | 129.84 | 0.2903 | 999.5 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.53 | -10.73 | 217.87 | -13.54 | 136.84 | 0.3377 | -676.0 | -512.9 | |
| 0.00 | 2.09 | 0.00 | 1.09 | -9.45 | 217.86 | -13.55 | 134.04 | 0.3228 | -831.0 | -734.9 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -5.78 | 217.92 | -13.49 | 124.71 | 0.2835 | -772.0 | -504.0 | |
| 5.72 | -3.00 | 2.98 | -3.00 | -7.71 | 217.61 | -13.80 | 129.33 | 0.3069 | -979.2 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -9.52 | 217.54 | -13.87 | 133.53 | 0.3274 | -836.0 | -664.8 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -5.82 | 217.63 | -13.77 | 124.25 | 0.2877 | -1004.0 | -843.1 | |
| 1.00 | 7.26 | 0.53 | 3.82 | -10.14 | 217.45 | -13.96 | 134.72 | 0.3356 | -1093.5 | -712.8 | |
| 0.00 | 1.00 | 0.00 | 0.52 | -6.03 | 217.60 | -13.81 | 124.80 | 0.2903 | -803.0 | -602.0 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -9.24 | 217.46 | -13.95 | 132.72 | 0.3253 | -835.0 | -654.6 | |
| 3.99 | -3.00 | 2.07 | -3.00 | -6.78 | 217.51 | -13.89 | 126.70 | 0.2987 | 242.8 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.67 | -10.58 | 217.36 | -14.04 | 135.48 | 0.3417 | -873.0 | -681.6 | |
| 3.63 | -3.00 | 1.88 | -3.00 | -6.41 | 217.46 | -13.94 | 125.58 | 0.2957 | -759.2 | 999999 | |
| 0.00 | 2.54 | 0.00 | 1.34 | -10.93 | 217.25 | -14.16 | 135.98 | 0.3470 | -777.0 | -690.6 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -8.74 | 217.35 | -14.06 | 131.34 | 0.3211 | -646.0 | -486.4 | |
| 0.00 | 1.09 | 0.00 | 0.57 | -10.34 | 217.18 | -14.22 | 134.60 | 0.3409 | -739.0 | -589.8 | |
| 0.00 | 2.18 | 0.00 | 1.15 | -9.83 | 217.17 | -14.23 | 133.49 | 0.3353 | -975.0 | -733.0 | |
| 0.00 | 4.90 | 0.00 | 2.57 | -9.49 | 217.19 | -14.22 | 132.76 | 0.3313 | -1021.0 | -768.1 | |
| 0.00 | 1.72 | 0.00 | 0.90 | -7.90 | 217.13 | -14.28 | 128.86 | 0.3151 | -629.0 | -537.1 | |
| 0.00 | 1.45 | 0.00 | 0.77 | -10.87 | 216.93 | -14.47 | 135.22 | 0.3500 | -747.0 | -568.2 | |
| 0.00 | 3.00 | 0.00 | 1.55 | -5.95 | 217.13 | -14.28 | 123.66 | 0.2960 | -861.0 | -697.6 | |
| 1.27 | 9.44 | 0.66 | 4.92 | -7.56 | 217.04 | -14.36 | 127.84 | 0.3127 | -1033.9 | -801.2 | |
| 0.00 | 1.36 | 0.00 | 0.72 | -9.99 | 216.94 | -14.46 | 133.39 | 0.3399 | -804.0 | -691.1 | |
| 0.00 | 1.09 | 0.00 | 0.57 | -9.81 | 216.95 | -14.45 | 132.99 | 0.3377 | -925.0 | -668.9 | |
| 1.82 | -48.00 | 0.95 | -48.00 | -7.37 | 217.02 | -14.39 | 127.31 | 0.3112 | -1104.3 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.00 | -7.87 | 217.00 | -14.40 | 128.54 | 0.3164 | -933.0 | -799.4 | |
| 0.00 | 1.82 | 0.00 | 0.96 | -9.65 | 216.83 | -14.57 | 132.41 | 0.3374 | -1072.0 | -909.2 | |
| 0.00 | 4.72 | 0.00 | 2.47 | -8.62 | 216.75 | -14.66 | 129.89 | 0.3274 | -487.0 | -748.8 | |
| 0.00 | 1.36 | 0.00 | 0.72 | -10.06 | 216.65 | -14.75 | 132.97 | 0.3441 | -713.0 | -665.2 | |
| 0.00 | 1.82 | 0.00 | 0.96 | -9.66 | 216.58 | -14.83 | 131.93 | 0.3406 | -1045.0 | -796.2 | |
| 0.00 | 2.18 | 0.00 | 1.13 | -6.36 | 216.67 | -14.73 | 123.96 | 0.3061 | -906.0 | -758.8 | |
| 3.09 | 26.78 | 1.62 | 14.03 | -8.13 | 216.58 | -14.83 | 128.37 | 0.3245 | -1261.9 | -866.8 | |
| 2.18 | -58.00 | 1.14 | -58.00 | -7.97 | 216.58 | -14.82 | 127.99 | 0.3229 | -1165.5 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -7.38 | 216.61 | -14.80 | 126.55 | 0.3167 | -1033.0 | -948.9 | |
| 2.27 | -58.00 | 1.19 | -58.00 | -8.35 | 216.50 | -14.90 | 128.76 | 0.3277 | -1055.2 | 999999 | |
| 0.00 | 0.73 | 0.00 | 0.38 | -9.22 | 216.37 | -15.03 | 130.56 | 0.3385 | -751.0 | -612.9 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -7.29 | 216.42 | -14.99 | 125.97 | 0.3183 | -924.0 | -743.2 | |
| 3.90 | -58.00 | 2.05 | -58.00 | -8.10 | 216.29 | -15.11 | 127.77 | 0.3280 | -1012.2 | 999999 | |
| 0.00 | 2.72 | 0.00 | 1.42 | -6.64 | 216.34 | -15.06 | 124.14 | 0.3132 | -1114.0 | -932.2 | |
| 0.00 | 2.54 | 0.00 | 1.34 | -9.66 | 216.00 | -15.41 | 130.87 | 0.3478 | -960.0 | -754.4 | |
| 0.00 | 1.54 | 0.00 | 0.80 | -5.93 | 216.14 | -15.26 | 121.87 | 0.3096 | -984.0 | -758.1 | |
| 1.00 | 3.27 | 0.52 | 1.71 | -6.58 | 216.09 | -15.31 | 123.55 | 0.3161 | -1101.5 | -870.4 | |
| 0.00 | 3.45 | 0.00 | 1.81 | -8.38 | 215.99 | -15.41 | 127.92 | 0.3347 | -1058.0 | -792.6 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -9.85 | 215.93 | -15.48 | 131.15 | 0.3507 | -623.0 | -508.7 | |
| 0.00 | 7.90 | 0.00 | 4.17 | -9.45 | 215.91 | -15.49 | 130.23 | 0.3466 | -1094.0 | -918.3 | |
| 0.00 | 1.00 | 0.00 | 0.53 | -9.73 | 215.77 | -15.63 | 130.60 | 0.3513 | -641.0 | -458.1 | |
| 0.00 | 1.18 | 0.00 | 0.63 | -9.83 | 215.44 | -15.96 | 130.24 | 0.3564 | -632.0 | -544.8 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -5.88 | 215.45 | -15.96 | 120.59 | 0.3191 | -829.0 | -833.9 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -8.49 | 215.32 | -16.09 | 126.98 | 0.3446 | -952.0 | -703.9 | |
| 0.00 | 0.82 | 0.00 | 0.43 | -9.64 | 215.26 | -16.14 | 129.51 | 0.3568 | -829.0 | -667.1 | |
| 0.00 | 3.54 | 0.00 | 1.86 | -7.15 | 215.34 | -16.07 | 123.75 | 0.3317 | -989.0 | -854.9 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -8.99 | 215.26 | -16.14 | 128.04 | 0.3502 | -860.0 | -694.2 | |
| 0.00 | 3.00 | 0.00 | 1.57 | -5.79 | 215.26 | -16.15 | 120.06 | 0.3211 | -1049.0 | -812.0 | |
| 0.00 | 3.09 | 0.00 | 1.63 | -9.02 | 215.07 | -16.34 | 127.79 | 0.3531 | -764.0 | -599.6 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -8.84 | 215.01 | -16.39 | 127.27 | 0.3520 | -759.0 | -664.6 | |
| 0.00 | 4.09 | 0.00 | 2.15 | -7.50 | 215.01 | -16.40 | 124.08 | 0.3394 | -815.0 | -784.2 | |
| 0.64 | 3.63 | 0.34 | 1.92 | -8.00 | 214.89 | -16.52 | 125.10 | 0.3456 | -1091.4 | -928.9 | |
| 0.00 | 2.45 | 0.00 | 1.29 | -8.28 | 214.88 | -16.53 | 125.75 | 0.3484 | -927.0 | -777.0 | |
| 27.69 | 103.50 | 14.56 | 54.43 | -6.45 | 214.56 | -16.84 | 120.75 | 0.3364 | -1224.9 | -506.9 | |
| 0.00 | 0.54 | 0.00 | 0.29 | -8.38 | 214.45 | -16.95 | 125.30 | 0.3550 | -709.0 | -628.7 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -8.07 | 214.37 | -17.03 | 124.44 | 0.3532 | -814.0 | -675.3 | |
| 0.00 | 2.00 | 0.00 | 1.06 | -8.47 | 214.29 | -17.12 | 125.26 | 0.3581 | -673.0 | -596.7 | |
| 0.00 | 2.27 | 0.00 | 1.19 | -4.73 | 214.39 | -17.01 | 115.88 | 0.3255 | -1059.0 | -813.6 | |
| 0.00 | 1.27 | 0.00 | 0.67 | -4.58 | 214.27 | -17.13 | 115.30 | 0.3262 | -961.0 | -763.7 | |
| 0.00 | 3.27 | 0.00 | 1.73 | -7.67 | 214.07 | -17.34 | 123.03 | 0.3538 | -860.0 | -696.0 | |
| 0.00 | 1.63 | 0.00 | 0.87 | -10.20 | 213.94 | -17.47 | 128.51 | 0.3791 | -696.0 | -500.2 | |
| 0.00 | 2.36 | 0.00 | 1.25 | -7.36 | 213.89 | -17.52 | 122.02 | 0.3536 | -956.0 | -603.7 | |
| 0.00 | 1.54 | 0.00 | 0.82 | -8.24 | 213.75 | -17.65 | 123.88 | 0.3631 | -798.0 | -660.2 | |
| 0.00 | 1.54 | 0.00 | 0.82 | -7.87 | 213.51 | -17.90 | 122.67 | 0.3631 | -761.0 | -648.6 | |
| 0.00 | 1.27 | 0.00 | 0.68 | -8.18 | 213.49 | -17.91 | 123.37 | 0.3661 | -440.0 | -382.0 | |
| 0.00 | 2.00 | 0.00 | 1.07 | -9.84 | 213.31 | -18.10 | 126.77 | 0.3837 | -733.0 | -558.7 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -10.24 | 213.28 | -18.12 | 127.59 | 0.3879 | -864.0 | -766.2 | |
| 0.00 | 2.91 | 0.00 | 1.56 | -10.13 | 212.80 | -18.60 | 126.63 | 0.3930 | -937.0 | -733.8 | |
| 0.00 | 0.64 | 0.00 | 0.34 | -10.22 | 212.66 | -18.74 | 126.63 | 0.3956 | -705.0 | -648.1 | |
| 0.00 | 2.18 | 0.00 | 1.17 | -7.98 | 212.30 | -19.10 | 121.26 | 0.3808 | -814.0 | -660.0 | |
| 0.00 | 0.91 | 0.00 | 0.48 | -6.28 | 212.25 | -19.16 | 117.18 | 0.3682 | -725.0 | -585.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
