SDO HMI 2014-07-08 14:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.33 | 163.65 | 14.09 | 84.45 | 6.54 | 204.38 | -16.01 | 79.11 | 0.2806 | -772.9 | -424.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-08 14:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.63 | 0.00 | 0.84 | 10.44 | 206.06 | -14.33 | 63.74 | 0.2726 | -908.0 | -677.7 | |
| 0.00 | 1.73 | 0.00 | 0.88 | 6.43 | 206.02 | -14.37 | 78.45 | 0.2529 | -883.0 | -685.8 | |
| 0.00 | 1.63 | 0.00 | 0.84 | 10.92 | 205.75 | -14.64 | 62.61 | 0.2807 | -947.0 | -680.1 | |
| 2.54 | 4.27 | 1.31 | 2.19 | 7.12 | 205.55 | -14.84 | 76.15 | 0.2628 | -1061.3 | -896.8 | |
| 0.00 | 1.45 | 0.00 | 0.75 | 11.43 | 204.66 | -15.73 | 62.61 | 0.3005 | -867.0 | -592.1 | |
| 24.79 | 144.04 | 12.78 | 74.23 | 6.32 | 204.56 | -15.83 | 79.79 | 0.2767 | -1337.6 | -455.2 | |
| 0.00 | 1.73 | 0.00 | 0.89 | 8.94 | 204.43 | -15.96 | 70.80 | 0.2889 | -807.0 | -657.0 | |
| 0.00 | 1.36 | 0.00 | 0.71 | 5.61 | 202.69 | -17.70 | 82.99 | 0.3061 | -729.0 | -543.7 | |
| 0.00 | 1.63 | 0.00 | 0.86 | 7.83 | 200.30 | -20.09 | 77.31 | 0.3503 | 812.0 | 602.1 | |
| 0.00 | 0.82 | 0.00 | 0.44 | 7.74 | 197.79 | -22.59 | 78.69 | 0.3899 | 834.0 | 661.7 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 5.96 | 197.41 | -22.97 | 83.35 | 0.3925 | 862.0 | 689.2 | |
| 0.00 | 1.27 | 0.00 | 0.69 | 8.86 | 197.16 | -23.23 | 76.19 | 0.4030 | 824.0 | 669.8 | |
| 0.00 | 1.00 | 0.00 | 0.54 | 6.26 | 197.23 | -23.15 | 82.62 | 0.3958 | 902.0 | 672.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
