SDO HMI 2014-07-08 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 15.44 | 0.00 | 8.22 | 17.40 | 199.15 | -16.80 | 48.49 | 0.3673 | -492.2 | -508.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-08 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.66 | 16.58 | 202.47 | -13.48 | 44.83 | 0.3184 | -779.0 | -546.1 | |
| 0.00 | 0.82 | 0.00 | 0.43 | 16.56 | 200.63 | -15.32 | 48.40 | 0.3401 | -941.0 | -783.1 | |
| 0.00 | 6.72 | 0.00 | 3.56 | 17.81 | 200.39 | -15.56 | 46.06 | 0.3562 | -686.0 | -725.6 | |
| 0.00 | 1.18 | 0.00 | 0.62 | 16.05 | 200.47 | -15.48 | 49.85 | 0.3370 | -938.0 | -735.3 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 16.65 | 200.39 | -15.56 | 48.62 | 0.3440 | -842.0 | -772.9 | |
| 0.00 | 1.36 | 0.00 | 0.72 | 16.05 | 200.31 | -15.64 | 50.14 | 0.3390 | -807.0 | -637.3 | |
| 0.00 | 0.82 | 0.00 | 0.43 | 17.70 | 199.37 | -16.58 | 48.03 | 0.3672 | -866.0 | -694.1 | |
| 0.00 | 1.09 | 0.00 | 0.60 | 18.60 | 194.24 | -21.71 | 53.26 | 0.4393 | 766.0 | 675.5 | |
| 0.00 | 1.09 | 0.00 | 0.63 | 18.78 | 188.40 | -27.55 | 58.61 | 0.5150 | 663.0 | 559.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
