SDO HMI 2014-07-09 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 16.26 | 0.00 | 9.27 | -22.37 | 197.81 | -13.19 | 154.60 | 0.4945 | 54.9 | -83.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-09 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.45 | -21.72 | 204.43 | -6.57 | 166.10 | 0.4444 | 796.0 | 657.1 | |
| 0.00 | 1.91 | 0.00 | 1.06 | -21.92 | 204.39 | -6.61 | 166.13 | 0.4476 | 703.0 | 595.9 | |
| 0.00 | 2.18 | 0.00 | 1.21 | -21.56 | 203.15 | -7.85 | 163.43 | 0.4472 | 1011.0 | 781.2 | |
| 0.00 | 1.82 | 0.00 | 1.07 | -26.98 | 200.26 | -10.74 | 161.97 | 0.5384 | -765.0 | -639.9 | |
| 0.00 | 1.45 | 0.00 | 0.85 | -26.64 | 199.53 | -11.47 | 160.60 | 0.5371 | -378.0 | -369.2 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -22.79 | 199.01 | -11.99 | 156.74 | 0.4868 | 621.0 | 524.7 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -18.90 | 194.61 | -16.39 | 145.10 | 0.4684 | 717.0 | 561.3 | |
| 0.00 | 2.54 | 0.00 | 1.44 | -19.40 | 193.04 | -17.96 | 143.28 | 0.4885 | -910.0 | -769.1 | |
| 0.00 | 2.18 | 0.00 | 1.27 | -22.49 | 192.57 | -18.43 | 146.37 | 0.5293 | -778.0 | -610.2 | |
| 0.00 | 1.45 | 0.00 | 0.85 | -21.28 | 190.97 | -20.03 | 142.72 | 0.5290 | -468.0 | -410.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
