SDO HMI 2014-07-09 12:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 24.89 | 0.00 | 14.65 | -16.50 | 232.37 | 24.12 | 227.24 | 0.5352 | -83.6 | 63.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-09 12:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.55 | 0.00 | 0.40 | -25.75 | 247.38 | 39.12 | 229.86 | 0.7457 | -480.0 | -496.8 | |
| 0.00 | 0.82 | 0.00 | 0.51 | -15.27 | 240.78 | 32.52 | 238.64 | 0.6096 | 624.0 | 430.7 | |
| 0.00 | 1.45 | 0.00 | 0.91 | -16.46 | 240.54 | 32.29 | 236.75 | 0.6147 | 482.0 | 498.1 | |
| 0.00 | 1.27 | 0.00 | 0.79 | -15.48 | 240.18 | 31.92 | 237.89 | 0.6039 | 722.0 | 525.4 | |
| 0.00 | 1.00 | 0.00 | 0.60 | -14.05 | 238.01 | 29.75 | 238.29 | 0.5680 | 580.0 | 480.9 | |
| 0.00 | 1.18 | 0.00 | 0.71 | -14.04 | 237.79 | 29.53 | 238.12 | 0.5652 | 764.0 | 704.7 | |
| 0.00 | 1.18 | 0.00 | 0.70 | -14.07 | 236.71 | 28.46 | 237.15 | 0.5523 | 873.0 | 616.9 | |
| 0.00 | 1.82 | 0.00 | 1.09 | -16.06 | 236.71 | 28.46 | 234.10 | 0.5674 | 814.0 | 663.8 | |
| 0.00 | 3.72 | 0.00 | 2.20 | -14.06 | 236.39 | 28.13 | 236.88 | 0.5482 | 644.0 | 546.1 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -16.02 | 236.49 | 28.24 | 233.96 | 0.5645 | 733.0 | 614.1 | |
| 0.00 | 1.27 | 0.00 | 0.74 | -16.63 | 233.13 | 24.87 | 229.64 | 0.5310 | -741.0 | -509.9 | |
| 0.00 | 0.91 | 0.00 | 0.53 | -17.19 | 232.33 | 24.08 | 227.91 | 0.5272 | -705.0 | -705.9 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -14.86 | 231.25 | 22.99 | 230.23 | 0.4931 | -711.0 | -543.7 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -15.05 | 230.89 | 22.63 | 229.50 | 0.4907 | -770.0 | -670.5 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -17.75 | 227.65 | 19.39 | 221.05 | 0.4834 | -767.0 | -542.0 | |
| 0.00 | 0.91 | 0.00 | 0.50 | -13.63 | 226.95 | 18.69 | 226.51 | 0.4311 | -590.0 | -447.1 | |
| 0.00 | 0.82 | 0.00 | 0.45 | -13.46 | 226.44 | 18.19 | 226.03 | 0.4235 | -817.0 | -654.1 | |
| 0.00 | 1.45 | 0.00 | 0.81 | -22.24 | 215.43 | 7.17 | 194.78 | 0.4547 | -727.0 | -506.5 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -18.45 | 214.19 | 5.93 | 194.56 | 0.3918 | -741.0 | -577.9 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -24.68 | 211.45 | 3.19 | 186.07 | 0.4807 | -859.0 | -642.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
