SDO HMI 2014-07-09 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.99 | 0.00 | 5.19 | 17.67 | 197.97 | -9.74 | 32.73 | 0.2947 | -446.4 | -416.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-09 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.66 | 18.06 | 200.57 | -7.14 | 25.50 | 0.2755 | -985.0 | -767.8 | |
| 0.00 | 0.82 | 0.00 | 0.42 | 16.53 | 200.50 | -7.21 | 28.50 | 0.2532 | -721.0 | -599.6 | |
| 0.00 | 3.36 | 0.00 | 1.73 | 18.03 | 200.28 | -7.43 | 26.45 | 0.2772 | -1044.0 | -822.0 | |
| 0.00 | 0.91 | 0.00 | 0.47 | 18.15 | 199.92 | -7.79 | 27.32 | 0.2817 | -884.0 | -785.9 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 14.89 | 198.39 | -9.32 | 38.90 | 0.2503 | -848.0 | -638.8 | |
| 0.00 | 1.45 | 0.00 | 0.77 | 18.30 | 193.60 | -14.11 | 42.44 | 0.3444 | 706.0 | 561.2 | |
| 0.00 | 1.09 | 0.00 | 0.58 | 18.41 | 190.11 | -17.59 | 48.26 | 0.3859 | 651.0 | 532.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
