SDO HMI 2014-07-09 19:13:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.51 | 164.84 | 34.84 | 194.93 | -11.98 | 267.88 | 63.62 | 254.92 | 0.9092 | -35.8 | -89.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-09 19:13:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.27 | 80.88 | 4.04 | 100.42 | -10.36 | 269.36 | 65.10 | 256.96 | 0.9176 | 642.3 | 114.7 | |
| 0.00 | 1.45 | 0.00 | 1.88 | -12.36 | 270.25 | 65.99 | 254.96 | 0.9256 | 375.0 | 417.9 | |
| 11.62 | -1.00 | 14.37 | -1.00 | -10.70 | 269.35 | 65.09 | 256.58 | 0.9179 | 629.0 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.71 | -8.39 | 266.72 | 62.46 | 258.67 | 0.8965 | 569.0 | 481.7 | |
| 0.00 | 1.00 | 0.00 | 1.18 | -12.19 | 267.95 | 63.68 | 254.73 | 0.9100 | 302.0 | 242.4 | |
| 0.00 | 1.72 | 0.00 | 2.02 | -13.92 | 267.34 | 63.08 | 252.73 | 0.9080 | -363.0 | -212.8 | |
| 14.62 | 74.98 | 16.43 | 84.15 | -13.47 | 266.24 | 61.98 | 252.99 | 0.8995 | -771.1 | -354.8 | |
| 0.00 | 1.00 | 0.00 | 1.11 | -14.99 | 265.55 | 61.29 | 251.18 | 0.8969 | -249.0 | -211.5 | |
| 0.00 | 0.27 | 0.00 | 0.30 | -14.42 | 265.02 | 60.75 | 251.69 | 0.8920 | -317.0 | -310.7 | |
| 0.00 | 1.00 | 0.00 | 1.09 | -14.58 | 265.03 | 60.76 | 251.52 | 0.8923 | -342.0 | -385.0 | |
| 0.00 | 1.00 | 0.00 | 1.07 | -15.81 | 264.20 | 59.94 | 249.97 | 0.8882 | -472.0 | -416.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
