SDO HMI 2014-07-09 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 51.47 | 327.54 | 45.09 | 286.88 | -19.16 | 254.16 | 51.44 | 243.62 | 0.8267 | 794.6 | 254.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-09 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 1.30 | -20.56 | 257.09 | 54.38 | 243.07 | 0.8556 | -302.0 | -304.1 | |
| 51.11 | 311.66 | 44.79 | 273.13 | -19.08 | 254.22 | 51.50 | 243.73 | 0.8270 | 982.3 | 266.0 | |
| 0.00 | 3.72 | 0.00 | 3.31 | -21.58 | 253.86 | 51.15 | 240.75 | 0.8321 | 48.0 | 67.0 | |
| 0.00 | 2.27 | 0.00 | 1.92 | -18.96 | 252.53 | 49.81 | 243.23 | 0.8114 | 683.0 | 571.6 | |
| 0.00 | 2.09 | 0.00 | 1.84 | -21.59 | 253.45 | 50.73 | 240.57 | 0.8287 | 342.0 | 321.5 | |
| 0.00 | 1.36 | 0.00 | 1.18 | -21.00 | 253.07 | 50.35 | 241.08 | 0.8233 | 109.0 | 170.8 | |
| 0.00 | 0.27 | 0.00 | 0.23 | -19.91 | 252.53 | 49.81 | 242.12 | 0.8147 | 313.0 | 375.3 | |
| 0.00 | 1.18 | 0.00 | 0.99 | -19.23 | 252.04 | 49.32 | 242.72 | 0.8079 | 327.0 | 376.2 | |
| 0.00 | 0.64 | 0.00 | 0.53 | -21.23 | 251.05 | 48.34 | 239.98 | 0.8064 | -473.0 | -369.1 | |
| 0.36 | 1.63 | 0.30 | 1.34 | -20.87 | 250.50 | 47.79 | 240.16 | 0.8000 | -531.2 | -441.4 | |
| 0.00 | 1.36 | 0.00 | 1.11 | -20.88 | 250.07 | 47.35 | 239.96 | 0.7961 | -582.0 | -578.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
