SDO HMI 2014-07-09 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 293.68 | 1569.37 | 156.85 | 835.88 | -7.75 | 220.92 | 18.20 | 237.39 | 0.3689 | 895.1 | 309.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-09 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.50 | -9.22 | 225.60 | 22.89 | 240.19 | 0.4443 | 621.0 | 500.8 | |
| 0.64 | 3.27 | 0.34 | 1.77 | -5.73 | 224.19 | 21.48 | 246.17 | 0.3999 | 934.3 | 840.0 | |
| 0.00 | 2.36 | 0.00 | 1.27 | -5.00 | 223.44 | 20.73 | 247.14 | 0.3843 | -708.0 | -550.2 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -4.84 | 223.08 | 20.36 | 247.17 | 0.3778 | -663.0 | -520.4 | |
| 0.00 | 2.18 | 0.00 | 1.17 | -5.57 | 222.84 | 20.13 | 245.13 | 0.3791 | -847.0 | -749.0 | |
| 13.53 | 45.21 | 7.20 | 24.08 | -5.10 | 222.34 | 19.62 | 245.74 | 0.3685 | 1108.3 | 428.8 | |
| 2.00 | 1136.96 | 1.08 | 608.72 | -8.88 | 222.40 | 19.69 | 237.06 | 0.3983 | 1039.8 | 467.1 | |
| 1.00 | -7.00 | 0.54 | -7.00 | -9.07 | 222.41 | 19.70 | 236.67 | 0.4000 | 796.3 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.82 | -5.37 | 221.96 | 19.24 | 244.64 | 0.3647 | 891.0 | 683.5 | |
| 1.00 | 2.54 | 0.53 | 1.35 | -4.75 | 221.84 | 19.13 | 246.07 | 0.3588 | 1070.7 | 819.6 | |
| 220.69 | -7.00 | 118.31 | -7.00 | -7.97 | 221.90 | 19.18 | 238.40 | 0.3837 | 1660.5 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.72 | -5.89 | 221.72 | 19.00 | 243.06 | 0.3648 | 475.0 | 362.5 | |
| 0.64 | 3.09 | 0.34 | 1.64 | -5.67 | 221.55 | 18.83 | 243.40 | 0.3608 | 746.7 | 567.3 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -10.09 | 221.75 | 19.04 | 233.64 | 0.4004 | 245.0 | 192.5 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -11.50 | 221.42 | 18.70 | 230.36 | 0.4097 | -814.0 | -546.7 | |
| 1.72 | -7.00 | 0.92 | -7.00 | -7.39 | 221.09 | 18.38 | 238.63 | 0.3678 | 1517.3 | 999999 | |
| 0.00 | 1.63 | 0.00 | 0.86 | -5.19 | 220.76 | 18.04 | 243.64 | 0.3457 | 953.0 | 815.5 | |
| 4.81 | -7.00 | 2.55 | -7.00 | -7.58 | 220.00 | 17.29 | 236.59 | 0.3544 | 1253.2 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.59 | -10.90 | 220.10 | 17.39 | 229.49 | 0.3876 | -594.0 | -477.2 | |
| 6.08 | -7.00 | 3.22 | -7.00 | -7.92 | 219.86 | 17.14 | 235.56 | 0.3555 | 1357.1 | 999999 | |
| 1.09 | -7.00 | 0.58 | -7.00 | -7.14 | 219.76 | 17.05 | 237.28 | 0.3472 | 879.6 | 999999 | |
| 1.27 | 5.72 | 0.67 | 3.00 | -5.41 | 219.67 | 16.96 | 241.58 | 0.3316 | -962.9 | -777.1 | |
| 0.00 | 1.27 | 0.00 | 0.68 | -10.90 | 219.91 | 17.19 | 229.18 | 0.3852 | -600.0 | -500.9 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -4.85 | 219.40 | 16.69 | 242.72 | 0.3233 | -873.0 | -691.3 | |
| 0.00 | 0.64 | 0.00 | 0.34 | -9.79 | 219.59 | 16.87 | 230.94 | 0.3699 | -422.0 | -319.9 | |
| 0.54 | -7.00 | 0.29 | -7.00 | -8.29 | 219.45 | 16.74 | 234.07 | 0.3535 | 977.3 | 999999 | |
| 4.99 | 192.82 | 2.62 | 101.10 | -6.24 | 219.34 | 16.63 | 238.92 | 0.3336 | -453.1 | 95.1 | |
| 1.54 | -27.00 | 0.81 | -27.00 | -5.90 | 219.27 | 16.55 | 239.70 | 0.3297 | -831.6 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.53 | -8.38 | 219.30 | 16.58 | 233.60 | 0.3523 | 882.0 | 715.5 | |
| 0.00 | 7.17 | 0.00 | 3.82 | -9.94 | 219.30 | 16.59 | 230.15 | 0.3679 | 87.0 | -80.9 | |
| 0.00 | 3.54 | 0.00 | 1.87 | -8.59 | 219.02 | 16.30 | 232.64 | 0.3507 | 907.0 | 740.0 | |
| 0.00 | 2.81 | 0.00 | 1.49 | -9.78 | 218.91 | 16.19 | 229.82 | 0.3613 | -530.0 | -481.5 | |
| 4.09 | -27.00 | 2.15 | -27.00 | -7.47 | 218.75 | 16.03 | 234.86 | 0.3363 | 1141.6 | 999999 | |
| 6.35 | -27.00 | 3.33 | -27.00 | -7.12 | 218.57 | 15.86 | 235.43 | 0.3307 | 1342.0 | 999999 | |
| 4.09 | 32.05 | 2.16 | 16.92 | -9.05 | 218.62 | 15.90 | 230.91 | 0.3501 | -672.7 | 404.6 | |
| 5.90 | -35.00 | 3.11 | -35.00 | -8.49 | 218.59 | 15.88 | 232.16 | 0.3442 | 752.3 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.53 | -10.05 | 218.38 | 15.66 | 228.30 | 0.3575 | -734.0 | -593.0 | |
| 0.00 | 3.54 | 0.00 | 1.87 | -9.70 | 218.29 | 15.58 | 228.90 | 0.3529 | -597.0 | -507.6 | |
| 1.54 | -27.00 | 0.81 | -27.00 | -7.61 | 218.18 | 15.46 | 233.53 | 0.3300 | -512.1 | 999999 | |
| 0.00 | 4.45 | 0.00 | 2.35 | -9.54 | 218.03 | 15.32 | 228.77 | 0.3479 | -561.0 | -755.6 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -11.59 | 218.10 | 15.39 | 224.68 | 0.3713 | -676.0 | -495.4 | |
| 0.00 | 1.63 | 0.00 | 0.87 | -12.25 | 218.11 | 15.39 | 223.42 | 0.3790 | -804.0 | -558.6 | |
| 0.00 | 17.61 | 0.00 | 9.23 | -8.13 | 217.65 | 14.94 | 231.31 | 0.3284 | -32.0 | -130.0 | |
| 0.00 | 0.82 | 0.00 | 0.43 | -9.66 | 217.68 | 14.97 | 227.86 | 0.3449 | -817.0 | -712.3 | |
| 0.00 | 3.45 | 0.00 | 1.79 | -6.05 | 217.52 | 14.81 | 236.42 | 0.3064 | -780.0 | -727.7 | |
| 1.82 | 17.16 | 0.95 | 8.94 | -6.48 | 217.44 | 14.73 | 235.10 | 0.3093 | -1079.7 | -682.0 | |
| 0.00 | 1.82 | 0.00 | 0.94 | -5.67 | 217.42 | 14.70 | 237.27 | 0.3016 | -958.0 | -811.0 | |
| 3.63 | -27.00 | 1.90 | -27.00 | -7.53 | 217.41 | 14.69 | 232.31 | 0.3192 | -924.2 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -5.08 | 217.03 | 14.31 | 238.27 | 0.2908 | -741.0 | -607.0 | |
| 0.45 | 2.36 | 0.24 | 1.23 | -7.21 | 216.96 | 14.24 | 232.25 | 0.3100 | -978.8 | -790.3 | |
| 0.00 | 1.82 | 0.00 | 0.95 | -8.24 | 216.93 | 14.21 | 229.64 | 0.3202 | -695.0 | -596.7 | |
| 0.00 | 0.73 | 0.00 | 0.38 | -8.08 | 216.86 | 14.14 | 229.88 | 0.3177 | -835.0 | -670.8 | |
| 0.73 | 3.45 | 0.38 | 1.79 | -6.59 | 216.68 | 13.97 | 233.37 | 0.3001 | -977.4 | -815.4 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -8.14 | 216.48 | 13.76 | 228.98 | 0.3135 | -873.0 | -626.1 | |
| 0.00 | 1.09 | 0.00 | 0.57 | -6.92 | 216.38 | 13.66 | 231.86 | 0.2994 | -923.0 | -808.7 | |
| 0.00 | 0.91 | 0.00 | 0.48 | -9.38 | 216.27 | 13.55 | 225.64 | 0.3248 | -844.0 | -713.4 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -9.01 | 216.22 | 13.51 | 226.39 | 0.3200 | -809.0 | -574.4 | |
| 0.00 | 1.00 | 0.00 | 0.52 | -6.36 | 216.05 | 13.33 | 232.70 | 0.2893 | -816.0 | -647.7 | |
| 0.00 | 0.82 | 0.00 | 0.43 | -10.35 | 216.18 | 13.47 | 223.36 | 0.3351 | -588.0 | -539.0 | |
| 0.00 | 8.17 | 0.00 | 4.22 | -6.42 | 215.83 | 13.11 | 232.08 | 0.2870 | -1107.0 | -835.1 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -9.34 | 215.86 | 13.14 | 224.84 | 0.3195 | -896.0 | -728.8 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -6.31 | 215.04 | 12.32 | 230.64 | 0.2756 | -887.0 | -727.6 | |
| 0.45 | 1.72 | 0.23 | 0.89 | -7.02 | 214.84 | 12.12 | 228.22 | 0.2807 | -881.0 | -740.6 | |
| 0.00 | 3.18 | 0.00 | 1.65 | -8.17 | 214.71 | 12.00 | 224.98 | 0.2923 | -1011.0 | -750.7 | |
| 3.09 | 14.80 | 1.59 | 7.62 | -6.83 | 214.52 | 11.80 | 227.98 | 0.2746 | -1033.1 | -840.9 | |
| 0.00 | 3.36 | 0.00 | 1.73 | -6.73 | 214.20 | 11.49 | 227.47 | 0.2696 | -938.0 | -796.8 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -10.73 | 214.04 | 11.32 | 217.71 | 0.3168 | -826.0 | -575.3 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -9.22 | 213.99 | 11.27 | 220.75 | 0.2969 | -804.0 | -604.1 | |
| 0.00 | 1.72 | 0.00 | 0.89 | -8.93 | 213.35 | 10.64 | 219.76 | 0.2863 | -956.0 | -782.6 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -7.93 | 213.32 | 10.61 | 222.05 | 0.2734 | -734.0 | -606.5 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -9.31 | 213.33 | 10.61 | 218.87 | 0.2910 | -924.0 | -816.4 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -9.74 | 213.28 | 10.57 | 217.80 | 0.2961 | -719.0 | -639.1 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -7.34 | 212.97 | 10.25 | 222.59 | 0.2620 | -869.0 | -629.0 | |
| 0.00 | 2.09 | 0.00 | 1.07 | -7.99 | 212.79 | 10.08 | 220.46 | 0.2682 | -922.0 | -776.3 | |
| 0.00 | 0.91 | 0.00 | 0.46 | -5.57 | 212.53 | 9.81 | 226.37 | 0.2354 | -754.0 | -658.2 | |
| 0.00 | 1.00 | 0.00 | 0.53 | -16.11 | 206.51 | 3.80 | 190.59 | 0.3477 | 592.0 | 433.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
