SDO HMI 2014-07-10 02:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.32 | 193.17 | 33.46 | 170.86 | -19.76 | 149.01 | -51.49 | 117.08 | 0.8289 | 357.7 | 76.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-10 02:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.54 | -7.69 | 160.08 | -40.42 | 105.96 | 0.6706 | 661.0 | 474.7 | |
| 0.00 | 0.73 | 0.00 | 0.55 | -20.75 | 156.65 | -43.86 | 121.59 | 0.7629 | 682.0 | 561.5 | |
| 0.00 | 0.73 | 0.00 | 0.56 | -20.99 | 156.51 | -43.99 | 121.81 | 0.7653 | 682.0 | 637.4 | |
| 0.00 | 0.91 | 0.00 | 0.72 | -17.59 | 153.24 | -47.26 | 116.21 | 0.7826 | 588.0 | 456.1 | |
| 0.00 | 1.36 | 0.00 | 1.09 | -17.71 | 152.73 | -47.78 | 116.14 | 0.7881 | 485.0 | 402.3 | |
| 0.00 | 1.27 | 0.00 | 1.02 | -17.52 | 152.65 | -47.86 | 115.88 | 0.7881 | 720.0 | 661.2 | |
| 0.00 | 0.82 | 0.00 | 0.70 | -20.86 | 151.07 | -49.44 | 119.14 | 0.8150 | 480.0 | 461.0 | |
| 0.00 | 0.91 | 0.00 | 0.78 | -21.21 | 150.81 | -49.70 | 119.43 | 0.8185 | 494.0 | 423.7 | |
| 0.00 | 1.73 | 0.00 | 1.47 | -20.74 | 150.87 | -49.64 | 118.92 | 0.8163 | 432.0 | 423.5 | |
| 0.00 | 3.09 | 0.00 | 2.65 | -20.59 | 150.58 | -49.92 | 118.63 | 0.8183 | 558.0 | 348.3 | |
| 6.81 | 70.56 | 5.90 | 62.02 | -19.84 | 149.74 | -50.76 | 117.44 | 0.8231 | 841.6 | 138.2 | |
| 1.18 | -11.00 | 1.04 | -11.00 | -20.28 | 149.44 | -51.07 | 117.83 | 0.8272 | 405.7 | 999999 | |
| 7.08 | 33.33 | 6.05 | 28.55 | -18.74 | 150.01 | -50.49 | 116.27 | 0.8170 | 969.9 | 405.6 | |
| 2.18 | 6.18 | 1.89 | 5.37 | -19.38 | 149.58 | -50.92 | 116.86 | 0.8230 | 779.3 | 510.9 | |
| 13.99 | -11.00 | 12.30 | -11.00 | -19.93 | 149.18 | -51.33 | 117.33 | 0.8283 | 577.7 | 999999 | |
| 1.54 | -13.00 | 1.33 | -13.00 | -18.69 | 149.73 | -50.78 | 116.11 | 0.8194 | 740.4 | 999999 | |
| 1.45 | -13.00 | 1.26 | -13.00 | -18.89 | 149.54 | -50.97 | 116.27 | 0.8218 | 501.1 | 999999 | |
| 0.00 | 1.73 | 0.00 | 1.57 | -21.29 | 148.10 | -52.41 | 118.46 | 0.8418 | 368.0 | 324.6 | |
| 1.00 | 38.41 | 0.90 | 34.93 | -20.33 | 148.52 | -51.99 | 117.54 | 0.8353 | 217.3 | -141.0 | |
| 0.00 | 3.72 | 0.00 | 3.28 | -19.42 | 148.89 | -51.61 | 116.64 | 0.8292 | 430.0 | 333.6 | |
| 0.00 | 2.72 | 0.00 | 2.42 | -19.73 | 148.70 | -51.81 | 116.92 | 0.8318 | 460.0 | 381.8 | |
| 0.00 | 0.36 | 0.00 | 0.32 | -19.10 | 148.77 | -51.73 | 116.23 | 0.8292 | 129.0 | 141.5 | |
| 2.09 | -19.00 | 1.89 | -19.00 | -20.32 | 148.15 | -52.35 | 117.39 | 0.8383 | 395.6 | 999999 | |
| 0.00 | 2.18 | 0.00 | 2.03 | -21.56 | 147.41 | -53.09 | 118.51 | 0.8483 | -183.0 | -145.0 | |
| 0.00 | 4.54 | 0.00 | 4.05 | -19.51 | 148.43 | -52.08 | 116.57 | 0.8335 | -205.0 | -141.6 | |
| 1.00 | -19.00 | 0.90 | -19.00 | -19.96 | 148.11 | -52.39 | 116.96 | 0.8376 | 305.5 | 999999 | |
| 0.00 | 0.73 | 0.00 | 0.66 | -19.78 | 147.83 | -52.68 | 116.65 | 0.8394 | 345.0 | 273.1 | |
| 0.00 | 1.00 | 0.00 | 0.93 | -21.11 | 147.10 | -53.40 | 117.89 | 0.8495 | -368.0 | -318.9 | |
| 0.00 | 1.63 | 0.00 | 1.56 | -20.63 | 146.13 | -54.38 | 117.02 | 0.8560 | -628.0 | -553.1 | |
| 0.00 | 1.36 | 0.00 | 1.28 | -20.09 | 146.30 | -54.21 | 116.47 | 0.8531 | -582.0 | -558.9 | |
| 0.00 | 0.64 | 0.00 | 0.60 | -19.85 | 146.42 | -54.09 | 116.25 | 0.8514 | -585.0 | -548.0 | |
| 0.00 | 2.27 | 0.00 | 2.16 | -20.40 | 146.02 | -54.48 | 116.73 | 0.8562 | -596.0 | -535.4 | |
| 0.00 | 1.27 | 0.00 | 1.21 | -20.14 | 145.99 | -54.51 | 116.43 | 0.8557 | -526.0 | -517.9 | |
| 0.00 | 1.36 | 0.00 | 1.29 | -19.94 | 146.04 | -54.46 | 116.22 | 0.8547 | -691.0 | -622.9 | |
| 0.00 | 1.36 | 0.00 | 1.31 | -20.47 | 145.54 | -54.97 | 116.63 | 0.8602 | -585.0 | -517.9 | |
| 0.00 | 1.00 | 0.00 | 0.94 | -19.07 | 146.25 | -54.25 | 115.32 | 0.8506 | 62.0 | 91.0 | |
| 0.00 | 0.27 | 0.00 | 0.26 | -19.99 | 145.79 | -54.71 | 116.19 | 0.8569 | -563.0 | -558.7 | |
| 0.00 | 1.27 | 0.00 | 1.24 | -20.52 | 145.17 | -55.34 | 116.57 | 0.8633 | -281.0 | -383.9 | |
| 0.00 | 0.82 | 0.00 | 0.78 | -19.58 | 145.50 | -55.01 | 115.63 | 0.8582 | -508.0 | -515.4 | |
| 0.00 | 0.91 | 0.00 | 0.87 | -19.27 | 145.59 | -54.91 | 115.32 | 0.8566 | -307.0 | -297.6 | |
| 0.00 | 1.18 | 0.00 | 1.15 | -20.27 | 144.96 | -55.55 | 116.22 | 0.8643 | -580.0 | -509.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
