SDO HMI 2014-07-10 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 49.59 | 293.84 | 47.01 | 278.23 | -19.21 | 254.06 | 54.65 | 244.65 | 0.8543 | 699.7 | 243.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-10 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.54 | 0.00 | 1.63 | -22.70 | 256.96 | 57.55 | 241.76 | 0.8856 | -301.0 | -260.2 | |
| 49.59 | 275.77 | 47.01 | 261.43 | -19.11 | 254.14 | 54.73 | 244.79 | 0.8547 | 851.3 | 246.0 | |
| 0.00 | 1.36 | 0.00 | 1.31 | -21.22 | 253.93 | 54.52 | 242.38 | 0.8588 | 467.0 | 383.5 | |
| 0.00 | 2.09 | 0.00 | 1.98 | -20.53 | 253.57 | 54.16 | 243.01 | 0.8540 | 495.0 | 322.9 | |
| 0.00 | 0.36 | 0.00 | 0.33 | -18.86 | 252.70 | 53.29 | 244.58 | 0.8420 | 451.0 | 473.0 | |
| 0.00 | 1.09 | 0.00 | 0.99 | -19.50 | 252.40 | 52.99 | 243.76 | 0.8413 | 669.0 | 597.2 | |
| 0.00 | 0.82 | 0.00 | 0.74 | -19.39 | 252.19 | 52.78 | 243.81 | 0.8392 | 655.0 | 538.3 | |
| 0.00 | 1.27 | 0.00 | 1.15 | -19.56 | 252.15 | 52.75 | 243.61 | 0.8394 | 627.0 | 601.5 | |
| 0.00 | 0.82 | 0.00 | 0.75 | -19.90 | 252.31 | 52.91 | 243.28 | 0.8418 | 438.0 | 414.0 | |
| 0.00 | 2.09 | 0.00 | 1.96 | -21.39 | 252.85 | 53.44 | 241.80 | 0.8507 | 647.0 | 451.6 | |
| 0.00 | 0.54 | 0.00 | 0.49 | -19.68 | 252.00 | 52.59 | 243.41 | 0.8384 | 448.0 | 403.3 | |
| 0.00 | 2.00 | 0.00 | 1.81 | -19.98 | 252.03 | 52.62 | 243.09 | 0.8396 | 361.0 | 424.0 | |
| 0.00 | 0.36 | 0.00 | 0.34 | -21.17 | 252.57 | 53.16 | 241.94 | 0.8478 | 517.0 | 545.0 | |
| 0.00 | 0.73 | 0.00 | 0.65 | -20.03 | 251.73 | 52.32 | 242.92 | 0.8372 | -228.0 | -184.6 | |
| 0.00 | 1.09 | 0.00 | 1.00 | -22.06 | 251.73 | 52.32 | 240.64 | 0.8437 | -174.0 | -324.2 | |
| 0.00 | 0.82 | 0.00 | 0.72 | -20.85 | 250.33 | 50.92 | 241.46 | 0.8279 | -360.0 | -418.7 | |
| 0.00 | 1.09 | 0.00 | 0.95 | -21.06 | 250.07 | 50.66 | 241.11 | 0.8264 | -639.0 | -585.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
