SDO HMI 2014-07-10 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.96 | 265.74 | 46.65 | 287.43 | -19.20 | 253.82 | 59.35 | 246.07 | 0.8907 | 701.2 | 166.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-10 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.96 | 250.12 | 46.65 | 271.46 | -19.15 | 253.94 | 59.47 | 246.16 | 0.8915 | 781.3 | 163.9 | |
| 0.00 | 1.63 | 0.00 | 1.77 | -20.73 | 253.45 | 58.98 | 244.30 | 0.8913 | 297.0 | 248.0 | |
| 0.00 | 0.73 | 0.00 | 0.74 | -19.22 | 251.87 | 57.40 | 245.49 | 0.8762 | 417.0 | 423.2 | |
| 0.00 | 1.27 | 0.00 | 1.29 | -19.27 | 251.54 | 57.07 | 245.34 | 0.8737 | -60.0 | -33.9 | |
| 0.00 | 3.18 | 0.00 | 3.24 | -19.57 | 251.70 | 57.23 | 245.06 | 0.8758 | 531.0 | 435.3 | |
| 0.00 | 6.63 | 0.00 | 6.76 | -20.00 | 251.64 | 57.17 | 244.57 | 0.8763 | 353.0 | 250.9 | |
| 0.00 | 1.27 | 0.00 | 1.28 | -20.13 | 251.12 | 56.65 | 244.26 | 0.8726 | -56.0 | -176.9 | |
| 0.00 | 0.91 | 0.00 | 0.89 | -21.25 | 249.87 | 55.40 | 242.62 | 0.8659 | -312.0 | -310.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
