SDO HMI 2014-07-10 14:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 262.71 | 1488.58 | 150.30 | 847.14 | -7.97 | 221.30 | 27.38 | 246.52 | 0.4985 | 834.6 | 311.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-10 14:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.91 | 0.00 | 1.13 | -6.63 | 225.15 | 31.23 | 251.50 | 0.5452 | 572.0 | 514.4 | |
| 0.00 | 1.91 | 0.00 | 1.12 | -6.13 | 224.97 | 31.05 | 252.29 | 0.5405 | 943.0 | 757.5 | |
| 0.00 | 0.36 | 0.00 | 0.22 | -9.96 | 225.01 | 31.09 | 245.73 | 0.5600 | 567.0 | 595.5 | |
| 0.00 | 0.91 | 0.00 | 0.54 | -9.64 | 224.94 | 31.02 | 246.21 | 0.5573 | 762.0 | 617.5 | |
| 13.71 | 26.43 | 7.87 | 15.17 | -5.25 | 222.83 | 28.91 | 252.70 | 0.5063 | 961.8 | 51.7 | |
| 0.00 | 2.45 | 0.00 | 1.44 | -10.08 | 223.12 | 29.20 | 244.18 | 0.5357 | -162.0 | -196.4 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -6.08 | 222.81 | 28.89 | 251.12 | 0.5097 | -734.0 | -533.7 | |
| 0.00 | 1.54 | 0.00 | 0.89 | -5.65 | 222.71 | 28.79 | 251.88 | 0.5063 | 124.0 | 149.9 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -5.44 | 222.18 | 28.26 | 251.95 | 0.4977 | 790.0 | 626.8 | |
| 218.40 | 1289.95 | 125.36 | 735.66 | -8.04 | 221.89 | 27.97 | 246.87 | 0.5070 | 1501.5 | 377.1 | |
| 0.00 | 1.54 | 0.00 | 0.89 | -10.16 | 221.93 | 28.01 | 243.10 | 0.5204 | 223.0 | 162.1 | |
| 0.00 | 0.54 | 0.00 | 0.32 | -10.53 | 221.82 | 27.90 | 242.36 | 0.5214 | -315.0 | -243.2 | |
| 0.00 | 1.36 | 0.00 | 0.78 | -10.47 | 220.70 | 26.78 | 241.52 | 0.5060 | 610.0 | 306.1 | |
| 0.00 | 9.35 | 0.00 | 5.36 | -10.65 | 220.40 | 26.48 | 240.94 | 0.5034 | 115.0 | 12.2 | |
| 0.00 | 3.81 | 0.00 | 2.18 | -10.96 | 220.26 | 26.34 | 240.26 | 0.5037 | -741.0 | -558.6 | |
| 4.63 | -10.00 | 2.61 | -10.00 | -7.57 | 219.88 | 25.97 | 246.21 | 0.4763 | 1051.5 | 999999 | |
| 1.82 | -10.00 | 1.02 | -10.00 | -8.03 | 219.92 | 26.00 | 245.33 | 0.4796 | 1249.0 | 999999 | |
| 1.63 | 4.09 | 0.91 | 2.28 | -5.45 | 219.70 | 25.78 | 250.28 | 0.4618 | -756.3 | -617.1 | |
| 0.73 | 3.36 | 0.41 | 1.91 | -9.84 | 219.92 | 26.00 | 241.94 | 0.4914 | 952.5 | 781.7 | |
| 0.00 | 2.18 | 0.00 | 1.24 | -10.19 | 219.91 | 25.99 | 241.31 | 0.4937 | 549.0 | 434.0 | |
| 0.00 | 1.82 | 0.00 | 1.03 | -10.41 | 219.90 | 25.98 | 240.90 | 0.4950 | 226.0 | 158.9 | |
| 0.00 | 2.18 | 0.00 | 1.23 | -8.59 | 219.75 | 25.83 | 244.13 | 0.4807 | 281.0 | 276.7 | |
| 0.00 | 0.64 | 0.00 | 0.36 | -10.66 | 219.88 | 25.97 | 240.44 | 0.4966 | -538.0 | -577.7 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -5.26 | 219.39 | 25.47 | 250.46 | 0.4562 | -753.0 | -592.8 | |
| 2.27 | -10.00 | 1.26 | -10.00 | -6.30 | 219.13 | 25.21 | 248.12 | 0.4582 | -429.0 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.87 | -9.73 | 219.15 | 25.23 | 241.45 | 0.4803 | -422.0 | -374.9 | |
| 2.72 | 5.63 | 1.54 | 3.19 | -10.39 | 219.17 | 25.25 | 240.26 | 0.4852 | -767.5 | -539.8 | |
| 0.00 | 1.63 | 0.00 | 0.90 | -3.92 | 218.76 | 24.85 | 252.88 | 0.4404 | -821.0 | -689.8 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -9.91 | 219.03 | 25.11 | 240.99 | 0.4799 | -587.0 | -465.7 | |
| 2.72 | 53.67 | 1.52 | 30.02 | -8.31 | 218.88 | 24.96 | 243.89 | 0.4669 | 1143.4 | 425.2 | |
| 1.91 | -10.00 | 1.06 | -10.00 | -7.13 | 218.80 | 24.88 | 246.17 | 0.4583 | 1263.7 | 999999 | |
| 0.00 | 2.27 | 0.00 | 1.28 | -9.63 | 218.97 | 25.05 | 241.47 | 0.4771 | -590.0 | -498.8 | |
| 2.18 | -10.00 | 1.21 | -10.00 | -7.35 | 218.78 | 24.86 | 245.72 | 0.4594 | 1120.5 | 999999 | |
| 0.82 | -10.00 | 0.45 | -10.00 | -7.09 | 218.63 | 24.71 | 246.10 | 0.4557 | 1317.9 | 999999 | |
| 0.00 | 0.64 | 0.00 | 0.36 | -9.33 | 218.61 | 24.69 | 241.67 | 0.4702 | -546.0 | -438.0 | |
| 1.09 | 2.09 | 0.61 | 1.17 | -8.89 | 218.47 | 24.56 | 242.39 | 0.4652 | -658.4 | -536.8 | |
| 1.63 | -30.00 | 0.91 | -30.00 | -8.17 | 218.39 | 24.47 | 243.72 | 0.4592 | 668.1 | 999999 | |
| 0.00 | 2.27 | 0.00 | 1.27 | -9.80 | 218.47 | 24.56 | 240.66 | 0.4717 | -474.0 | -403.2 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -9.33 | 218.37 | 24.45 | 241.46 | 0.4669 | -682.0 | -541.7 | |
| 0.00 | 1.82 | 0.00 | 1.01 | -9.04 | 218.32 | 24.40 | 241.95 | 0.4641 | -722.0 | -624.0 | |
| 0.00 | 1.82 | 0.00 | 1.02 | -9.58 | 218.32 | 24.40 | 240.93 | 0.4680 | -668.0 | -510.8 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -9.89 | 218.28 | 24.36 | 240.30 | 0.4697 | -632.0 | -490.5 | |
| 0.00 | 2.00 | 0.00 | 1.10 | -5.80 | 217.93 | 24.01 | 248.18 | 0.4378 | -804.0 | -710.2 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -4.63 | 217.85 | 23.93 | 250.67 | 0.4302 | -616.0 | -459.3 | |
| 0.00 | 3.27 | 0.00 | 1.82 | -9.32 | 218.06 | 24.15 | 241.17 | 0.4626 | -750.0 | -680.9 | |
| 2.63 | -10.00 | 1.45 | -10.00 | -6.39 | 217.82 | 23.90 | 246.85 | 0.4397 | -950.7 | 999999 | |
| 2.82 | -10.00 | 1.56 | -10.00 | -7.44 | 217.74 | 23.82 | 244.59 | 0.4452 | -739.8 | 999999 | |
| 1.00 | -10.00 | 0.55 | -10.00 | -6.60 | 217.69 | 23.78 | 246.29 | 0.4392 | -705.7 | 999999 | |
| 0.00 | 3.18 | 0.00 | 1.74 | -5.15 | 217.63 | 23.71 | 249.36 | 0.4298 | -759.0 | -584.1 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -6.14 | 217.67 | 23.75 | 247.26 | 0.4361 | -866.0 | -768.2 | |
| 0.00 | 5.45 | 0.00 | 3.01 | -7.99 | 217.57 | 23.65 | 243.30 | 0.4465 | 20.0 | -156.4 | |
| 0.00 | 3.27 | 0.00 | 1.80 | -6.69 | 217.43 | 23.51 | 245.87 | 0.4360 | -822.0 | -606.6 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -12.24 | 217.73 | 23.81 | 235.46 | 0.4810 | -737.0 | -555.4 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -6.25 | 217.31 | 23.39 | 246.69 | 0.4315 | -868.0 | -617.8 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -7.37 | 217.33 | 23.42 | 244.36 | 0.4390 | -842.0 | -707.3 | |
| 0.00 | 2.45 | 0.00 | 1.35 | -6.77 | 217.23 | 23.32 | 245.51 | 0.4337 | -752.0 | -627.3 | |
| 0.00 | 1.27 | 0.00 | 0.71 | -9.94 | 216.89 | 22.98 | 238.75 | 0.4516 | -524.0 | -422.7 | |
| 0.00 | 2.91 | 0.00 | 1.59 | -7.90 | 216.56 | 22.64 | 242.47 | 0.4318 | -732.0 | -642.4 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -9.39 | 216.29 | 22.37 | 239.15 | 0.4391 | -840.0 | -754.6 | |
| 0.00 | 4.09 | 0.00 | 2.22 | -6.34 | 216.08 | 22.16 | 245.34 | 0.4143 | -718.0 | -793.4 | |
| 0.00 | 1.54 | 0.00 | 0.84 | -7.90 | 215.46 | 21.55 | 241.29 | 0.4165 | -897.0 | -680.3 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -9.84 | 215.45 | 21.53 | 237.29 | 0.4315 | -801.0 | -641.4 | |
| 0.00 | 2.36 | 0.00 | 1.28 | -8.11 | 215.11 | 21.19 | 240.45 | 0.4132 | -786.0 | -690.5 | |
| 0.00 | 0.82 | 0.00 | 0.44 | -6.89 | 214.82 | 20.90 | 242.78 | 0.4000 | -791.0 | -683.9 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -7.36 | 214.84 | 20.92 | 241.77 | 0.4037 | -893.0 | -754.0 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -9.73 | 214.91 | 20.99 | 236.85 | 0.4235 | -788.0 | -697.6 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -6.89 | 214.66 | 20.74 | 242.60 | 0.3976 | -924.0 | -723.5 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -10.18 | 213.91 | 20.00 | 234.67 | 0.4143 | -720.0 | -547.2 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -9.86 | 213.76 | 19.84 | 235.11 | 0.4095 | -832.0 | -625.5 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -9.13 | 213.42 | 19.51 | 236.17 | 0.3986 | -1002.0 | -785.9 | |
| 0.00 | 0.64 | 0.00 | 0.34 | -7.93 | 212.94 | 19.02 | 238.12 | 0.3817 | -788.0 | -565.9 | |
| 0.00 | 1.27 | 0.00 | 0.67 | -7.26 | 211.81 | 17.89 | 238.11 | 0.3604 | -938.0 | -812.4 | |
| 0.00 | 1.82 | 0.00 | 0.96 | -6.97 | 211.57 | 17.65 | 238.46 | 0.3547 | -812.0 | -588.1 | |
| 0.00 | 0.64 | 0.00 | 0.34 | -7.15 | 211.41 | 17.50 | 237.79 | 0.3541 | -839.0 | -654.6 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -14.57 | 210.25 | 16.33 | 220.96 | 0.4169 | -800.0 | -637.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
