SDO HMI 2014-07-10 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.43 | 60.38 | 26.40 | 86.11 | 14.43 | 262.23 | 69.97 | 283.97 | 0.9390 | -414.7 | -166.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-10 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.82 | 0.00 | 2.90 | 9.17 | 264.57 | 72.31 | 278.39 | 0.9521 | -296.0 | -238.1 | |
| 11.62 | 26.60 | 16.91 | 38.91 | 14.27 | 262.72 | 70.46 | 283.78 | 0.9419 | -434.7 | -64.1 | |
| 0.00 | 0.64 | 0.00 | 0.87 | 12.41 | 261.41 | 69.15 | 281.82 | 0.9340 | -323.0 | -305.3 | |
| 0.00 | 2.36 | 0.00 | 3.15 | 12.29 | 260.81 | 68.56 | 281.70 | 0.9303 | -165.0 | -122.2 | |
| 6.81 | 28.96 | 9.49 | 40.28 | 15.18 | 261.71 | 69.45 | 284.78 | 0.9361 | -427.6 | -232.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
