SDO HMI 2014-07-11 03:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.72 | 27.25 | 9.04 | 52.41 | 14.66 | 262.48 | 75.76 | 284.14 | 0.9680 | -242.4 | -242.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 03:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.91 | 0.00 | 5.94 | 13.78 | 263.20 | 76.48 | 283.23 | 0.9711 | -90.0 | -43.2 | |
| 1.54 | 8.36 | 3.17 | 16.70 | 14.18 | 263.35 | 76.63 | 283.64 | 0.9717 | -164.1 | -301.6 | |
| 0.00 | 1.54 | 0.00 | 3.19 | 14.49 | 263.42 | 76.69 | 283.96 | 0.9720 | -211.0 | -192.4 | |
| 2.27 | 14.44 | 4.20 | 26.58 | 15.10 | 261.71 | 74.99 | 284.60 | 0.9648 | -279.4 | -268.1 | |
| 0.91 | -4.00 | 1.67 | -4.00 | 15.40 | 261.52 | 74.80 | 284.90 | 0.9639 | -407.8 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
