SDO HMI 2014-07-11 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 16.18 | 0.00 | 9.23 | -22.32 | 196.83 | 12.30 | 204.12 | 0.4950 | -106.2 | -96.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.86 | -21.93 | 205.41 | 20.88 | 217.41 | 0.5464 | 614.0 | 487.4 | |
| 0.00 | 2.36 | 0.00 | 1.39 | -22.25 | 204.72 | 20.19 | 216.13 | 0.5439 | 584.0 | 428.9 | |
| 0.00 | 0.64 | 0.00 | 0.37 | -22.43 | 203.45 | 18.92 | 214.22 | 0.5352 | 480.0 | 383.0 | |
| 0.00 | 1.36 | 0.00 | 0.78 | -22.22 | 198.51 | 13.98 | 206.99 | 0.4947 | 720.0 | 589.6 | |
| 0.00 | 3.27 | 0.00 | 1.81 | -19.18 | 197.50 | 12.97 | 208.46 | 0.4467 | -657.0 | -475.0 | |
| 0.00 | 0.91 | 0.00 | 0.50 | -19.44 | 197.32 | 12.79 | 207.84 | 0.4490 | -694.0 | -471.3 | |
| 0.00 | 0.64 | 0.00 | 0.35 | -20.79 | 193.81 | 9.28 | 199.85 | 0.4459 | -597.0 | -497.3 | |
| 0.00 | 2.73 | 0.00 | 1.52 | -22.06 | 192.49 | 7.96 | 196.34 | 0.4582 | -822.0 | -511.4 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -22.33 | 192.48 | 7.95 | 196.13 | 0.4621 | -611.0 | -483.3 | |
| 0.00 | 1.64 | 0.00 | 0.99 | -30.94 | 183.64 | -0.89 | 178.67 | 0.5742 | -79.0 | -142.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
