SDO HMI 2014-07-11 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.34 | 170.79 | 44.65 | 278.71 | -19.38 | 253.60 | 69.62 | 248.21 | 0.9537 | 403.8 | 109.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.34 | 161.43 | 44.65 | 264.22 | -19.28 | 253.68 | 69.70 | 248.32 | 0.9540 | 422.9 | 100.9 | |
| 0.00 | 0.64 | 0.00 | 0.97 | -19.02 | 252.26 | 68.28 | 248.32 | 0.9466 | 515.0 | 505.3 | |
| 0.00 | 1.36 | 0.00 | 2.02 | -19.18 | 251.70 | 67.72 | 248.04 | 0.9438 | 365.0 | 394.3 | |
| 0.00 | 0.82 | 0.00 | 1.27 | -20.99 | 252.31 | 68.33 | 246.28 | 0.9490 | 295.0 | 222.2 | |
| 0.00 | 2.00 | 0.00 | 3.18 | -21.39 | 252.70 | 68.72 | 245.96 | 0.9514 | 196.0 | 117.2 | |
| 0.00 | 3.63 | 0.00 | 5.69 | -21.60 | 252.37 | 68.39 | 245.67 | 0.9500 | 459.0 | 348.4 | |
| 0.00 | 0.91 | 0.00 | 1.36 | -22.85 | 251.08 | 67.09 | 244.11 | 0.9450 | -257.0 | -273.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
