SDO HMI 2014-07-11 10:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.34 | 167.60 | 45.32 | 289.14 | -19.45 | 253.52 | 70.63 | 248.31 | 0.9586 | 329.9 | 72.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 10:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.16 | 154.70 | 43.46 | 268.40 | -19.28 | 253.66 | 70.77 | 248.51 | 0.9591 | 365.6 | 66.2 | |
| 0.00 | 1.64 | 0.00 | 2.56 | -19.19 | 251.86 | 68.97 | 248.27 | 0.9503 | 548.0 | 455.3 | |
| 0.00 | 1.18 | 0.00 | 1.93 | -21.13 | 252.27 | 69.38 | 246.35 | 0.9544 | 421.0 | 329.0 | |
| 0.45 | 5.81 | 0.75 | 9.62 | -21.53 | 252.31 | 69.43 | 245.95 | 0.9550 | 342.8 | 249.4 | |
| 0.00 | 1.09 | 0.00 | 1.73 | -22.73 | 251.27 | 68.39 | 244.50 | 0.9513 | -119.0 | -107.0 | |
| 0.00 | 1.00 | 0.00 | 1.58 | -22.96 | 251.15 | 68.27 | 244.24 | 0.9510 | -228.0 | -204.7 | |
| 0.73 | 2.18 | 1.11 | 3.32 | -22.84 | 250.31 | 67.43 | 244.19 | 0.9467 | -445.4 | -366.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
