SDO HMI 2014-07-11 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.79 | 146.32 | 43.15 | 277.03 | -19.42 | 253.54 | 72.30 | 248.63 | 0.9659 | 275.2 | 42.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.79 | 136.68 | 43.15 | 260.26 | -19.29 | 253.66 | 72.42 | 248.78 | 0.9663 | 298.6 | 34.7 | |
| 0.00 | 2.00 | 0.00 | 3.42 | -19.27 | 251.87 | 70.64 | 248.50 | 0.9585 | 494.0 | 439.0 | |
| 0.00 | 1.00 | 0.00 | 1.81 | -21.52 | 252.50 | 71.27 | 246.31 | 0.9633 | -54.0 | 17.2 | |
| 0.00 | 1.00 | 0.00 | 1.77 | -21.33 | 252.18 | 70.95 | 246.44 | 0.9617 | 373.0 | 311.2 | |
| 0.00 | 3.09 | 0.00 | 5.50 | -21.63 | 252.11 | 70.88 | 246.13 | 0.9617 | 401.0 | 288.5 | |
| 0.00 | 0.64 | 0.00 | 1.09 | -22.83 | 251.12 | 69.88 | 244.71 | 0.9585 | -159.0 | -115.1 | |
| 0.00 | 1.91 | 0.00 | 3.18 | -23.12 | 250.49 | 69.26 | 244.28 | 0.9559 | -411.0 | -329.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
