SDO HMI 2014-07-11 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 201.51 | 1233.08 | 134.50 | 816.36 | -7.99 | 221.45 | 40.22 | 253.37 | 0.6694 | 920.0 | 309.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.18 | 0.00 | 0.84 | -6.18 | 226.05 | 44.81 | 257.44 | 0.7201 | 451.0 | 313.2 | |
| 2.72 | 7.54 | 1.85 | 5.12 | -5.13 | 223.53 | 42.29 | 258.19 | 0.6870 | 661.4 | 585.0 | |
| 0.00 | 1.09 | 0.00 | 0.74 | -5.09 | 223.24 | 42.00 | 258.17 | 0.6832 | 779.0 | 741.1 | |
| 178.45 | 1152.62 | 119.59 | 764.68 | -8.03 | 221.93 | 40.70 | 253.50 | 0.6756 | 1380.7 | 354.4 | |
| 0.82 | -4.00 | 0.53 | -4.00 | -5.84 | 220.74 | 39.51 | 256.29 | 0.6537 | -453.2 | 999999 | |
| 0.00 | 2.00 | 0.00 | 1.33 | -11.00 | 220.61 | 39.37 | 248.70 | 0.6706 | 391.0 | 409.0 | |
| 0.00 | 1.09 | 0.00 | 0.71 | -8.93 | 219.75 | 38.52 | 251.31 | 0.6518 | 777.0 | 697.9 | |
| 0.00 | 0.36 | 0.00 | 0.24 | -11.10 | 220.02 | 38.78 | 248.28 | 0.6639 | 3.0 | -57.8 | |
| 2.63 | -4.00 | 1.71 | -4.00 | -8.11 | 219.58 | 38.34 | 252.44 | 0.6464 | 933.8 | 999999 | |
| 0.00 | 1.63 | 0.00 | 1.05 | -5.77 | 219.32 | 38.08 | 255.88 | 0.6350 | -661.0 | -524.3 | |
| 0.00 | 5.63 | 0.00 | 3.69 | -10.37 | 219.79 | 38.55 | 249.22 | 0.6580 | 113.0 | 197.8 | |
| 0.00 | 1.73 | 0.00 | 1.13 | -9.45 | 219.66 | 38.43 | 250.49 | 0.6527 | 390.0 | 279.4 | |
| 2.54 | -4.00 | 1.63 | -4.00 | -6.08 | 219.19 | 37.95 | 255.36 | 0.6343 | -391.6 | 999999 | |
| 1.73 | -4.00 | 1.11 | -4.00 | -7.38 | 219.15 | 37.91 | 253.36 | 0.6382 | 846.9 | 999999 | |
| 0.00 | 5.36 | 0.00 | 3.50 | -10.54 | 219.50 | 38.26 | 248.82 | 0.6552 | -68.0 | -188.1 | |
| 2.09 | -4.00 | 1.34 | -4.00 | -7.15 | 218.93 | 37.69 | 253.62 | 0.6346 | 977.5 | 999999 | |
| 4.63 | -4.00 | 2.98 | -4.00 | -8.86 | 218.92 | 37.68 | 251.03 | 0.6410 | 441.8 | 999999 | |
| 0.54 | -4.00 | 0.35 | -4.00 | -6.17 | 218.61 | 37.38 | 254.99 | 0.6271 | -536.8 | 999999 | |
| 0.00 | 3.00 | 0.00 | 1.89 | -5.92 | 218.40 | 37.16 | 255.30 | 0.6234 | -682.0 | -592.3 | |
| 0.00 | 2.54 | 0.00 | 1.60 | -5.24 | 218.35 | 37.11 | 256.35 | 0.6205 | -568.0 | -461.1 | |
| 0.00 | 1.54 | 0.00 | 0.97 | -5.42 | 218.24 | 37.01 | 256.03 | 0.6197 | -640.0 | -545.5 | |
| 1.09 | -4.00 | 0.70 | -4.00 | -8.68 | 218.47 | 37.24 | 251.09 | 0.6345 | -508.4 | 999999 | |
| 0.00 | 3.36 | 0.00 | 2.14 | -8.12 | 218.33 | 37.09 | 251.88 | 0.6305 | 360.0 | 415.9 | |
| 1.54 | -4.00 | 0.98 | -4.00 | -7.18 | 218.20 | 36.96 | 253.26 | 0.6252 | -206.7 | 999999 | |
| 1.73 | -4.00 | 1.10 | -4.00 | -9.12 | 218.41 | 37.17 | 250.40 | 0.6355 | -585.7 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.66 | -13.21 | 219.02 | 37.79 | 244.77 | 0.6617 | -393.0 | -360.3 | |
| 1.00 | -4.00 | 0.63 | -4.00 | -6.43 | 218.05 | 36.82 | 254.37 | 0.6206 | -771.0 | 999999 | |
| 0.00 | 2.54 | 0.00 | 1.63 | -10.21 | 218.35 | 37.12 | 248.74 | 0.6395 | -495.0 | -418.9 | |
| 0.00 | 0.73 | 0.00 | 0.45 | -4.69 | 217.81 | 36.58 | 257.03 | 0.6117 | -497.0 | -434.2 | |
| 0.00 | 0.73 | 0.00 | 0.46 | -9.45 | 218.17 | 36.94 | 249.79 | 0.6340 | -581.0 | -499.0 | |
| 0.00 | 1.54 | 0.00 | 0.97 | -6.20 | 217.69 | 36.45 | 254.58 | 0.6150 | -905.0 | -767.4 | |
| 0.00 | 1.27 | 0.00 | 0.80 | -6.88 | 217.75 | 36.51 | 253.53 | 0.6182 | -334.0 | -273.4 | |
| 0.00 | 4.45 | 0.00 | 2.80 | -6.60 | 217.72 | 36.49 | 253.96 | 0.6169 | -624.0 | -528.3 | |
| 0.00 | 15.44 | 0.00 | 9.82 | -9.16 | 217.95 | 36.71 | 250.12 | 0.6298 | -735.0 | -598.9 | |
| 0.00 | 0.73 | 0.00 | 0.46 | -7.41 | 217.72 | 36.48 | 252.70 | 0.6198 | -432.0 | -356.4 | |
| 0.00 | 0.73 | 0.00 | 0.45 | -4.67 | 217.47 | 36.23 | 256.93 | 0.6070 | -666.0 | -596.0 | |
| 0.00 | 1.18 | 0.00 | 0.75 | -8.93 | 217.80 | 36.57 | 250.39 | 0.6270 | -773.0 | -686.1 | |
| 0.00 | 2.45 | 0.00 | 1.54 | -6.41 | 217.52 | 36.28 | 254.18 | 0.6134 | -661.0 | -709.0 | |
| 0.00 | 2.09 | 0.00 | 1.30 | -4.64 | 217.28 | 36.04 | 256.92 | 0.6043 | -775.0 | -656.8 | |
| 0.00 | 1.27 | 0.00 | 0.82 | -11.82 | 217.61 | 36.38 | 245.98 | 0.6378 | -681.0 | -531.2 | |
| 0.00 | 1.18 | 0.00 | 0.73 | -4.86 | 216.69 | 35.45 | 256.34 | 0.5970 | -608.0 | -457.2 | |
| 0.00 | 1.00 | 0.00 | 0.62 | -8.48 | 216.76 | 35.52 | 250.56 | 0.6116 | -751.0 | -597.8 | |
| 0.00 | 1.18 | 0.00 | 0.72 | -5.99 | 215.68 | 34.44 | 254.05 | 0.5871 | -693.0 | -607.3 | |
| 0.00 | 0.54 | 0.00 | 0.33 | -6.16 | 215.39 | 34.15 | 253.64 | 0.5839 | -486.0 | -471.5 | |
| 0.00 | 0.91 | 0.00 | 0.57 | -11.17 | 215.72 | 34.49 | 245.85 | 0.6110 | -486.0 | -406.7 | |
| 0.00 | 0.54 | 0.00 | 0.32 | -6.38 | 212.27 | 31.03 | 251.68 | 0.5418 | -681.0 | -536.5 | |
| 0.00 | 0.91 | 0.00 | 0.53 | -9.02 | 209.49 | 28.26 | 245.16 | 0.5172 | -672.0 | -557.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
