SDO HMI 2014-07-11 15:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 67.37 | 219.00 | 35.50 | 115.11 | 8.00 | 161.68 | -18.45 | 76.09 | 0.3233 | -296.8 | -138.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 15:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.73 | 8.39 | 171.99 | -8.14 | 60.92 | 0.1610 | -840.0 | -670.6 | |
| 0.00 | 2.18 | 0.00 | 1.09 | 7.62 | 171.29 | -8.84 | 67.01 | 0.1662 | -828.0 | -692.2 | |
| 2.72 | 6.81 | 1.37 | 3.42 | 7.56 | 171.04 | -9.09 | 67.90 | 0.1698 | -1152.0 | -877.3 | |
| 0.00 | 1.18 | 0.00 | 0.60 | 8.99 | 170.39 | -9.74 | 62.08 | 0.1900 | -885.0 | -651.1 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 7.64 | 170.35 | -9.77 | 68.82 | 0.1813 | -728.0 | -615.7 | |
| 0.00 | 1.00 | 0.00 | 0.50 | 9.05 | 170.04 | -10.09 | 62.61 | 0.1957 | -1053.0 | -897.3 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 9.07 | 169.69 | -10.44 | 63.24 | 0.2012 | -890.0 | -709.0 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 7.78 | 169.32 | -10.81 | 69.94 | 0.1987 | -950.0 | -718.4 | |
| 0.00 | 1.09 | 0.00 | 0.55 | 8.48 | 168.86 | -11.27 | 67.48 | 0.2101 | -792.0 | -565.8 | |
| 0.00 | 1.82 | 0.00 | 0.92 | 9.25 | 168.75 | -11.38 | 64.39 | 0.2170 | -1013.0 | -800.5 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 7.84 | 168.79 | -11.34 | 70.51 | 0.2076 | -881.0 | -698.1 | |
| 0.00 | 8.44 | 0.00 | 4.28 | 8.85 | 168.73 | -11.40 | 66.12 | 0.2146 | -1110.0 | -807.8 | |
| 0.00 | 1.63 | 0.00 | 0.83 | 9.18 | 168.05 | -12.08 | 65.91 | 0.2272 | -867.0 | -649.7 | |
| 9.17 | 16.89 | 4.66 | 8.59 | 5.47 | 167.12 | -13.01 | 82.87 | 0.2269 | -1139.4 | -675.2 | |
| 0.00 | 2.45 | 0.00 | 1.25 | 5.01 | 166.97 | -13.16 | 84.94 | 0.2287 | -1014.0 | -759.2 | |
| 0.00 | 0.64 | 0.00 | 0.32 | 9.06 | 166.73 | -13.40 | 68.36 | 0.2473 | 696.0 | 587.0 | |
| 0.00 | 1.18 | 0.00 | 0.60 | 7.96 | 166.70 | -13.43 | 72.69 | 0.2419 | -812.0 | -741.6 | |
| 0.00 | 3.00 | 0.00 | 1.53 | 6.38 | 166.75 | -13.38 | 79.17 | 0.2352 | -934.0 | -679.0 | |
| 0.00 | 0.82 | 0.00 | 0.42 | 6.13 | 166.69 | -13.44 | 80.24 | 0.2355 | -866.0 | -749.0 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 6.31 | 166.50 | -13.63 | 79.61 | 0.2392 | -769.0 | -608.0 | |
| 0.73 | 3.45 | 0.37 | 1.77 | 7.98 | 165.94 | -14.19 | 73.43 | 0.2543 | -1059.1 | -768.6 | |
| 3.63 | 19.16 | 1.87 | 9.86 | 8.46 | 164.97 | -15.16 | 72.67 | 0.2722 | -1094.2 | -709.1 | |
| 2.18 | 3.45 | 1.12 | 1.77 | 5.31 | 165.01 | -15.12 | 84.29 | 0.2622 | 972.5 | 762.5 | |
| 7.26 | -22.00 | 3.74 | -22.00 | 8.36 | 164.85 | -15.28 | 73.12 | 0.2737 | -1136.1 | 999999 | |
| 0.00 | 2.18 | 0.00 | 1.12 | 6.47 | 164.82 | -15.31 | 80.02 | 0.2676 | -967.0 | -718.9 | |
| 0.00 | 2.72 | 0.00 | 1.41 | 7.99 | 164.25 | -15.88 | 74.97 | 0.2817 | -800.0 | -534.4 | |
| 0.00 | 1.91 | 0.00 | 0.99 | 10.12 | 163.93 | -16.20 | 68.17 | 0.2971 | 994.0 | 857.4 | |
| 0.00 | 1.63 | 0.00 | 0.85 | 10.00 | 163.68 | -16.45 | 68.85 | 0.3003 | 998.0 | 814.9 | |
| 0.00 | 0.91 | 0.00 | 0.47 | 4.80 | 163.49 | -16.64 | 86.49 | 0.2871 | -703.0 | -622.3 | |
| 0.00 | 1.00 | 0.00 | 0.52 | 10.11 | 163.00 | -17.13 | 69.23 | 0.3115 | 765.0 | 543.2 | |
| 0.00 | 1.00 | 0.00 | 0.52 | 9.88 | 162.49 | -17.64 | 70.40 | 0.3183 | -561.0 | -503.6 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 8.81 | 162.55 | -17.58 | 73.63 | 0.3125 | -787.0 | -591.2 | |
| 0.00 | 3.45 | 0.00 | 1.81 | 11.60 | 162.26 | -17.87 | 65.64 | 0.3314 | 711.0 | 643.5 | |
| 0.00 | 12.62 | 0.00 | 6.57 | 5.41 | 162.16 | -17.97 | 84.67 | 0.3098 | -845.0 | -751.6 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 6.30 | 162.13 | -18.00 | 81.83 | 0.3116 | -884.0 | -636.2 | |
| 0.00 | 2.54 | 0.00 | 1.33 | 10.21 | 161.92 | -18.21 | 69.96 | 0.3288 | 1013.0 | 815.8 | |
| 0.00 | 2.45 | 0.00 | 1.29 | 9.37 | 161.67 | -18.46 | 72.61 | 0.3287 | 965.0 | 722.1 | |
| 0.00 | 1.45 | 0.00 | 0.76 | 10.63 | 161.47 | -18.66 | 69.17 | 0.3379 | 873.0 | 699.4 | |
| 0.00 | 2.09 | 0.00 | 1.10 | 9.44 | 160.39 | -19.74 | 73.38 | 0.3491 | -744.0 | -691.7 | |
| 0.00 | 1.54 | 0.00 | 0.82 | 9.86 | 160.17 | -19.96 | 72.37 | 0.3544 | -753.0 | -715.7 | |
| 24.70 | 39.50 | 13.14 | 21.03 | 8.25 | 159.05 | -21.08 | 77.45 | 0.3663 | -1038.9 | -510.1 | |
| 0.00 | 0.64 | 0.00 | 0.34 | 9.98 | 158.74 | -21.39 | 73.03 | 0.3771 | -614.0 | -480.3 | |
| 1.54 | -41.00 | 0.82 | -41.00 | 8.30 | 158.78 | -21.35 | 77.43 | 0.3707 | -651.2 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.58 | 7.86 | 158.11 | -22.02 | 78.90 | 0.3802 | 166.0 | 135.1 | |
| 0.00 | 0.82 | 0.00 | 0.44 | 7.48 | 157.89 | -22.24 | 79.95 | 0.3827 | -660.0 | -485.3 | |
| 0.91 | 6.08 | 0.49 | 3.29 | 9.08 | 156.90 | -23.23 | 76.33 | 0.4026 | 1032.4 | 855.3 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 7.86 | 156.91 | -23.22 | 79.35 | 0.3991 | 712.0 | 492.4 | |
| 0.00 | 2.72 | 0.00 | 1.48 | 9.38 | 156.74 | -23.39 | 75.67 | 0.4059 | 937.0 | 778.0 | |
| 1.00 | 2.36 | 0.54 | 1.28 | 7.39 | 156.60 | -23.53 | 80.61 | 0.4030 | 892.3 | 656.7 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 7.08 | 156.38 | -23.75 | 81.44 | 0.4059 | 684.0 | 628.2 | |
| 0.00 | 0.82 | 0.00 | 0.44 | 7.29 | 156.17 | -23.96 | 80.99 | 0.4096 | 857.0 | 745.2 | |
| 0.00 | 3.81 | 0.00 | 2.08 | 8.72 | 156.01 | -24.12 | 77.59 | 0.4153 | 684.0 | 733.8 | |
| 2.00 | 23.33 | 1.09 | 12.73 | 8.47 | 155.96 | -24.17 | 78.19 | 0.4155 | 1090.3 | 776.1 | |
| 0.00 | 6.17 | 0.00 | 3.36 | 9.12 | 155.92 | -24.21 | 76.69 | 0.4179 | 960.0 | 811.8 | |
| 3.81 | -53.00 | 2.08 | -53.00 | 8.53 | 155.69 | -24.44 | 78.17 | 0.4199 | 974.8 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.69 | 9.54 | 155.61 | -24.52 | 75.84 | 0.4238 | 768.0 | 671.8 | |
| 7.72 | -53.00 | 4.21 | -53.00 | 8.77 | 155.60 | -24.53 | 77.63 | 0.4218 | 984.5 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.80 | 6.87 | 154.46 | -25.67 | 82.38 | 0.4357 | 630.0 | 444.8 | |
| 0.00 | 1.18 | 0.00 | 0.65 | 4.75 | 153.92 | -26.21 | 87.29 | 0.4425 | 743.0 | 503.4 | |
| 0.00 | 1.00 | 0.00 | 0.58 | 8.60 | 148.94 | -31.19 | 79.96 | 0.5220 | 747.0 | 627.5 | |
| 0.00 | 1.82 | 0.00 | 1.06 | 8.71 | 148.68 | -31.45 | 79.80 | 0.5261 | 667.0 | 537.2 | |
| 0.00 | 1.36 | 0.00 | 0.79 | 9.16 | 148.42 | -31.71 | 79.01 | 0.5307 | 654.0 | 489.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
