SDO HMI 2014-07-11 16:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 193.20 | 1211.24 | 132.41 | 821.89 | -7.77 | 221.17 | 41.60 | 254.19 | 0.6858 | 831.4 | 313.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-11 16:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.99 | -8.80 | 225.25 | 45.67 | 254.18 | 0.7371 | 107.0 | 150.9 | |
| 0.00 | 1.72 | 0.00 | 1.23 | -6.67 | 224.35 | 44.77 | 256.75 | 0.7209 | 286.0 | 366.3 | |
| 0.00 | 1.27 | 0.00 | 0.90 | -6.52 | 223.77 | 44.19 | 256.79 | 0.7137 | 246.0 | 215.9 | |
| 0.00 | 1.27 | 0.00 | 0.89 | -4.94 | 223.61 | 44.04 | 258.94 | 0.7080 | 633.0 | 567.7 | |
| 1.36 | 3.18 | 0.95 | 2.22 | -5.12 | 223.59 | 44.01 | 258.68 | 0.7081 | 707.0 | 561.5 | |
| 0.00 | 2.54 | 0.00 | 1.79 | -6.85 | 223.68 | 44.10 | 256.30 | 0.7135 | -269.0 | -181.9 | |
| 0.00 | 0.82 | 0.00 | 0.57 | -5.08 | 223.37 | 43.79 | 258.68 | 0.7053 | 713.0 | 567.7 | |
| 0.00 | 1.18 | 0.00 | 0.83 | -6.47 | 223.42 | 43.84 | 256.76 | 0.7094 | 529.0 | 446.2 | |
| 1.82 | 869.18 | 1.27 | 597.24 | -6.74 | 223.19 | 43.62 | 256.32 | 0.7074 | -334.7 | 372.9 | |
| 4.45 | -9.00 | 3.06 | -9.00 | -6.39 | 222.44 | 42.86 | 256.57 | 0.6973 | -187.8 | 999999 | |
| 3.72 | 5.81 | 2.55 | 3.99 | -5.89 | 222.26 | 42.69 | 257.23 | 0.6938 | -435.1 | -248.6 | |
| 165.68 | -9.00 | 113.98 | -9.00 | -8.01 | 221.95 | 42.38 | 254.14 | 0.6961 | 1387.1 | 999999 | |
| 1.36 | -9.00 | 0.91 | -9.00 | -5.81 | 220.68 | 41.11 | 256.85 | 0.6740 | -344.7 | 999999 | |
| 0.00 | 2.36 | 0.00 | 1.59 | -9.73 | 220.17 | 40.59 | 251.03 | 0.6804 | 374.0 | 417.0 | |
| 0.00 | 1.27 | 0.00 | 0.83 | -5.69 | 219.42 | 39.85 | 256.61 | 0.6577 | -558.0 | -397.9 | |
| 0.00 | 1.91 | 0.00 | 1.27 | -8.90 | 219.68 | 40.11 | 252.02 | 0.6715 | 792.0 | 599.7 | |
| 0.00 | 1.54 | 0.00 | 1.02 | -6.77 | 219.40 | 39.82 | 255.00 | 0.6607 | 524.0 | 395.8 | |
| 3.18 | 244.48 | 2.11 | 160.02 | -8.11 | 219.50 | 39.93 | 253.08 | 0.6664 | 960.9 | 345.9 | |
| 2.00 | -18.00 | 1.31 | -18.00 | -6.02 | 219.21 | 39.63 | 256.05 | 0.6559 | -473.8 | 999999 | |
| 0.00 | 6.45 | 0.00 | 4.33 | -10.46 | 219.66 | 40.09 | 249.78 | 0.6771 | 227.0 | 199.7 | |
| 0.00 | 4.27 | 0.00 | 2.85 | -9.70 | 219.51 | 39.94 | 250.79 | 0.6723 | 250.0 | 203.6 | |
| 3.45 | -18.00 | 2.26 | -18.00 | -6.69 | 219.03 | 39.46 | 254.98 | 0.6558 | 637.8 | 999999 | |
| 0.00 | 1.82 | 0.00 | 1.22 | -10.93 | 219.58 | 40.00 | 249.09 | 0.6779 | -503.0 | -355.5 | |
| 0.00 | 1.18 | 0.00 | 0.79 | -9.88 | 219.33 | 39.76 | 250.46 | 0.6709 | -125.0 | -224.8 | |
| 0.00 | 1.00 | 0.00 | 0.67 | -11.37 | 219.57 | 39.99 | 248.46 | 0.6796 | -492.0 | -439.8 | |
| 0.00 | 1.00 | 0.00 | 0.67 | -10.42 | 219.37 | 39.80 | 249.72 | 0.6734 | -283.0 | -355.4 | |
| 2.09 | -18.00 | 1.37 | -18.00 | -7.09 | 218.91 | 39.34 | 254.35 | 0.6555 | 1041.2 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.73 | -10.73 | 219.38 | 39.81 | 249.28 | 0.6748 | -602.0 | -460.3 | |
| 0.82 | -18.00 | 0.53 | -18.00 | -6.12 | 218.66 | 39.09 | 255.71 | 0.6492 | -522.7 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.61 | -11.32 | 219.23 | 39.66 | 248.37 | 0.6755 | -586.0 | -548.0 | |
| 0.00 | 1.72 | 0.00 | 1.16 | -11.70 | 219.22 | 39.64 | 247.84 | 0.6769 | -738.0 | -603.6 | |
| 0.91 | 2.45 | 0.59 | 1.59 | -5.96 | 218.45 | 38.88 | 255.88 | 0.6460 | -709.3 | -569.7 | |
| 0.00 | 2.36 | 0.00 | 1.52 | -5.27 | 218.32 | 38.74 | 256.87 | 0.6422 | -569.0 | -475.1 | |
| 0.00 | 1.27 | 0.00 | 0.82 | -5.64 | 218.31 | 38.73 | 256.30 | 0.6431 | -523.0 | -422.1 | |
| 0.00 | 2.09 | 0.00 | 1.34 | -5.45 | 218.21 | 38.64 | 256.56 | 0.6413 | -726.0 | -634.7 | |
| 0.00 | 0.82 | 0.00 | 0.54 | -10.29 | 218.59 | 39.01 | 249.54 | 0.6634 | -390.0 | -314.1 | |
| 1.27 | -18.00 | 0.82 | -18.00 | -7.18 | 218.17 | 38.59 | 253.92 | 0.6463 | -100.1 | 999999 | |
| 1.09 | -18.00 | 0.70 | -18.00 | -6.37 | 218.09 | 38.52 | 255.11 | 0.6426 | -706.9 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.04 | -13.18 | 218.96 | 39.38 | 245.66 | 0.6804 | -522.0 | -448.9 | |
| 0.00 | 1.09 | 0.00 | 0.73 | -12.95 | 218.87 | 39.30 | 245.93 | 0.6783 | -589.0 | -559.6 | |
| 0.00 | 7.08 | 0.00 | 4.64 | -9.37 | 218.30 | 38.73 | 250.75 | 0.6561 | -329.0 | -313.9 | |
| 0.00 | 0.91 | 0.00 | 0.58 | -5.71 | 217.80 | 38.23 | 256.02 | 0.6368 | -725.0 | -617.4 | |
| 0.00 | 2.81 | 0.00 | 1.81 | -6.58 | 217.80 | 38.22 | 254.69 | 0.6395 | -449.0 | -449.0 | |
| 0.00 | 1.72 | 0.00 | 1.11 | -5.95 | 217.70 | 38.13 | 255.61 | 0.6362 | -698.0 | -530.4 | |
| 0.00 | 1.54 | 0.00 | 1.00 | -8.54 | 217.92 | 38.35 | 251.80 | 0.6481 | -534.0 | -490.5 | |
| 0.00 | 3.90 | 0.00 | 2.50 | -6.32 | 217.66 | 38.08 | 255.03 | 0.6368 | -790.0 | -738.2 | |
| 0.00 | 9.17 | 0.00 | 5.97 | -9.25 | 217.89 | 38.32 | 250.73 | 0.6505 | -500.0 | -606.5 | |
| 0.00 | 1.18 | 0.00 | 0.77 | -10.39 | 218.05 | 38.47 | 249.14 | 0.6571 | -445.0 | -444.1 | |
| 0.00 | 1.18 | 0.00 | 0.75 | -4.73 | 217.34 | 37.77 | 257.37 | 0.6278 | -729.0 | -600.2 | |
| 0.00 | 1.00 | 0.00 | 0.63 | -4.55 | 217.25 | 37.68 | 257.63 | 0.6260 | -687.0 | -535.0 | |
| 0.00 | 1.45 | 0.00 | 0.93 | -7.99 | 216.81 | 37.23 | 252.13 | 0.6318 | -429.0 | -329.2 | |
| 0.00 | 1.09 | 0.00 | 0.69 | -6.24 | 216.37 | 36.80 | 254.65 | 0.6197 | -268.0 | -295.0 | |
| 0.00 | 1.45 | 0.00 | 0.91 | -5.70 | 216.06 | 36.49 | 255.38 | 0.6137 | -532.0 | -467.4 | |
| 0.00 | 1.27 | 0.00 | 0.79 | -6.25 | 215.31 | 35.73 | 254.18 | 0.6056 | -740.0 | -669.2 | |
| 0.00 | 1.18 | 0.00 | 0.75 | -10.52 | 215.41 | 35.84 | 247.59 | 0.6249 | -157.0 | -198.4 | |
| 0.00 | 1.09 | 0.00 | 0.68 | -10.36 | 213.76 | 34.19 | 246.91 | 0.6031 | -656.0 | -569.9 | |
| 0.00 | 1.18 | 0.00 | 0.73 | -11.20 | 213.61 | 34.03 | 245.51 | 0.6055 | -717.0 | -596.7 | |
| 0.00 | 1.09 | 0.00 | 0.66 | -14.56 | 210.05 | 30.48 | 237.85 | 0.5820 | -499.0 | -448.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
