SDO HMI 2014-07-12 01:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 67.45 | 211.28 | 34.42 | 107.93 | 8.12 | 162.11 | -12.48 | 69.03 | 0.2285 | -236.0 | -203.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-12 01:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.41 | 8.30 | 172.64 | -1.95 | 24.32 | 0.0822 | -844.0 | -663.0 | |
| 0.00 | 1.36 | 0.00 | 0.68 | 8.66 | 172.51 | -2.08 | 23.86 | 0.0890 | -860.0 | -678.3 | |
| 0.00 | 1.27 | 0.00 | 0.63 | 7.71 | 172.02 | -2.57 | 34.51 | 0.0786 | -907.0 | -740.6 | |
| 0.64 | 1.82 | 0.32 | 0.90 | 7.44 | 171.50 | -3.09 | 41.79 | 0.0805 | -1059.3 | -892.8 | |
| 0.00 | 2.63 | 0.00 | 1.31 | 8.75 | 170.41 | -4.18 | 41.06 | 0.1101 | -1055.0 | -832.8 | |
| 0.00 | 1.45 | 0.00 | 0.72 | 8.01 | 169.56 | -5.03 | 51.19 | 0.1120 | -1047.0 | -770.2 | |
| 0.00 | 1.45 | 0.00 | 0.72 | 7.74 | 169.47 | -5.12 | 53.66 | 0.1103 | -958.0 | -748.2 | |
| 0.00 | 2.54 | 0.00 | 1.27 | 8.53 | 169.02 | -5.57 | 50.55 | 0.1248 | -820.0 | -927.1 | |
| 0.36 | 2.72 | 0.18 | 1.36 | 8.86 | 168.99 | -5.60 | 48.68 | 0.1290 | -1033.5 | -880.1 | |
| 0.00 | 1.45 | 0.00 | 0.73 | 8.62 | 168.87 | -5.72 | 50.75 | 0.1279 | -1090.0 | -920.6 | |
| 0.00 | 1.45 | 0.00 | 0.73 | 9.13 | 167.99 | -6.60 | 51.70 | 0.1452 | -819.0 | -627.1 | |
| 7.54 | 14.53 | 3.76 | 7.25 | 5.74 | 167.82 | -6.77 | 75.38 | 0.1217 | -1202.7 | -767.2 | |
| 4.09 | -12.00 | 2.04 | -12.00 | 5.90 | 167.73 | -6.86 | 74.37 | 0.1239 | -1169.0 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.77 | 5.38 | 167.61 | -6.98 | 78.69 | 0.1239 | -868.0 | -776.5 | |
| 0.00 | 1.09 | 0.00 | 0.54 | 6.14 | 167.35 | -7.23 | 73.33 | 0.1313 | -1044.0 | -880.6 | |
| 0.00 | 0.91 | 0.00 | 0.45 | 6.35 | 167.29 | -7.30 | 71.92 | 0.1334 | -1021.0 | -856.7 | |
| 0.00 | 2.27 | 0.00 | 1.13 | 6.10 | 167.17 | -7.42 | 73.94 | 0.1342 | -891.0 | -846.5 | |
| 0.00 | 2.36 | 0.00 | 1.18 | 6.44 | 166.98 | -7.61 | 71.97 | 0.1390 | -981.0 | -820.9 | |
| 2.36 | 5.08 | 1.19 | 2.55 | 9.06 | 166.65 | -7.93 | 56.99 | 0.1633 | 1068.1 | 793.4 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 10.32 | 166.53 | -8.06 | 51.33 | 0.1774 | -767.0 | -619.5 | |
| 2.63 | 7.45 | 1.32 | 3.73 | 7.05 | 166.57 | -8.02 | 68.89 | 0.1491 | -1164.7 | -525.5 | |
| 1.00 | 2.45 | 0.50 | 1.23 | 7.69 | 166.50 | -8.09 | 65.15 | 0.1545 | -1000.7 | -744.3 | |
| 0.00 | 1.18 | 0.00 | 0.59 | 9.21 | 166.46 | -8.12 | 56.82 | 0.1674 | 778.0 | 538.2 | |
| 0.00 | 1.27 | 0.00 | 0.64 | 7.86 | 165.96 | -8.62 | 65.46 | 0.1640 | -977.0 | -709.7 | |
| 0.00 | 5.54 | 0.00 | 2.79 | 7.31 | 165.20 | -9.39 | 70.20 | 0.1728 | -858.0 | -775.3 | |
| 4.99 | 21.06 | 2.52 | 10.61 | 8.40 | 165.05 | -9.54 | 64.72 | 0.1821 | -1060.0 | -821.3 | |
| 2.54 | -26.00 | 1.28 | -26.00 | 8.16 | 165.02 | -9.57 | 66.02 | 0.1809 | -1177.4 | 999999 | |
| 1.18 | 2.91 | 0.59 | 1.46 | 5.32 | 165.04 | -9.54 | 81.82 | 0.1675 | 1093.2 | 816.3 | |
| 0.00 | 1.73 | 0.00 | 0.87 | 7.82 | 164.81 | -9.78 | 68.19 | 0.1820 | -789.0 | -513.3 | |
| 1.27 | 2.09 | 0.64 | 1.05 | 5.11 | 164.83 | -9.76 | 83.24 | 0.1708 | 1030.4 | 830.7 | |
| 0.54 | 2.09 | 0.27 | 1.05 | 6.53 | 164.12 | -10.47 | 76.00 | 0.1869 | 1070.7 | 839.8 | |
| 0.00 | 2.63 | 0.00 | 1.34 | 10.23 | 163.71 | -10.88 | 59.51 | 0.2165 | 935.0 | 710.5 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 9.92 | 163.41 | -11.18 | 61.43 | 0.2185 | 856.0 | 681.6 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 10.37 | 163.14 | -11.45 | 60.16 | 0.2262 | 853.0 | 674.8 | |
| 0.00 | 2.09 | 0.00 | 1.07 | 12.49 | 163.02 | -11.57 | 52.78 | 0.2470 | 749.0 | 558.0 | |
| 0.00 | 1.73 | 0.00 | 0.88 | 8.78 | 162.91 | -11.68 | 67.14 | 0.2182 | -844.0 | -707.9 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 11.99 | 162.34 | -12.25 | 55.95 | 0.2515 | 965.0 | 753.4 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 5.20 | 162.46 | -12.13 | 83.95 | 0.2113 | -891.0 | -657.9 | |
| 0.00 | 2.91 | 0.00 | 1.47 | 6.05 | 162.22 | -12.36 | 80.12 | 0.2171 | -837.0 | -755.4 | |
| 0.00 | 2.09 | 0.00 | 1.07 | 10.17 | 161.91 | -12.68 | 63.26 | 0.2430 | 1137.0 | 980.9 | |
| 0.00 | 4.99 | 0.00 | 2.57 | 10.21 | 160.35 | -14.24 | 65.57 | 0.2671 | -533.0 | -694.9 | |
| 18.25 | 46.03 | 9.36 | 23.64 | 8.28 | 160.11 | -14.48 | 72.83 | 0.2602 | -1129.4 | -731.9 | |
| 0.00 | 1.18 | 0.00 | 0.61 | 8.88 | 159.67 | -14.92 | 71.10 | 0.2701 | -555.0 | -315.7 | |
| 5.99 | -42.00 | 3.08 | -42.00 | 8.27 | 159.57 | -15.02 | 73.40 | 0.2688 | -1013.5 | 999999 | |
| 2.18 | -42.00 | 1.12 | -42.00 | 8.42 | 159.15 | -15.44 | 73.28 | 0.2763 | -746.9 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.75 | 8.16 | 158.80 | -15.78 | 74.46 | 0.2807 | -758.0 | -387.6 | |
| 0.00 | 0.73 | 0.00 | 0.38 | 7.85 | 158.18 | -16.41 | 76.04 | 0.2897 | 794.0 | 665.9 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 8.04 | 157.01 | -17.58 | 76.22 | 0.3093 | 943.0 | 672.8 | |
| 0.00 | 0.82 | 0.00 | 0.43 | 9.01 | 156.48 | -18.11 | 73.60 | 0.3214 | 957.0 | 800.2 | |
| 2.54 | 4.09 | 1.33 | 2.14 | 9.49 | 156.26 | -18.33 | 72.32 | 0.3270 | 1044.2 | 859.6 | |
| 0.00 | 1.45 | 0.00 | 0.76 | 8.73 | 156.17 | -18.42 | 74.68 | 0.3253 | 921.0 | 594.8 | |
| 0.00 | 3.63 | 0.00 | 1.90 | 7.35 | 156.07 | -18.52 | 78.93 | 0.3224 | 1129.0 | 844.2 | |
| 0.00 | 2.36 | 0.00 | 1.24 | 8.81 | 156.00 | -18.59 | 74.53 | 0.3283 | 1231.0 | 938.2 | |
| 0.00 | 1.00 | 0.00 | 0.52 | 7.62 | 155.83 | -18.76 | 78.22 | 0.3270 | 791.0 | 660.0 | |
| 0.00 | 2.09 | 0.00 | 1.10 | 8.78 | 155.74 | -18.85 | 74.81 | 0.3322 | 699.0 | 664.6 | |
| 0.00 | 0.91 | 0.00 | 0.48 | 5.18 | 155.79 | -18.80 | 85.74 | 0.3232 | 844.0 | 686.1 | |
| 0.00 | 1.45 | 0.00 | 0.76 | 7.86 | 155.59 | -19.00 | 77.63 | 0.3316 | 832.0 | 665.2 | |
| 5.36 | 12.08 | 2.82 | 6.36 | 9.20 | 155.33 | -19.26 | 73.88 | 0.3404 | 1050.6 | 567.2 | |
| 3.99 | -58.00 | 2.10 | -58.00 | 9.04 | 155.27 | -19.32 | 74.36 | 0.3407 | 1099.5 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.77 | 8.97 | 154.88 | -19.71 | 74.81 | 0.3466 | 947.0 | 735.6 | |
| 0.00 | 1.36 | 0.00 | 0.72 | 6.25 | 154.81 | -19.78 | 82.70 | 0.3405 | 781.0 | 553.6 | |
| 0.00 | 2.91 | 0.00 | 1.54 | 9.02 | 154.16 | -20.43 | 75.14 | 0.3583 | 584.0 | 675.9 | |
| 0.00 | 1.18 | 0.00 | 0.63 | 12.42 | 153.78 | -20.80 | 66.54 | 0.3797 | 851.0 | 660.0 | |
| 0.00 | 2.72 | 0.00 | 1.44 | 7.06 | 153.90 | -20.69 | 80.70 | 0.3569 | 628.0 | 690.2 | |
| 0.00 | 3.00 | 0.00 | 1.65 | 8.91 | 148.89 | -25.70 | 77.86 | 0.4400 | 695.0 | 586.1 | |
| 0.00 | 1.09 | 0.00 | 0.60 | 8.66 | 148.74 | -25.85 | 78.48 | 0.4417 | 630.0 | 462.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
