SDO HMI 2014-07-12 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 135.87 | 814.43 | 125.07 | 744.51 | -7.89 | 221.29 | 56.06 | 257.88 | 0.8423 | 756.0 | 253.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-12 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.54 | 3.99 | 0.51 | 3.73 | -5.57 | 222.36 | 57.13 | 260.82 | 0.8489 | -301.5 | -8.5 | |
| 117.36 | 623.83 | 109.68 | 582.14 | -7.93 | 222.06 | 56.82 | 258.00 | 0.8496 | 1161.8 | 280.7 | |
| 0.00 | 0.54 | 0.00 | 0.49 | -6.01 | 221.03 | 55.80 | 260.06 | 0.8372 | 261.0 | 298.2 | |
| 0.00 | 1.09 | 0.00 | 0.95 | -6.25 | 219.88 | 54.65 | 259.55 | 0.8266 | -92.0 | -46.8 | |
| 0.00 | 1.54 | 0.00 | 1.34 | -5.68 | 219.69 | 54.46 | 260.20 | 0.8239 | -85.0 | -125.3 | |
| 0.00 | 2.36 | 0.00 | 2.08 | -7.37 | 219.85 | 54.62 | 258.22 | 0.8282 | 225.0 | 262.8 | |
| 0.00 | 0.45 | 0.00 | 0.41 | -9.41 | 220.28 | 55.05 | 255.89 | 0.8359 | 450.0 | 469.2 | |
| 0.00 | 1.63 | 0.00 | 1.41 | -4.90 | 219.43 | 54.20 | 261.10 | 0.8201 | -459.0 | -384.5 | |
| 0.00 | 0.82 | 0.00 | 0.75 | -11.07 | 220.66 | 55.43 | 254.05 | 0.8426 | -175.0 | -282.9 | |
| 0.91 | 33.49 | 0.79 | 29.04 | -8.24 | 219.44 | 54.21 | 257.08 | 0.8257 | 697.5 | 373.7 | |
| 0.45 | 1.63 | 0.39 | 1.39 | -5.30 | 218.91 | 53.67 | 260.52 | 0.8155 | -313.8 | -324.5 | |
| 4.45 | 82.69 | 3.80 | 70.39 | -5.98 | 218.89 | 53.66 | 259.69 | 0.8165 | -237.8 | 267.4 | |
| 0.36 | -12.00 | 0.31 | -12.00 | -5.57 | 218.84 | 53.61 | 260.17 | 0.8152 | -417.8 | 999999 | |
| 0.00 | 2.36 | 0.00 | 2.03 | -7.44 | 219.07 | 53.84 | 257.96 | 0.8208 | 424.0 | 399.2 | |
| 2.45 | 17.79 | 2.17 | 15.62 | -10.03 | 219.57 | 54.34 | 254.99 | 0.8304 | 743.3 | 276.8 | |
| 1.27 | -10.00 | 1.11 | -10.00 | -8.60 | 219.19 | 53.96 | 256.60 | 0.8241 | 421.9 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.69 | -5.56 | 218.63 | 53.40 | 260.14 | 0.8131 | -363.0 | -412.3 | |
| 2.27 | -12.00 | 1.94 | -12.00 | -7.15 | 218.76 | 53.53 | 258.25 | 0.8172 | 938.2 | 999999 | |
| 0.00 | 1.27 | 0.00 | 1.15 | -12.78 | 219.87 | 54.63 | 251.84 | 0.8390 | -249.0 | -224.1 | |
| 0.00 | 0.91 | 0.00 | 0.78 | -8.61 | 218.77 | 53.54 | 256.49 | 0.8200 | -130.0 | -119.9 | |
| 0.00 | 0.91 | 0.00 | 0.76 | -5.04 | 218.10 | 52.87 | 260.68 | 0.8070 | -414.0 | -387.3 | |
| 0.00 | 1.82 | 0.00 | 1.55 | -8.19 | 218.54 | 53.30 | 256.94 | 0.8169 | -235.0 | -60.2 | |
| 0.00 | 1.36 | 0.00 | 1.16 | -8.40 | 218.53 | 53.29 | 256.68 | 0.8172 | -246.0 | -294.8 | |
| 0.00 | 1.45 | 0.00 | 1.25 | -9.69 | 218.70 | 53.47 | 255.17 | 0.8215 | -209.0 | -91.2 | |
| 0.00 | 1.27 | 0.00 | 1.08 | -8.39 | 218.32 | 53.09 | 256.64 | 0.8151 | -214.0 | -245.0 | |
| 0.00 | 1.09 | 0.00 | 0.93 | -8.64 | 218.31 | 53.08 | 256.34 | 0.8156 | -331.0 | -340.8 | |
| 0.00 | 1.18 | 0.00 | 0.99 | -7.48 | 218.04 | 52.81 | 257.69 | 0.8107 | -47.0 | -65.7 | |
| 0.00 | 0.27 | 0.00 | 0.23 | -8.32 | 218.10 | 52.86 | 256.68 | 0.8128 | -389.0 | -355.0 | |
| 0.00 | 3.00 | 0.00 | 2.65 | -12.61 | 219.06 | 53.83 | 251.82 | 0.8313 | -657.0 | -469.0 | |
| 0.00 | 2.00 | 0.00 | 1.75 | -12.33 | 218.66 | 53.43 | 252.04 | 0.8269 | -288.0 | -325.3 | |
| 0.00 | 0.27 | 0.00 | 0.23 | -8.32 | 217.59 | 52.35 | 256.56 | 0.8077 | -582.0 | -597.7 | |
| 0.00 | 1.09 | 0.00 | 0.90 | -8.08 | 217.29 | 52.06 | 256.77 | 0.8043 | -290.0 | -358.7 | |
| 0.00 | 1.18 | 0.00 | 0.99 | -9.06 | 217.43 | 52.20 | 255.62 | 0.8077 | -367.0 | -433.3 | |
| 0.00 | 0.82 | 0.00 | 0.68 | -8.90 | 217.34 | 52.11 | 255.80 | 0.8065 | -482.0 | -502.7 | |
| 0.00 | 1.00 | 0.00 | 0.81 | -6.26 | 216.85 | 51.62 | 258.92 | 0.7962 | -199.0 | -294.0 | |
| 0.00 | 0.91 | 0.00 | 0.74 | -6.56 | 216.64 | 51.41 | 258.50 | 0.7946 | -124.0 | -184.9 | |
| 0.00 | 1.18 | 0.00 | 0.96 | -6.95 | 216.40 | 51.17 | 257.97 | 0.7929 | -126.0 | -263.8 | |
| 0.00 | 1.00 | 0.00 | 0.79 | -7.47 | 215.22 | 49.99 | 257.03 | 0.7815 | -542.0 | -356.2 | |
| 0.00 | 1.91 | 0.00 | 1.45 | -6.94 | 213.49 | 48.26 | 257.26 | 0.7617 | -482.0 | -331.4 | |
| 0.45 | 1.45 | 0.35 | 1.13 | -12.24 | 213.14 | 47.91 | 250.42 | 0.7719 | 599.4 | 539.2 | |
| 0.00 | 1.72 | 0.00 | 1.28 | -6.61 | 212.08 | 46.85 | 257.31 | 0.7451 | -349.0 | -394.4 | |
| 0.00 | 1.27 | 0.00 | 0.99 | -13.07 | 213.25 | 48.02 | 249.43 | 0.7757 | 426.0 | 359.8 | |
| 0.00 | 0.27 | 0.00 | 0.21 | -12.35 | 212.84 | 47.61 | 250.18 | 0.7691 | 289.0 | 414.7 | |
| 5.36 | 8.80 | 4.02 | 6.61 | -12.45 | 211.30 | 46.07 | 249.48 | 0.7532 | -700.1 | -422.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
