SDO HMI 2014-07-12 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 89.48 | 402.38 | 213.53 | 1046.63 | -7.26 | 241.46 | 78.45 | 261.77 | 0.9807 | -10.4 | 76.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-12 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.14 | 203.68 | 86.01 | 684.23 | -7.35 | 243.94 | 80.93 | 261.93 | 0.9898 | 191.5 | 182.1 | |
| 6.44 | -1.00 | 22.92 | -1.00 | -8.87 | 244.33 | 81.32 | 260.45 | 0.9911 | 30.1 | 999999 | |
| 2.45 | 7.99 | 5.76 | 18.84 | -4.94 | 240.39 | 77.38 | 264.05 | 0.9784 | 345.9 | 288.2 | |
| 0.36 | 3.09 | 0.72 | 6.13 | -4.31 | 238.08 | 75.07 | 264.47 | 0.9691 | -219.5 | -96.7 | |
| 1.45 | 4.27 | 2.81 | 8.27 | -4.75 | 237.73 | 74.72 | 263.98 | 0.9678 | -340.9 | -178.3 | |
| 0.00 | 0.91 | 0.00 | 1.88 | -7.79 | 238.39 | 75.38 | 260.93 | 0.9719 | 78.0 | 134.9 | |
| 9.89 | 60.27 | 18.98 | 114.16 | -6.58 | 237.46 | 74.44 | 262.07 | 0.9674 | -516.7 | -88.5 | |
| 0.00 | 0.36 | 0.00 | 0.73 | -7.67 | 237.96 | 74.95 | 261.00 | 0.9701 | 197.0 | 211.0 | |
| 12.43 | -7.00 | 22.99 | -7.00 | -5.46 | 236.92 | 73.91 | 263.16 | 0.9645 | 324.4 | 999999 | |
| 14.98 | 74.70 | 28.34 | 140.66 | -7.98 | 237.06 | 74.05 | 260.59 | 0.9663 | -436.6 | -251.4 | |
| 0.27 | 10.98 | 0.47 | 18.99 | -5.15 | 235.95 | 72.94 | 263.39 | 0.9598 | 62.7 | 248.4 | |
| 3.45 | -11.00 | 5.97 | -11.00 | -5.42 | 235.82 | 72.81 | 263.09 | 0.9593 | 379.4 | 999999 | |
| 11.35 | 27.14 | 16.71 | 39.73 | -4.94 | 232.87 | 69.86 | 263.27 | 0.9433 | -413.6 | -357.9 | |
| 1.27 | 6.90 | 1.85 | 10.05 | -5.59 | 232.50 | 69.49 | 262.54 | 0.9416 | -394.1 | -324.5 | |
| 0.00 | 2.09 | 0.00 | 2.96 | -5.46 | 231.94 | 68.93 | 262.61 | 0.9382 | -561.0 | -431.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
