SDO HMI 2014-07-13 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.80 | 55.13 | 9.89 | 38.80 | 6.37 | 203.86 | 45.25 | 274.93 | 0.7090 | -78.4 | -119.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-13 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.64 | 0.00 | 0.48 | 4.94 | 208.21 | 49.60 | 272.96 | 0.7620 | -292.0 | -368.1 | |
| 0.00 | 1.00 | 0.00 | 0.76 | 4.98 | 207.93 | 49.32 | 273.01 | 0.7588 | -309.0 | -407.3 | |
| 0.00 | 0.73 | 0.00 | 0.55 | 4.35 | 207.78 | 49.17 | 272.17 | 0.7572 | 544.0 | 469.9 | |
| 0.00 | 2.63 | 0.00 | 1.99 | 5.21 | 207.81 | 49.20 | 273.30 | 0.7574 | -600.0 | -473.9 | |
| 0.00 | 3.09 | 0.00 | 2.29 | 5.84 | 206.86 | 48.25 | 274.13 | 0.7464 | -279.0 | -338.9 | |
| 1.91 | 18.17 | 1.41 | 13.40 | 6.00 | 206.78 | 48.17 | 274.34 | 0.7455 | -638.8 | -523.0 | |
| 7.63 | -6.00 | 5.62 | -6.00 | 6.11 | 206.47 | 47.86 | 274.49 | 0.7419 | -820.3 | 999999 | |
| 0.00 | 0.45 | 0.00 | 0.33 | 4.84 | 206.11 | 47.50 | 272.76 | 0.7378 | -345.0 | -366.6 | |
| 0.00 | 2.72 | 0.00 | 1.98 | 5.65 | 205.92 | 47.31 | 273.86 | 0.7354 | -704.0 | -582.0 | |
| 0.00 | 2.00 | 0.00 | 1.43 | 6.16 | 204.85 | 46.24 | 274.56 | 0.7227 | -678.0 | -561.3 | |
| 0.00 | 1.27 | 0.00 | 0.91 | 4.97 | 204.73 | 46.12 | 272.91 | 0.7213 | -568.0 | -367.8 | |
| 0.00 | 0.82 | 0.00 | 0.58 | 8.49 | 204.86 | 46.25 | 277.79 | 0.7234 | 513.0 | 388.8 | |
| 1.45 | 2.72 | 1.04 | 1.95 | 9.23 | 204.76 | 46.15 | 278.83 | 0.7226 | 624.3 | 453.6 | |
| 0.45 | 2.00 | 0.32 | 1.42 | 8.29 | 204.56 | 45.95 | 277.53 | 0.7197 | 462.4 | 363.1 | |
| 0.36 | 1.36 | 0.25 | 0.95 | 6.44 | 203.57 | 44.95 | 274.97 | 0.7070 | -577.8 | -497.5 | |
| 0.00 | 0.82 | 0.00 | 0.53 | 7.66 | 199.33 | 40.72 | 276.94 | 0.6536 | 661.0 | 535.4 | |
| 0.00 | 2.45 | 0.00 | 1.59 | 6.67 | 199.02 | 40.41 | 275.42 | 0.6490 | 634.0 | 462.9 | |
| 0.00 | 1.09 | 0.00 | 0.69 | 5.19 | 197.34 | 38.73 | 273.12 | 0.6262 | 629.0 | 483.7 | |
| 0.00 | 1.54 | 0.00 | 0.97 | 5.63 | 197.02 | 38.41 | 273.84 | 0.6219 | 412.0 | 361.4 | |
| 0.00 | 0.36 | 0.00 | 0.23 | 6.49 | 197.01 | 38.40 | 275.22 | 0.6220 | 564.0 | 444.0 | |
| 0.00 | 0.91 | 0.00 | 0.57 | 5.98 | 196.77 | 38.16 | 274.40 | 0.6186 | 578.0 | 510.3 | |
| 0.00 | 1.91 | 0.00 | 1.20 | 6.16 | 196.75 | 38.14 | 274.70 | 0.6183 | 716.0 | 603.2 | |
| 2.00 | 4.00 | 1.25 | 2.49 | 8.28 | 195.99 | 37.38 | 278.21 | 0.6092 | 853.1 | 693.2 | |
| 0.00 | 1.45 | 0.00 | 0.90 | 7.00 | 195.74 | 37.13 | 276.13 | 0.6047 | -447.0 | -438.3 | |
| 0.00 | 1.00 | 0.00 | 0.61 | 5.52 | 194.69 | 36.08 | 273.69 | 0.5896 | 455.0 | 382.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
