SDO HMI 2014-07-14 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 44.87 | 246.96 | 113.37 | 620.36 | -7.74 | 222.11 | 77.83 | 261.22 | 0.9809 | 445.4 | 142.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-14 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 44.87 | 233.88 | 113.37 | 594.24 | -7.73 | 222.24 | 77.96 | 261.24 | 0.9814 | 463.5 | 146.3 | |
| 0.00 | 3.45 | 0.00 | 6.97 | -6.38 | 219.50 | 75.22 | 262.32 | 0.9707 | -367.0 | -257.9 | |
| 0.00 | 3.09 | 0.00 | 6.09 | -6.75 | 219.06 | 74.78 | 261.89 | 0.9690 | 150.0 | 116.1 | |
| 0.00 | 1.27 | 0.00 | 2.45 | -7.00 | 218.70 | 74.42 | 261.59 | 0.9676 | 326.0 | 323.4 | |
| 0.00 | 3.27 | 0.00 | 6.70 | -9.35 | 219.35 | 75.07 | 259.26 | 0.9715 | 296.0 | 296.6 | |
| 0.00 | 0.73 | 0.00 | 1.43 | -10.05 | 218.72 | 74.44 | 258.46 | 0.9692 | 75.0 | 35.1 | |
| 0.00 | 1.27 | 0.00 | 2.48 | -10.28 | 218.52 | 74.24 | 258.20 | 0.9685 | 134.0 | 99.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
