SDO HMI 2014-07-18 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.88 | 47.91 | 6.49 | 26.22 | 6.66 | 111.65 | 25.26 | 275.77 | 0.4278 | 32.6 | 497.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-18 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.09 | 0.00 | 0.61 | 7.31 | 114.38 | 27.99 | 276.85 | 0.4707 | -840.0 | -733.0 | |
| 0.00 | 1.27 | 0.00 | 0.71 | 7.07 | 114.26 | 27.87 | 276.35 | 0.4686 | -909.0 | -720.7 | |
| 0.00 | 1.09 | 0.00 | 0.61 | 6.78 | 113.93 | 27.54 | 275.76 | 0.4633 | -842.0 | -646.2 | |
| 0.00 | 1.18 | 0.00 | 0.65 | 6.66 | 113.09 | 26.70 | 275.59 | 0.4503 | -932.0 | -700.1 | |
| 0.00 | 1.09 | 0.00 | 0.60 | 6.88 | 112.97 | 26.58 | 276.09 | 0.4485 | -917.0 | -760.4 | |
| 0.00 | 1.18 | 0.00 | 0.65 | 6.42 | 112.90 | 26.52 | 275.08 | 0.4472 | -794.0 | -607.1 | |
| 0.00 | 1.09 | 0.00 | 0.60 | 7.28 | 112.92 | 26.53 | 276.99 | 0.4483 | -830.0 | -724.2 | |
| 4.08 | 39.92 | 2.24 | 21.79 | 6.34 | 111.67 | 25.28 | 275.03 | 0.4279 | 905.1 | 844.6 | |
| 4.99 | -8.00 | 2.72 | -8.00 | 6.91 | 111.09 | 24.70 | 276.45 | 0.4193 | 1006.9 | 999999 | |
| 2.81 | -8.00 | 1.53 | -8.00 | 6.46 | 111.03 | 24.65 | 275.37 | 0.4179 | 1135.7 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
