SDO HMI 2014-07-18 19:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.35 | 21.50 | 3.68 | 12.54 | -21.94 | 67.37 | -17.91 | 147.32 | 0.5300 | 116.8 | -53.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-18 19:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.90 | 8.71 | 1.68 | 5.05 | -21.81 | 68.48 | -16.80 | 148.77 | 0.5195 | 1043.2 | 727.4 | |
| 2.54 | -1.00 | 1.47 | -1.00 | -22.05 | 68.42 | -16.86 | 148.93 | 0.5230 | 771.6 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.63 | -21.58 | 68.30 | -16.98 | 148.25 | 0.5180 | 1016.0 | 830.7 | |
| 0.00 | 0.63 | 0.00 | 0.37 | -22.23 | 68.12 | -17.16 | 148.68 | 0.5275 | 651.0 | 572.6 | |
| 0.00 | 1.45 | 0.00 | 0.84 | -21.72 | 68.15 | -17.13 | 148.17 | 0.5209 | 860.0 | 638.9 | |
| 0.00 | 0.73 | 0.00 | 0.42 | -21.99 | 66.94 | -18.34 | 146.73 | 0.5338 | -611.0 | -487.0 | |
| 0.00 | 1.09 | 0.00 | 0.64 | -22.09 | 66.72 | -18.56 | 146.54 | 0.5369 | -729.0 | -556.0 | |
| 0.00 | 2.36 | 0.00 | 1.39 | -22.01 | 66.17 | -19.10 | 145.69 | 0.5404 | -854.0 | -594.9 | |
| 0.00 | 2.63 | 0.00 | 1.55 | -22.18 | 65.94 | -19.34 | 145.57 | 0.5444 | -744.0 | -668.6 | |
| 0.91 | 2.18 | 0.53 | 1.28 | -21.78 | 65.86 | -19.42 | 144.99 | 0.5403 | -893.7 | -717.9 | |
| 0.00 | 0.63 | 0.00 | 0.37 | -22.09 | 65.74 | -19.53 | 145.19 | 0.5449 | -638.0 | -436.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
