SDO HMI 2014-07-19 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.15 | 70.63 | 14.17 | 39.94 | -21.76 | 67.75 | -11.46 | 157.51 | 0.4835 | 482.1 | -91.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-19 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.72 | 41.85 | 2.09 | 23.53 | -21.70 | 69.23 | -9.98 | 160.05 | 0.4740 | 996.5 | 583.9 | |
| 1.91 | -1.00 | 1.07 | -1.00 | -21.83 | 69.22 | -9.99 | 160.13 | 0.4760 | 775.1 | 999999 | |
| 4.27 | -1.00 | 2.40 | -1.00 | -21.80 | 68.86 | -10.36 | 159.45 | 0.4775 | 749.7 | 999999 | |
| 10.71 | -1.00 | 6.02 | -1.00 | -21.46 | 68.88 | -10.33 | 159.22 | 0.4725 | 1102.9 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.46 | -21.91 | 68.38 | -10.83 | 158.68 | 0.4817 | 500.0 | 305.8 | |
| 1.91 | 21.51 | 1.09 | 12.26 | -22.09 | 66.28 | -12.93 | 155.21 | 0.4966 | -892.8 | -750.7 | |
| 0.00 | 1.82 | 0.00 | 1.04 | -22.33 | 65.89 | -13.33 | 154.78 | 0.5024 | -632.0 | -565.4 | |
| 2.18 | -6.00 | 1.24 | -6.00 | -21.75 | 65.81 | -13.41 | 154.11 | 0.4952 | -920.9 | 999999 | |
| 0.45 | 4.63 | 0.26 | 2.65 | -22.13 | 65.53 | -13.68 | 154.02 | 0.5021 | -656.0 | -601.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
