SDO HMI 2014-07-21 00:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 61.13 | 225.40 | 34.50 | 127.45 | -21.20 | 68.31 | 12.26 | 204.30 | 0.4833 | 86.0 | 161.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-21 00:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.22 | 151.84 | 13.72 | 86.12 | -20.96 | 69.55 | 13.50 | 206.70 | 0.4872 | 1210.3 | 333.6 | |
| 4.54 | -1.00 | 2.58 | -1.00 | -21.30 | 69.55 | 13.50 | 206.37 | 0.4917 | 931.9 | 999999 | |
| 2.81 | -1.00 | 1.59 | -1.00 | -21.22 | 69.14 | 13.09 | 205.75 | 0.4879 | 760.2 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -20.41 | 69.07 | 13.02 | 206.42 | 0.4764 | 792.0 | 616.2 | |
| 2.18 | 10.43 | 1.22 | 5.83 | -19.96 | 68.43 | 12.38 | 205.74 | 0.4660 | 1063.0 | 682.8 | |
| 2.27 | -5.00 | 1.27 | -5.00 | -20.05 | 68.14 | 12.09 | 205.12 | 0.4653 | 733.0 | 999999 | |
| 0.00 | 3.63 | 0.00 | 2.05 | -21.53 | 67.62 | 11.58 | 202.85 | 0.4827 | 708.0 | 682.8 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -22.30 | 66.68 | 10.63 | 200.55 | 0.4881 | -716.0 | -502.5 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -22.26 | 66.51 | 10.46 | 200.28 | 0.4867 | -490.0 | -492.7 | |
| 0.63 | 1.54 | 0.35 | 0.86 | -20.62 | 65.90 | 9.85 | 200.46 | 0.4599 | -864.6 | -737.3 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -22.25 | 65.87 | 9.82 | 199.16 | 0.4833 | -807.0 | -660.0 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -22.45 | 65.89 | 9.84 | 199.03 | 0.4863 | -674.0 | -566.6 | |
| 1.45 | 3.27 | 0.81 | 1.83 | -21.46 | 65.69 | 9.64 | 199.40 | 0.4710 | -903.4 | -755.8 | |
| 0.00 | 0.63 | 0.00 | 0.36 | -22.42 | 65.68 | 9.64 | 198.69 | 0.4847 | -672.0 | -590.1 | |
| 0.00 | 1.81 | 0.00 | 1.02 | -21.25 | 65.57 | 9.53 | 199.35 | 0.4674 | -978.0 | -802.9 | |
| 0.00 | 1.27 | 0.00 | 0.71 | -21.76 | 65.57 | 9.53 | 198.97 | 0.4748 | -552.0 | -540.4 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -21.32 | 65.38 | 9.33 | 198.93 | 0.4674 | -591.0 | -698.2 | |
| 3.08 | 44.26 | 1.74 | 24.88 | -22.00 | 65.32 | 9.27 | 198.33 | 0.4770 | -857.9 | -625.5 | |
| 2.54 | -18.00 | 1.43 | -18.00 | -22.03 | 65.09 | 9.04 | 197.89 | 0.4763 | -934.1 | 999999 | |
| 7.98 | -18.00 | 4.48 | -18.00 | -21.69 | 65.04 | 8.99 | 198.03 | 0.4711 | -1107.2 | 999999 | |
| 1.45 | -18.00 | 0.82 | -18.00 | -22.30 | 64.84 | 8.79 | 197.24 | 0.4791 | -645.7 | 999999 | |
| 7.98 | -18.00 | 4.49 | -18.00 | -22.02 | 64.79 | 8.74 | 197.34 | 0.4748 | -965.9 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
