SDO HMI 2014-07-21 02:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 57.22 | 214.85 | 32.46 | 122.04 | -21.16 | 68.34 | 13.40 | 206.27 | 0.4901 | 235.7 | 120.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-21 02:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.57 | 143.62 | 17.42 | 81.88 | -20.98 | 69.60 | 14.65 | 208.58 | 0.4957 | 1123.0 | 308.5 | |
| 0.00 | 0.82 | 0.00 | 0.46 | -20.36 | 69.10 | 14.16 | 208.40 | 0.4840 | 668.0 | 580.3 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -20.15 | 69.08 | 14.14 | 208.58 | 0.4811 | 764.0 | 527.3 | |
| 2.81 | -1.00 | 1.60 | -1.00 | -21.20 | 69.12 | 14.17 | 207.56 | 0.4952 | 735.7 | 999999 | |
| 1.72 | 3.27 | 0.97 | 1.84 | -19.97 | 68.57 | 13.62 | 207.89 | 0.4750 | 1013.9 | 841.8 | |
| 2.90 | 6.26 | 1.63 | 3.52 | -19.97 | 68.23 | 13.29 | 207.32 | 0.4725 | 886.6 | 680.9 | |
| 1.18 | 5.26 | 0.67 | 2.98 | -21.54 | 67.63 | 12.69 | 204.75 | 0.4899 | 809.2 | 673.0 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -22.34 | 66.59 | 11.65 | 202.27 | 0.4946 | -641.0 | -564.4 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -20.20 | 66.36 | 11.41 | 203.73 | 0.4632 | -797.0 | -593.6 | |
| 0.54 | 1.54 | 0.30 | 0.86 | -20.63 | 65.86 | 10.91 | 202.43 | 0.4662 | -871.2 | -760.8 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -20.83 | 65.84 | 10.89 | 202.22 | 0.4690 | -587.0 | -525.8 | |
| 2.18 | 3.54 | 1.23 | 1.99 | -21.47 | 65.62 | 10.67 | 201.28 | 0.4768 | -857.9 | -624.3 | |
| 0.36 | 1.45 | 0.20 | 0.82 | -21.23 | 65.54 | 10.59 | 201.32 | 0.4730 | -940.0 | -743.2 | |
| 0.00 | 0.64 | 0.00 | 0.36 | -22.46 | 65.59 | 10.65 | 200.45 | 0.4907 | -486.0 | -413.6 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -21.77 | 65.48 | 10.53 | 200.78 | 0.4803 | -704.0 | -601.0 | |
| 2.81 | 43.09 | 1.59 | 24.31 | -21.97 | 65.26 | 10.31 | 200.22 | 0.4820 | -917.5 | -624.3 | |
| 8.07 | -16.00 | 4.55 | -16.00 | -21.83 | 64.98 | 10.03 | 199.83 | 0.4786 | -1108.6 | 999999 | |
| 4.08 | -16.00 | 2.30 | -16.00 | -22.00 | 64.76 | 9.81 | 199.31 | 0.4798 | -1017.0 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
