SDO HMI 2014-07-22 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.85 | 93.47 | 15.63 | 66.88 | -20.98 | 69.34 | 38.65 | 234.18 | 0.7213 | 596.2 | 190.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-22 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.87 | 84.68 | 11.40 | 60.87 | -21.00 | 69.85 | 39.16 | 234.50 | 0.7264 | 951.6 | 236.6 | |
| 4.26 | -1.00 | 3.02 | -1.00 | -20.78 | 68.94 | 38.25 | 234.18 | 0.7161 | 816.0 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.63 | -19.55 | 67.98 | 37.28 | 235.04 | 0.6988 | 628.0 | 444.7 | |
| 1.72 | 3.17 | 1.21 | 2.22 | -21.32 | 67.82 | 37.13 | 232.77 | 0.7085 | 648.7 | 508.9 | |
| 0.00 | 0.63 | 0.00 | 0.43 | -21.54 | 65.65 | 34.96 | 230.94 | 0.6887 | -479.0 | -449.7 | |
| 0.00 | 0.27 | 0.00 | 0.18 | -20.87 | 65.27 | 34.58 | 231.46 | 0.6803 | -625.0 | -553.0 | |
| 0.00 | 2.90 | 0.00 | 1.95 | -21.55 | 64.70 | 34.01 | 230.19 | 0.6795 | -658.0 | -695.5 | |
| 0.00 | 0.91 | 0.00 | 0.60 | -22.09 | 63.31 | 32.62 | 228.42 | 0.6700 | -664.0 | -637.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
