SDO HMI 2014-07-29 05:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 66.25 | 355.25 | 64.98 | 353.49 | -8.27 | 249.12 | -58.35 | 102.94 | 0.8662 | 459.5 | -23.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-29 05:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.79 | -9.00 | 253.79 | -53.69 | 104.94 | 0.8259 | 294.0 | 322.2 | |
| 2.08 | 329.69 | 1.96 | 326.59 | -8.80 | 250.79 | -56.68 | 103.94 | 0.8529 | 783.0 | -5.3 | |
| 5.35 | -2.00 | 5.07 | -2.00 | -8.64 | 250.55 | -56.93 | 103.69 | 0.8547 | 663.7 | 999999 | |
| 43.41 | -2.00 | 42.31 | -2.00 | -8.10 | 249.46 | -58.01 | 102.82 | 0.8632 | 728.4 | 999999 | |
| 2.90 | -2.00 | 2.86 | -2.00 | -7.49 | 248.95 | -58.52 | 102.01 | 0.8665 | 568.4 | 999999 | |
| 1.00 | 7.79 | 1.02 | 7.93 | -9.79 | 248.30 | -59.17 | 104.47 | 0.8759 | -557.8 | -556.4 | |
| 3.08 | -2.00 | 3.09 | -2.00 | -8.02 | 248.53 | -58.94 | 102.53 | 0.8709 | 364.4 | 999999 | |
| 0.00 | 1.36 | 0.00 | 1.40 | -9.86 | 247.91 | -59.56 | 104.45 | 0.8791 | -634.0 | -580.3 | |
| 0.00 | 1.36 | 0.00 | 1.41 | -10.12 | 247.83 | -59.64 | 104.72 | 0.8802 | -399.0 | -335.8 | |
| 3.26 | -2.00 | 3.28 | -2.00 | -7.79 | 248.34 | -59.13 | 102.22 | 0.8721 | 434.3 | 999999 | |
| 0.00 | 1.18 | 0.00 | 1.25 | -11.39 | 247.28 | -60.19 | 106.00 | 0.8867 | -528.0 | -410.3 | |
| 1.00 | -2.00 | 1.01 | -2.00 | -8.02 | 248.17 | -59.31 | 102.45 | 0.8739 | 121.6 | 999999 | |
| 0.00 | 1.36 | 0.00 | 1.45 | -11.26 | 247.02 | -60.46 | 105.78 | 0.8886 | -474.0 | -414.0 | |
| 0.00 | 1.27 | 0.00 | 1.29 | -7.88 | 247.96 | -59.52 | 102.25 | 0.8754 | 79.0 | 76.9 | |
| 4.17 | -2.00 | 4.38 | -2.00 | -9.72 | 247.33 | -60.14 | 104.16 | 0.8835 | -685.2 | 999999 | |
| 0.00 | 2.08 | 0.00 | 2.22 | -9.15 | 246.68 | -60.79 | 103.38 | 0.8876 | -693.0 | -571.4 | |
| 0.00 | 1.27 | 0.00 | 1.35 | -8.80 | 246.72 | -60.75 | 103.00 | 0.8868 | 74.0 | 64.1 | |
| 0.00 | 1.09 | 0.00 | 1.18 | -5.05 | 245.51 | -61.96 | 98.61 | 0.8911 | 310.0 | 273.3 | |
| 0.00 | 1.09 | 0.00 | 1.22 | -7.22 | 244.85 | -62.62 | 100.88 | 0.8989 | 134.0 | 173.2 | |
| 0.00 | 4.80 | 0.00 | 5.41 | -6.65 | 244.58 | -62.89 | 100.21 | 0.9001 | 305.0 | 234.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
