SDO HMI 2014-07-29 21:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 95.79 | 475.16 | 76.21 | 377.46 | -8.50 | 249.01 | -49.64 | 105.54 | 0.7842 | 345.4 | 80.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-29 21:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.96 | -7.85 | 255.04 | -43.61 | 106.77 | 0.7160 | 172.0 | 224.5 | |
| 0.00 | 1.00 | 0.00 | 0.70 | -6.76 | 255.09 | -43.56 | 105.31 | 0.7118 | 764.0 | 640.8 | |
| 0.00 | 1.63 | 0.00 | 1.15 | -6.58 | 254.94 | -43.71 | 105.02 | 0.7131 | 554.0 | 405.9 | |
| 0.00 | 0.45 | 0.00 | 0.33 | -9.28 | 253.35 | -45.30 | 108.03 | 0.7400 | 506.0 | 348.6 | |
| 0.00 | 0.81 | 0.00 | 0.59 | -6.64 | 253.68 | -44.97 | 104.66 | 0.7279 | 526.0 | 459.2 | |
| 0.00 | 0.45 | 0.00 | 0.35 | -10.95 | 251.18 | -47.47 | 109.33 | 0.7690 | 458.0 | 385.8 | |
| 0.00 | 0.54 | 0.00 | 0.41 | -8.09 | 251.21 | -47.44 | 105.73 | 0.7599 | 526.0 | 375.0 | |
| 2.17 | 451.42 | 1.67 | 358.52 | -8.87 | 250.85 | -47.80 | 106.60 | 0.7660 | 686.3 | 84.5 | |
| 0.00 | 1.36 | 0.00 | 1.03 | -7.39 | 251.00 | -47.65 | 104.77 | 0.7602 | -73.0 | -159.3 | |
| 6.52 | -8.00 | 5.01 | -8.00 | -8.56 | 250.72 | -47.93 | 106.17 | 0.7665 | 839.7 | 999999 | |
| 0.00 | 1.63 | 0.00 | 1.25 | -8.09 | 250.80 | -47.85 | 105.60 | 0.7643 | 496.0 | 460.2 | |
| 0.27 | -8.00 | 0.21 | -8.00 | -8.51 | 249.70 | -48.95 | 105.78 | 0.7772 | 598.3 | 999999 | |
| 0.27 | -8.00 | 0.21 | -8.00 | -8.62 | 249.59 | -49.06 | 105.87 | 0.7787 | 420.7 | 999999 | |
| 45.81 | -8.00 | 35.99 | -8.00 | -8.00 | 249.46 | -49.19 | 105.06 | 0.7784 | 951.6 | 999999 | |
| 2.81 | -8.00 | 2.23 | -8.00 | -8.58 | 249.17 | -49.48 | 105.70 | 0.7830 | -296.4 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.73 | -9.86 | 248.92 | -49.73 | 107.19 | 0.7891 | -383.0 | -356.2 | |
| 0.00 | 1.18 | 0.00 | 0.95 | -10.16 | 248.67 | -49.98 | 107.48 | 0.7926 | -409.0 | -400.9 | |
| 1.45 | -8.00 | 1.14 | -8.00 | -7.40 | 249.13 | -49.52 | 104.21 | 0.7803 | 574.6 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.74 | -10.91 | 248.35 | -50.30 | 108.28 | 0.7979 | -613.0 | -508.1 | |
| 2.54 | -8.00 | 2.01 | -8.00 | -7.61 | 248.86 | -49.79 | 104.39 | 0.7837 | 688.0 | 999999 | |
| 0.00 | 1.36 | 0.00 | 1.12 | -10.99 | 248.14 | -50.51 | 108.31 | 0.8002 | -541.0 | -483.3 | |
| 7.88 | -8.00 | 6.43 | -8.00 | -10.19 | 248.22 | -50.43 | 107.37 | 0.7971 | -828.5 | 999999 | |
| 4.26 | -8.00 | 3.40 | -8.00 | -7.94 | 248.57 | -50.09 | 104.72 | 0.7876 | 538.5 | 999999 | |
| 2.81 | -8.00 | 2.29 | -8.00 | -9.89 | 248.14 | -50.51 | 106.97 | 0.7971 | -753.5 | 999999 | |
| 1.36 | -8.00 | 1.10 | -8.00 | -8.82 | 248.12 | -50.53 | 105.67 | 0.7945 | 366.1 | 999999 | |
| 3.89 | -8.00 | 3.14 | -8.00 | -7.84 | 248.24 | -50.41 | 104.50 | 0.7907 | 512.1 | 999999 | |
| 0.00 | 1.36 | 0.00 | 1.12 | -9.82 | 247.81 | -50.84 | 106.78 | 0.8002 | -634.0 | -618.1 | |
| 3.98 | -8.00 | 3.29 | -8.00 | -9.78 | 247.53 | -51.12 | 106.65 | 0.8029 | -655.4 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.53 | -11.16 | 247.20 | -51.45 | 108.20 | 0.8098 | -563.0 | -484.9 | |
| 8.96 | -8.00 | 7.41 | -8.00 | -9.19 | 247.40 | -51.25 | 105.90 | 0.8027 | -635.9 | 999999 | |
| 0.81 | 2.72 | 0.68 | 2.27 | -8.52 | 246.79 | -51.86 | 104.90 | 0.8071 | 524.2 | 371.0 | |
| 0.00 | 1.18 | 0.00 | 0.99 | -8.57 | 246.53 | -52.12 | 104.89 | 0.8098 | 313.0 | 243.5 | |
| 0.00 | 0.91 | 0.00 | 0.78 | -7.85 | 245.29 | -53.36 | 103.70 | 0.8203 | -291.0 | -296.0 | |
| 0.00 | 1.63 | 0.00 | 1.43 | -7.23 | 244.52 | -54.13 | 102.76 | 0.8264 | 435.0 | 277.1 | |
| 0.00 | 1.72 | 0.00 | 1.51 | -6.53 | 244.32 | -54.33 | 101.88 | 0.8269 | -149.0 | -152.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
