SDO HMI 2014-07-30 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 105.24 | 561.88 | 68.14 | 365.24 | -8.24 | 249.12 | -37.97 | 109.82 | 0.6494 | 412.8 | 145.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-30 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.53 | -8.52 | 257.32 | -29.77 | 115.30 | 0.5452 | 545.0 | 550.8 | |
| 0.00 | 1.00 | 0.00 | 0.58 | -2.07 | 256.22 | -30.86 | 103.23 | 0.5287 | 672.0 | 547.0 | |
| 0.00 | 1.72 | 0.00 | 1.06 | -9.38 | 254.05 | -33.04 | 114.38 | 0.5927 | 652.0 | 519.0 | |
| 0.00 | 1.72 | 0.00 | 1.08 | -8.94 | 252.31 | -34.77 | 112.62 | 0.6126 | -29.0 | -129.8 | |
| 0.00 | 1.27 | 0.00 | 0.79 | -8.28 | 252.31 | -34.78 | 111.61 | 0.6093 | 614.0 | 523.3 | |
| 1.72 | 3.98 | 1.08 | 2.51 | -7.31 | 251.27 | -35.81 | 109.54 | 0.6181 | -736.2 | -522.2 | |
| 0.00 | 3.53 | 0.00 | 2.17 | -1.40 | 251.54 | -35.55 | 100.19 | 0.5928 | 429.0 | 388.5 | |
| 0.00 | 1.09 | 0.00 | 0.69 | -7.70 | 251.05 | -36.04 | 110.01 | 0.6228 | 808.0 | 602.5 | |
| 8.96 | 52.95 | 5.69 | 33.65 | -8.37 | 250.86 | -36.23 | 110.92 | 0.6282 | 919.6 | 377.1 | |
| 0.00 | 1.45 | 0.00 | 0.91 | -7.36 | 250.97 | -36.12 | 109.46 | 0.6223 | -336.0 | -234.2 | |
| 1.81 | 5.52 | 1.15 | 3.51 | -7.85 | 250.53 | -36.55 | 109.98 | 0.6300 | 870.0 | 611.5 | |
| 1.90 | 342.17 | 1.21 | 221.28 | -6.76 | 250.03 | -37.06 | 108.08 | 0.6318 | 865.7 | 322.3 | |
| 0.00 | 1.90 | 0.00 | 1.25 | -10.81 | 249.54 | -37.55 | 113.75 | 0.6563 | -780.0 | -586.4 | |
| 0.00 | 0.27 | 0.00 | 0.18 | -9.23 | 249.56 | -37.52 | 111.50 | 0.6484 | 192.0 | 270.0 | |
| 0.00 | 1.90 | 0.00 | 1.24 | -9.43 | 249.42 | -37.67 | 111.71 | 0.6511 | -86.0 | -109.3 | |
| 64.99 | -12.00 | 41.96 | -12.00 | -7.83 | 249.46 | -37.63 | 109.39 | 0.6435 | 1047.2 | 999999 | |
| 0.00 | 2.35 | 0.00 | 1.56 | -10.80 | 248.60 | -38.49 | 113.22 | 0.6676 | -797.0 | -711.8 | |
| 0.00 | 2.53 | 0.00 | 1.69 | -11.22 | 248.53 | -38.56 | 113.77 | 0.6703 | -621.0 | -517.7 | |
| 1.99 | -12.00 | 1.29 | -12.00 | -7.17 | 248.90 | -38.19 | 108.16 | 0.6478 | 526.1 | 999999 | |
| 4.25 | -12.00 | 2.77 | -12.00 | -7.71 | 248.81 | -38.28 | 108.90 | 0.6512 | 783.2 | 999999 | |
| 0.27 | -12.00 | 0.18 | -12.00 | -8.15 | 248.76 | -38.33 | 109.52 | 0.6537 | 579.0 | 999999 | |
| 0.00 | 1.90 | 0.00 | 1.27 | -11.04 | 248.32 | -38.77 | 113.41 | 0.6720 | -707.0 | -507.3 | |
| 0.00 | 1.18 | 0.00 | 0.77 | -8.81 | 248.64 | -38.45 | 110.43 | 0.6580 | -108.0 | -120.2 | |
| 0.00 | 0.81 | 0.00 | 0.53 | -8.47 | 248.68 | -38.41 | 109.95 | 0.6560 | 203.0 | 166.8 | |
| 1.90 | -12.00 | 1.24 | -12.00 | -7.93 | 248.70 | -38.39 | 109.18 | 0.6534 | 647.0 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.91 | -11.53 | 248.16 | -38.93 | 113.99 | 0.6762 | -773.0 | -688.1 | |
| 0.27 | -12.00 | 0.18 | -12.00 | -8.06 | 248.61 | -38.48 | 109.33 | 0.6551 | 579.3 | 999999 | |
| 0.00 | 3.89 | 0.00 | 2.55 | -8.42 | 248.49 | -38.60 | 109.78 | 0.6581 | 461.0 | 378.5 | |
| 0.00 | 2.08 | 0.00 | 1.39 | -10.55 | 248.12 | -38.97 | 112.61 | 0.6721 | -619.0 | -472.0 | |
| 0.63 | 10.68 | 0.42 | 7.10 | -10.29 | 248.12 | -38.97 | 112.26 | 0.6709 | -906.1 | -663.9 | |
| 0.00 | 1.45 | 0.00 | 0.97 | -11.25 | 247.96 | -39.12 | 113.51 | 0.6772 | -608.0 | -488.5 | |
| 2.44 | 88.53 | 1.62 | 58.74 | -9.47 | 248.19 | -38.89 | 111.14 | 0.6663 | -886.3 | -254.3 | |
| 1.09 | -12.00 | 0.71 | -12.00 | -8.08 | 248.33 | -38.76 | 109.22 | 0.6587 | 477.3 | 999999 | |
| 3.26 | -12.00 | 2.14 | -12.00 | -7.90 | 248.31 | -38.78 | 108.94 | 0.6581 | 639.7 | 999999 | |
| 0.63 | -30.00 | 0.42 | -30.00 | -9.89 | 248.06 | -39.03 | 111.66 | 0.6698 | -893.9 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.80 | -11.78 | 247.72 | -39.37 | 114.10 | 0.6826 | -726.0 | -526.7 | |
| 3.80 | -32.00 | 2.51 | -32.00 | -8.88 | 248.11 | -38.97 | 110.26 | 0.6647 | 70.7 | 999999 | |
| 0.00 | 2.17 | 0.00 | 1.45 | -9.55 | 247.86 | -39.22 | 111.09 | 0.6707 | -711.0 | -708.1 | |
| 0.72 | 1.72 | 0.48 | 1.15 | -9.78 | 247.75 | -39.34 | 111.36 | 0.6730 | -794.6 | -604.2 | |
| 0.00 | 1.45 | 0.00 | 0.96 | -8.08 | 247.81 | -39.27 | 108.98 | 0.6650 | 323.0 | 284.4 | |
| 3.80 | -32.00 | 2.54 | -32.00 | -9.32 | 247.58 | -39.51 | 110.62 | 0.6731 | -694.4 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.02 | -7.91 | 247.60 | -39.49 | 108.63 | 0.6670 | 375.0 | 304.1 | |
| 0.00 | 0.91 | 0.00 | 0.61 | -9.78 | 247.23 | -39.86 | 111.10 | 0.6793 | -489.0 | -385.3 | |
| 0.00 | 1.00 | 0.00 | 0.71 | -15.07 | 245.89 | -41.20 | 117.45 | 0.7190 | 452.0 | 418.1 | |
| 0.81 | 2.35 | 0.55 | 1.59 | -8.39 | 246.45 | -40.64 | 108.79 | 0.6829 | 540.8 | 417.6 | |
| 0.00 | 1.18 | 0.00 | 0.81 | -7.87 | 245.33 | -41.76 | 107.59 | 0.6944 | -619.0 | -562.2 | |
| 0.00 | 1.72 | 0.00 | 1.18 | -6.55 | 245.07 | -42.02 | 105.65 | 0.6929 | 271.0 | 255.2 | |
| 0.00 | 1.36 | 0.00 | 0.96 | -10.20 | 244.19 | -42.90 | 110.27 | 0.7165 | -561.0 | -433.7 | |
| 0.00 | 1.27 | 0.00 | 0.89 | -9.70 | 244.23 | -42.86 | 109.61 | 0.7141 | -748.0 | -644.0 | |
| 0.00 | 1.27 | 0.00 | 0.90 | -10.02 | 244.13 | -42.95 | 110.00 | 0.7164 | -685.0 | -504.8 | |
| 0.00 | 1.27 | 0.00 | 0.89 | -9.18 | 244.06 | -43.03 | 108.84 | 0.7141 | -626.0 | -490.6 | |
| 0.00 | 1.72 | 0.00 | 1.24 | -10.80 | 243.40 | -43.69 | 110.71 | 0.7277 | -275.0 | -287.1 | |
| 0.00 | 0.91 | 0.00 | 0.63 | -6.21 | 244.02 | -43.07 | 104.80 | 0.7045 | -625.0 | -436.0 | |
| 0.00 | 0.72 | 0.00 | 0.54 | -7.31 | 240.81 | -46.27 | 105.16 | 0.7449 | -518.0 | -424.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
