SDO HMI 2014-07-30 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.08 | 62.30 | 19.77 | 50.93 | -18.65 | 237.45 | -47.42 | 118.71 | 0.7970 | -45.9 | -102.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-30 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.00 | 0.00 | 0.70 | -17.56 | 245.22 | -39.65 | 121.51 | 0.7159 | 629.0 | 539.4 | |
| 0.00 | 0.72 | 0.00 | 0.53 | -18.10 | 243.03 | -41.84 | 120.89 | 0.7411 | 686.0 | 575.2 | |
| 0.00 | 0.54 | 0.00 | 0.40 | -18.07 | 242.48 | -42.39 | 120.55 | 0.7465 | 564.0 | 523.3 | |
| 0.00 | 1.27 | 0.00 | 0.94 | -16.31 | 241.86 | -43.01 | 118.06 | 0.7442 | 611.0 | 495.4 | |
| 0.36 | 1.27 | 0.28 | 0.97 | -18.00 | 240.33 | -44.54 | 119.32 | 0.7673 | 769.8 | 663.7 | |
| 6.61 | 13.58 | 5.13 | 10.56 | -18.12 | 239.93 | -44.94 | 119.26 | 0.7718 | 696.7 | 405.9 | |
| 1.81 | -6.00 | 1.42 | -6.00 | -18.31 | 239.59 | -45.28 | 119.32 | 0.7759 | 552.5 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.23 | -18.52 | 238.60 | -46.27 | 119.07 | 0.7862 | 501.0 | 385.5 | |
| 0.00 | 1.54 | 0.00 | 1.23 | -18.38 | 238.28 | -46.60 | 118.75 | 0.7887 | 273.0 | 258.5 | |
| 0.00 | 1.36 | 0.00 | 1.10 | -18.51 | 237.80 | -47.07 | 118.69 | 0.7936 | -287.0 | -282.8 | |
| 0.00 | 1.36 | 0.00 | 1.10 | -18.31 | 237.78 | -47.09 | 118.45 | 0.7930 | -250.0 | -272.0 | |
| 0.00 | 2.63 | 0.00 | 2.16 | -18.63 | 237.09 | -47.78 | 118.50 | 0.8007 | -667.0 | -527.9 | |
| 0.00 | 1.36 | 0.00 | 1.14 | -19.33 | 236.24 | -48.63 | 118.91 | 0.8112 | -363.0 | -336.1 | |
| 6.25 | 22.18 | 5.28 | 18.85 | -19.14 | 236.02 | -48.85 | 118.60 | 0.8125 | -763.0 | -205.0 | |
| 0.00 | 1.27 | 0.00 | 1.08 | -19.56 | 235.85 | -49.02 | 119.00 | 0.8155 | -71.0 | -92.5 | |
| 3.89 | 10.68 | 3.26 | 8.94 | -18.51 | 236.12 | -48.75 | 117.92 | 0.8091 | -822.4 | -586.2 | |
| 3.44 | -14.00 | 2.94 | -14.00 | -19.31 | 235.60 | -49.27 | 118.61 | 0.8168 | -317.2 | 999999 | |
| 1.72 | -14.00 | 1.46 | -14.00 | -19.00 | 235.73 | -49.14 | 118.31 | 0.8145 | -539.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
