SDO HMI 2014-07-31 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 31.44 | 0.00 | 17.06 | 12.59 | 257.03 | -22.35 | 70.43 | 0.3991 | 353.2 | 316.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-31 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.08 | 0.00 | 1.07 | 16.56 | 268.25 | -11.13 | 44.26 | 0.2663 | -932.0 | -678.3 | |
| 0.00 | 1.72 | 0.00 | 0.88 | 13.09 | 265.70 | -13.67 | 60.37 | 0.2661 | -769.0 | -666.8 | |
| 0.00 | 1.27 | 0.00 | 0.66 | 14.25 | 264.18 | -15.20 | 59.16 | 0.2973 | -796.0 | -610.6 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 11.77 | 263.20 | -16.18 | 68.17 | 0.2951 | -840.0 | -576.2 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 15.44 | 261.39 | -17.99 | 59.76 | 0.3461 | -625.0 | -473.2 | |
| 0.00 | 0.72 | 0.00 | 0.38 | 13.42 | 260.63 | -18.75 | 66.02 | 0.3436 | -877.0 | -641.4 | |
| 0.00 | 1.72 | 0.00 | 0.91 | 9.50 | 259.72 | -19.66 | 77.82 | 0.3409 | 818.0 | 659.5 | |
| 0.00 | 1.27 | 0.00 | 0.67 | 9.37 | 259.56 | -19.82 | 78.26 | 0.3431 | 959.0 | 856.4 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 6.69 | 259.66 | -19.72 | 86.12 | 0.3373 | 822.0 | 638.4 | |
| 0.00 | 1.27 | 0.00 | 0.67 | 9.57 | 259.12 | -20.25 | 77.89 | 0.3506 | 772.0 | 658.0 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 16.43 | 258.16 | -21.22 | 61.02 | 0.3985 | 786.0 | 742.0 | |
| 0.00 | 2.17 | 0.00 | 1.17 | 16.26 | 257.91 | -21.47 | 61.65 | 0.4009 | 791.0 | 634.4 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 16.36 | 257.25 | -22.13 | 62.06 | 0.4109 | 720.0 | 586.8 | |
| 0.00 | 0.63 | 0.00 | 0.34 | 15.59 | 257.23 | -22.14 | 63.83 | 0.4063 | 704.0 | 580.0 | |
| 0.00 | 1.18 | 0.00 | 0.63 | 10.12 | 257.23 | -22.15 | 77.26 | 0.3821 | 543.0 | 367.2 | |
| 0.00 | 0.54 | 0.00 | 0.29 | 10.13 | 256.66 | -22.72 | 77.48 | 0.3911 | 646.0 | 422.5 | |
| 0.00 | 1.36 | 0.00 | 0.74 | 4.32 | 255.40 | -23.98 | 92.25 | 0.4073 | 750.0 | 641.6 | |
| 0.00 | 1.99 | 0.00 | 1.08 | 4.50 | 255.36 | -24.02 | 91.80 | 0.4077 | 865.0 | 763.3 | |
| 0.00 | 1.36 | 0.00 | 0.74 | 4.40 | 255.19 | -24.18 | 92.01 | 0.4104 | 808.0 | 651.1 | |
| 0.00 | 1.36 | 0.00 | 0.76 | 14.31 | 252.29 | -27.09 | 70.07 | 0.4713 | 793.0 | 609.6 | |
| 0.00 | 1.36 | 0.00 | 0.79 | 19.04 | 249.35 | -30.03 | 62.82 | 0.5339 | 725.0 | 550.5 | |
| 0.00 | 1.27 | 0.00 | 0.76 | 20.35 | 247.82 | -31.55 | 61.50 | 0.5604 | 581.0 | 475.3 | |
| 0.00 | 1.45 | 0.00 | 0.86 | 15.34 | 246.52 | -32.85 | 70.78 | 0.5562 | 636.0 | 551.0 | |
| 0.00 | 1.27 | 0.00 | 0.78 | 14.93 | 243.50 | -35.88 | 72.53 | 0.5959 | 597.0 | 491.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
