SDO HMI 2014-08-01 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47.34 | 99.44 | 30.37 | 63.41 | -18.92 | 237.69 | -30.65 | 130.05 | 0.6316 | -81.2 | -21.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-01 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.81 | -17.06 | 242.73 | -25.61 | 132.51 | 0.5627 | 749.0 | 563.9 | |
| 0.00 | 0.81 | 0.00 | 0.49 | -18.20 | 242.41 | -25.93 | 133.70 | 0.5767 | 603.0 | 448.2 | |
| 0.00 | 1.09 | 0.00 | 0.66 | -18.02 | 242.05 | -26.29 | 133.07 | 0.5788 | 654.0 | 422.8 | |
| 0.00 | 1.00 | 0.00 | 0.60 | -17.70 | 241.78 | -26.56 | 132.36 | 0.5787 | 679.0 | 519.7 | |
| 5.43 | 9.06 | 3.36 | 5.60 | -18.17 | 240.15 | -28.19 | 131.33 | 0.6000 | 909.6 | 639.7 | |
| 1.63 | 11.86 | 1.01 | 7.39 | -18.36 | 239.68 | -28.67 | 131.12 | 0.6066 | 912.8 | 662.9 | |
| 3.35 | -6.00 | 2.09 | -6.00 | -18.31 | 239.36 | -28.99 | 130.75 | 0.6095 | 835.2 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.40 | -18.53 | 238.95 | -29.40 | 130.65 | 0.6156 | 592.0 | 462.1 | |
| 1.18 | 4.71 | 0.74 | 2.94 | -18.20 | 238.97 | -29.37 | 130.24 | 0.6126 | 682.2 | 618.9 | |
| 0.00 | 0.54 | 0.00 | 0.34 | -19.25 | 238.66 | -29.69 | 131.30 | 0.6246 | 403.0 | 365.5 | |
| 6.70 | 13.31 | 4.23 | 8.40 | -18.75 | 238.57 | -29.77 | 130.58 | 0.6213 | 695.2 | 380.8 | |
| 0.00 | 1.00 | 0.00 | 0.63 | -18.39 | 238.49 | -29.85 | 130.04 | 0.6192 | 241.0 | 296.7 | |
| 0.63 | -11.00 | 0.40 | -11.00 | -18.67 | 238.21 | -30.13 | 130.15 | 0.6244 | 515.4 | 999999 | |
| 0.00 | 1.63 | 0.00 | 1.05 | -19.90 | 237.81 | -30.53 | 131.34 | 0.6385 | -230.0 | -347.4 | |
| 0.00 | 1.27 | 0.00 | 0.80 | -18.62 | 237.89 | -30.45 | 129.80 | 0.6274 | 468.0 | 375.3 | |
| 0.45 | 1.54 | 0.29 | 0.99 | -19.44 | 237.04 | -31.30 | 130.09 | 0.6426 | -783.8 | -681.2 | |
| 0.00 | 2.99 | 0.00 | 1.92 | -19.13 | 237.07 | -31.27 | 129.73 | 0.6399 | -692.0 | -602.7 | |
| 0.00 | 1.45 | 0.00 | 0.93 | -18.63 | 237.10 | -31.24 | 129.11 | 0.6357 | -863.0 | -784.8 | |
| 1.81 | 6.34 | 1.17 | 4.09 | -19.15 | 236.80 | -31.54 | 129.51 | 0.6428 | -895.3 | -715.5 | |
| 1.99 | -19.00 | 1.28 | -19.00 | -18.98 | 236.76 | -31.58 | 129.27 | 0.6419 | -899.9 | 999999 | |
| 2.17 | 19.74 | 1.41 | 12.84 | -19.41 | 236.29 | -32.05 | 129.41 | 0.6501 | -954.5 | -675.7 | |
| 5.34 | -21.00 | 3.48 | -21.00 | -19.58 | 236.17 | -32.17 | 129.53 | 0.6526 | -722.2 | 999999 | |
| 2.90 | -21.00 | 1.88 | -21.00 | -19.11 | 236.28 | -32.06 | 129.02 | 0.6479 | -864.3 | 999999 | |
| 3.98 | 6.07 | 2.58 | 3.93 | -18.75 | 236.09 | -32.25 | 128.41 | 0.6471 | -781.9 | -616.8 | |
| 9.78 | 13.04 | 6.45 | 8.60 | -19.86 | 235.42 | -32.93 | 129.25 | 0.6624 | -822.5 | -484.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
