SDO HMI 2014-08-02 00:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.21 | 70.32 | 63.44 | 329.06 | 9.02 | 172.85 | -84.47 | 81.53 | 0.9938 | 69.5 | 51.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-02 00:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.71 | 10.41 | 6.59 | 25.28 | 10.49 | 178.31 | -79.00 | 80.47 | 0.9796 | -514.4 | -370.6 | |
| 0.00 | 1.45 | 0.00 | 3.82 | 10.54 | 177.21 | -80.10 | 80.35 | 0.9832 | 96.0 | 79.6 | |
| 0.00 | 1.18 | 0.00 | 3.72 | 10.46 | 175.48 | -81.84 | 80.30 | 0.9882 | 348.0 | 354.0 | |
| 0.00 | 1.27 | 0.00 | 4.14 | 10.28 | 175.26 | -82.06 | 80.47 | 0.9888 | 220.0 | 249.4 | |
| 0.00 | 1.36 | 0.00 | 5.22 | 10.99 | 173.64 | -83.67 | 79.63 | 0.9925 | 311.0 | 268.1 | |
| 0.00 | 6.97 | 0.00 | 27.46 | 9.30 | 173.82 | -83.49 | 81.34 | 0.9924 | 419.0 | 417.0 | |
| 0.00 | 6.24 | 0.00 | 21.16 | 7.93 | 175.01 | -82.31 | 82.82 | 0.9899 | 146.0 | 142.7 | |
| 2.35 | 22.62 | 13.01 | 137.06 | 9.28 | 171.82 | -85.49 | 81.19 | 0.9960 | 98.2 | -29.3 | |
| 1.09 | 18.82 | 5.37 | 101.20 | 8.70 | 172.20 | -85.12 | 81.80 | 0.9955 | 257.4 | 99.6 | |
| 7.06 | -9.00 | 38.47 | -9.00 | 8.12 | 171.69 | -85.63 | 82.34 | 0.9964 | 104.4 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
