SDO HMI 2014-08-02 15:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.03 | 111.84 | 30.50 | 228.87 | 9.15 | 172.51 | -76.56 | 82.01 | 0.9702 | 183.4 | 74.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-02 15:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.99 | 12.49 | 4.41 | 18.33 | 10.12 | 178.02 | -71.05 | 81.32 | 0.9433 | -574.0 | -402.7 | |
| 0.00 | 1.72 | 0.00 | 2.56 | 10.44 | 177.76 | -71.31 | 80.97 | 0.9447 | -477.0 | -457.4 | |
| 0.00 | 1.09 | 0.00 | 1.64 | 10.94 | 177.48 | -71.60 | 80.43 | 0.9462 | -326.0 | -335.5 | |
| 0.00 | 3.08 | 0.00 | 5.21 | 10.20 | 175.28 | -73.80 | 81.10 | 0.9579 | 484.0 | 393.0 | |
| 0.00 | 1.36 | 0.00 | 2.55 | 11.08 | 173.47 | -75.60 | 80.08 | 0.9661 | 297.0 | 296.5 | |
| 0.00 | 0.81 | 0.00 | 1.54 | 10.77 | 173.46 | -75.62 | 80.40 | 0.9663 | 510.0 | 494.7 | |
| 0.00 | 1.36 | 0.00 | 2.66 | 11.30 | 172.91 | -76.17 | 79.82 | 0.9685 | 51.0 | 94.9 | |
| 0.00 | 5.70 | 0.00 | 10.55 | 9.20 | 173.90 | -75.17 | 82.05 | 0.9647 | 459.0 | 431.5 | |
| 0.00 | 1.90 | 0.00 | 3.96 | 11.43 | 171.98 | -77.10 | 79.64 | 0.9723 | 401.0 | 354.4 | |
| 0.00 | 2.53 | 0.00 | 4.94 | 8.87 | 173.09 | -75.98 | 82.34 | 0.9683 | 533.0 | 510.7 | |
| 0.00 | 2.17 | 0.00 | 4.35 | 9.20 | 172.62 | -76.45 | 81.97 | 0.9703 | 565.0 | 514.2 | |
| 0.00 | 1.72 | 0.00 | 3.61 | 9.02 | 172.06 | -77.02 | 82.12 | 0.9726 | 398.0 | 410.3 | |
| 2.08 | 38.45 | 4.31 | 83.17 | 8.66 | 172.16 | -76.91 | 82.50 | 0.9723 | 414.1 | 118.9 | |
| 5.79 | 37.46 | 12.66 | 83.80 | 9.21 | 171.49 | -77.58 | 81.88 | 0.9748 | 306.1 | -32.4 | |
| 1.18 | -13.00 | 2.47 | -13.00 | 8.49 | 171.99 | -77.08 | 82.66 | 0.9730 | 495.0 | 999999 | |
| 2.99 | -13.00 | 6.65 | -13.00 | 8.35 | 171.22 | -77.86 | 82.75 | 0.9761 | 55.0 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
